Charge Up The Trails - Unmatched performance in an SL e-trail bike
We’re proud to unveil the latest evolution in our lineup: the Collosus TLE. Born from a passion to push the limits of our Collosus platform, the TLE was designed to elevate the trail experience for riders like you. Drawing inspiration from the success of the Collosus N and DH models, the TLE reintroduces carbon construction and integrates our Independent Floating Suspension (IFS) system—refined to be lighter, stiffer, and more efficient than ever. The goal? Deliver unmatched performance without compromise. Years of development and rider feedback shaped the Collosus TLE into more than just a bike; it’s a companion built for progress. With a custom-tuned ride feel and dialed-in suspension kinematics, it balances anti-squat, anti-rise, and leverage curve to deliver precise climbing efficiency, confident braking, and plush responsiveness on every descent. Built around a full 29er platform, the TLE features Fox-tuned shocks and a versatile shock yoke, offering extensive adjustability to match your style. Practical touches like tailgate protection, generous chainstay coverage, and internal cable routing complete a clean, quiet ride on any trail. The TLE is also future-ready, with Bosch motor compatibility, a range extender option, and a Bosch PowerMore 250Wh battery included as standard—ready to take on long rides and epic adventures alike. The Collosus TLE is more than a new model—it’s a statement of our commitment to progress, performance, and the journey ahead. Experience what’s next in full-suspension carbon trail bikes.
Robust IFS linkage construction
The main part of the IFS system is the double link at the bottom of the seat tube, on the TLE we separated the links which gives us more freedom to keep the same anti squat, which was all dictated by the characteristics of the previous model.
A ride that’s balanced, powerful, and light
With a rear end length of 450mm, the Collosus TLE delivers a well-balanced ride. The longer chainstays are designed to seamlessly accommodate the Bosch Performance Line SX motor, providing a powerful 55 Nm of torque paired with a 400 Wh battery. It climbs with ease and descends with the confidence of a full enduro bike.
Smart design, built-in convenience
From a 750ml bottle fitment to Power More range extender compatibility with a 250Wh battery included, every detail is built for convenience. The top tube blends form and function, letting riders check sag while seated. With internal cable routing and dropper post integration, the Collosus TLE stays clean and purpose-driven.
UDH compatibility for next-gen shifting
With the UDH dropouts, the Collosus TLE is now compatible with T-Type drivetrains for seamless integration with modern shifting systems.
Ready for a more robust dropper post
Now featuring a 34.9mm seat tube diameter to support stronger, more reliable dropper posts.
Double-row bearings, consistent performance
The frame runs 3901 double row sealed bearings, ensuring unparalleled consistency across all main pivot points, including the shock yoke.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frameset | ACX e-MTB |
| fork | FOX PERFORMANCE ELITE 36, FLOAT EVOL, 160mm TRAVEL, OFFSET - 44mm, HSC-LSC, HSR-LSR, W/ FENDER |
| rear shock | FOX FLOAT X PERFORMANCE ELITE, E2E - 210x55mm |
| frame color | GREEN / BLUE |
| decal color | BLACK SILVER |
| shifter | SRAM EC AXS POD CONTROLLER, 1x12-SPEED TRIGGER |
| crank | SRAM XX CARBON T-TYPE, 34T |
| cassette | SRAM XX EAGLE T-TYPE 10-52T XD DRIVER |
| rear derailleur | SRAM XX EAGLE T-TYPE AXS |
| chain | SRAM XX T-TYPE |
| saddle | XTENT, CR-MO ø7mm |
| seatpost | TRANZ X JD-YSP39KL 170mm (S, M) / 200mm (L, XL) TRAVEL, DxL - 34.9x495mm (S, M) / 556mm (L, XL) |
| handlebar | RACE FACE CHESTER 35, W - 780mm, BB - 35mm, R/D - 35mm, B - 8degree |
| handlestem | Race Face Affect R 35, EXT - 40mm, BB - 35mm, R/D - 0mm |
| headset | FSA NO.42/47/ACB, IS 42/28.6 | IS 52/40 |
| wheel set | MT6 TUBELESS READY |
| tire | MAXXIS DISSECTOR 29"x2.40" 622x65, TLE |
| rim | F - ALLOY DOUBLE WALL FV H -18mm 622x36 32H FOR TYRE 622-54/76 W/ TUBELESS TAPE / R - ALLOY DOUBLE WALL FV H -18mm 622x36 32H FOR TYRE 622-54/76 W/ TUBELESS TAPE |
| hub | F - DT SWISS 370 HYBRID CLASSIC 15x110mm 32H 6-BOLT / R - DT SWISS 370 HYBRID CLASSIC 12x148mm 32H 6-BOLT FOR XD DRIVER |
| spokes | F - STAINLESS 14G NDS -292mm DS -294mm W/ 12mm BRASS NIPPLE / R - STAINLESS 14G NDS -294mm DS -292mm W/ 12mm BRASS NIPPLE |
| brake lever | MAGURA HC3 |
| brake caliper | MAGURA MT7 HYDRAULIC DISC |
| rotor | MAGURA MDR C, 203MM 6-BOLT |
| motor | BOSCH PERFORMANCE LINE SX BDU3145 |
| sensor | BOSCH RIM MAGNET |
| battery | BOSCH COMPACTTUBE 400 FIXED MOUNT HORIZONTAL |
| Frame Material | Carbon |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Groupset Model | XX1 Eagle AXS |
| Fork Brand | Fox |
| Motor Brand | Bosch |
| Max Assisted Speed | 32km/h |
| Battery Brand | Bosch |
| Motor Type | Mid-Drive Motor |
| Shifting Type | Electronic |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Enduro |
| Frameset | ACX e-MTB |
| Fork | FOX PERFORMANCE ELITE 36, FLOAT EVOL, 160mm TRAVEL, OFFSET - 44mm, HSC-LSC, HSR-LSR, W/ FENDER |
| REAR SHOCK | FOX FLOAT X PERFORMANCE ELITE, E2E - 210x55mm |
| FRAME COLOR | GREEN / BLUE |
| DECAL COLOR | BLACK SILVER |
| Shifter | SRAM EC AXS POD CONTROLLER, 1x12-SPEED TRIGGER |
| CRANK | SRAM XX CARBON T-TYPE, 34T |
| Cassette | SRAM XX EAGLE T-TYPE 10-52T XD DRIVER |
| Rear Derailleur | SRAM XX EAGLE T-TYPE AXS |
| Chain | SRAM XX T-TYPE |
| Saddle | XTENT, CR-MO ø7mm |
| Seatpost | TRANZ X JD-YSP39KL 170mm (S, M) / 200mm (L, XL) TRAVEL, DxL - 34.9x495mm (S, M) / 556mm (L, XL) |
| Handlebar | RACE FACE CHESTER 35, W - 780mm, BB - 35mm, R/D - 35mm, B - 8degree |
| Handlestem | Race Face Affect R 35, EXT - 40mm, BB - 35mm, R/D - 0mm |
| Headset | FSA NO.42/47/ACB, IS 42/28.6 | IS 52/40 |
| Wheel Set | MT6 TUBELESS READY |
| TIRE | MAXXIS DISSECTOR 29"x2.40" 622x65, TLE |
| Rim | F - ALLOY DOUBLE WALL FV H -18mm 622x36 32H FOR TYRE 622-54/76 W/ TUBELESS TAPE / R - ALLOY DOUBLE WALL FV H -18mm 622x36 32H FOR TYRE 622-54/76 W/ TUBELESS TAPE |
| Hub | F - DT SWISS 370 HYBRID CLASSIC 15x110mm 32H 6-BOLT / R - DT SWISS 370 HYBRID CLASSIC 12x148mm 32H 6-BOLT FOR XD DRIVER |
| SPOKES | F - STAINLESS 14G NDS -292mm DS -294mm W/ 12mm BRASS NIPPLE / R - STAINLESS 14G NDS -294mm DS -292mm W/ 12mm BRASS NIPPLE |
| Brake lever | MAGURA HC3 |
| BRAKE CALIPER | MAGURA MT7 HYDRAULIC DISC |
| Rotor | MAGURA MDR C, 203MM 6-BOLT |
| Motor | BOSCH PERFORMANCE LINE SX BDU3145 |
| SENSOR | BOSCH RIM MAGNET |
| Battery | BOSCH COMPACTTUBE 400 FIXED MOUNT HORIZONTAL |
| Frame Style | Step-Over |
