The Fuel EX 7 is a do-anything trail machine evolved to eat up singletrack. Upgraded 150 mm front and 140 mm rear suspension smooth out rough and technical descents, while a lightweight aluminium frame keeps things lively on the climbs. New in-frame storage and adjustable geometry give you all the perks that come with the carbon model, without the price tag. Tubeless wheels, and reliable Shimano SLX 1x12 drivetrain round-out this build for ultimate trail fun.
It's right for you if...
You're looking for a ride-anything full-suspension with stepped-up components, like a supple RockShox Gold RL fork that gobbles up rock gardens for fun and flowy descents.
The tech you get
A lightweight alloy full-suspension frame with 150 mm RockShox Gold RL fork with DebonAir spring for small bump compliance and a FOX Performance rear shock. Plus, a 1x12 Shimano SLX drivetrain and wide Bontrager wheels with tubeless tyres and a dropper post. New adjustable geometry that lets you take control of your set-up.
Why you'll love it
The final word
For the all-mountain rider, the Fuel EX 7 takes the cake. Its capable geometry is ready to rally the mountain, and upgraded suspension and drivetrain keep you riding all day.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| fork | RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel |
| shock | Fox Performance Float EVOL, 3-position DPS damper, tuned by Trek Suspension Lab, 185 mm x 55 mm |
| wheel front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle |
| wheel rear (xs/s) | Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 54, 6-bolt, Boost148, 12 mm thru axle |
| wheel rear (s/m/ml/l/xl/xxl) | Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12 mm thru axle |
| hub front | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle |
| hub rear | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle |
| skewer rear | Bontrager Switch thru-axle, removable lever |
| rim | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
| tyre (xs/s) | Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi, 27.5x2.50" |
| tyre (s/m/ml/l/xl/xxl) | Bontrager XR5 Team Issue, Tubeless Ready, aramid bead, 120 tpi, 29x2.50" |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| rim strip | Bontrager TLR |
| shifter | Shimano SLX M7100, 12-speed |
| rear derailleur | Shimano XT M8100, long cage |
| crank | Shimano Deore M6120, 30T ring, 55 mm chainline, 170 mm length |
| bottom bracket | Shimano BB-MT501 BSA |
| cassette | Shimano Deore M6100, 10-51, 12-speed |
| chain | Shimano Deore M6100, 12-speed |
| saddle | Bontrager Arvada, steel rails, 138 mm width |
| seatpost | TranzX JD-YSI-22PLQ, internal routing, 34.9 mm, 346 mm length |
| seatpost travel | XS/S - 100mm; M/ML - 150mm; L/XL/XXL - 170mm |
| handlebar | Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width |
| grips | Bontrager XR Trail Comp, nylon lock-on |
| stem | Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree |
| stem length | XS/S - 35mm; M/ML/L/XL/XXL - 50mm |
| head set | Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible |
| brake | Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper |
| brake rotor | Shimano RT66, 6-bolt |
| weight | M – 15.97 kg/35.21 lb (with TLR sealant, no tubes) |
| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| frame | Alpha Platinum Aluminium, internal storage, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, guided internal routing, 34.9 mm seat tube, downtube guard, 140 mm travel |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Groupset Brand | Shimano |
| Groupset Model | XT |
| Fork Brand | Rockshox |
| Fork Travel | 141 - 170mm |
| Shock Travel | 121 - 140mm |
| Pedals Included | No |
| Ride Style | Trail |
| Fork | RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel |
| Shock | Fox Performance Float EVOL, 3-position DPS damper, tuned by Trek Suspension Lab, 185 mm x 55 mm |
| Wheel Front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle |
| Wheel rear (XS/S) | Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 54, 6-bolt, Boost148, 12 mm thru axle |
| Wheel rear (S/M/ML/L/XL/XXL) | Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12 mm thru axle |
| Hub Front | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle |
| Hub Rear | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle |
| Skewer rear | Bontrager Switch thru-axle, removable lever |
| Rim | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
| Tyre (XS/S) | Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi, 27.5x2.50" |
| Tyre (S/M/ML/L/XL/XXL) | Bontrager XR5 Team Issue, Tubeless Ready, aramid bead, 120 tpi, 29x2.50" |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Rim strip | Bontrager TLR |
| Shifter | Shimano SLX M7100, 12-speed |
| Rear Derailleur | Shimano XT M8100, long cage |
| CRANK | Shimano Deore M6120, 30T ring, 55 mm chainline, 170 mm length |
| Bottom Bracket | Shimano BB-MT501 BSA |
| Cassette | Shimano Deore M6100, 10-51, 12-speed |
| Chain | Shimano Deore M6100, 12-speed |
| Saddle | Bontrager Arvada, steel rails, 138 mm width |
| Seatpost | TranzX JD-YSI-22PLQ, internal routing, 34.9 mm, 346 mm length |
| Seatpost travel | XS/S - 100mm; M/ML - 150mm; L/XL/XXL - 170mm |
| Handlebar | Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width |
| GRIPS | Bontrager XR Trail Comp, nylon lock-on |
| Stem | Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree |
| Stem Length | XS/S - 35mm; M/ML/L/XL/XXL - 50mm |
| Head Set | Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible |
| BRAKE | Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper |
| BRAKE ROTOR | Shimano RT66, 6-bolt |
| Weight | M – 15.97 kg/35.21 lb (with TLR sealant, no tubes) |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| FRAME | Alpha Platinum Aluminium, internal storage, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, guided internal routing, 34.9 mm seat tube, downtube guard, 140 mm travel |
| Brake Type | Hydraulic Disc Brake |
| Shifting Type | Mechanical |
| Drivetrain Gearing | 1 x 12 |
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
