The Splice strikes that coveted balance of bike path-cruiser and hybrid comfort. It’s the perfect complement to a camping trip, the perfect steed for rides through the local park, and it’s also a great commuter. It’s got modern geometry that provides an excellent fit with a shorter reach and the ability to run a dropper post. The Splice has just enough suspension up front that you can lock out for efficient pedaling, hydraulic disc brakes for powerful stopping, and sturdy wheels and tires. It may just tempt you to explore further than ever before.
KONA 6061 ALUMINUM
Kona 7005 and 6061 Aluminum alloys are used extensively throughout our fleet of mountain and asphalt bicycles. A tough, durable, light alloy, both Kona 7005 and 6061 deliver fantastic, reliable performance that lasts for thousands of rides. Much of our 7005/6061 tubing is butted and/or formed, meaning the tubing’s wall thickness can be increased or decreased, as well as shaped, so we can fine-tune a particular frame’s strength and ride characteristics depending on its intended application.
INTERNAL HEADSET
Bearing cups are actually pressed into the frame and are easily removable. An internal headset also reduces stack height, so the height of the stem and bars are more adjustable, giving the rider the best fit possible.
TAPERED HEAD TUBE
More girth at the bottom of the head tube better distributes shock force, prolonging the bearing life of the headset itself and eliminating brake shudder, while providing confident steering performance. The inherent strength of its triangular design also means a stronger steering position and improved balance, giving the rider more control in rough terrain. A zero-stack, tapered head tube also puts strength where the load is going—into the lower headset cup—maximizing bearing durability where it’s needed.
| sizes | S, M, L, XL |
| rear shock | N/A |
| fork | Suntour NEX Coil Spring 80mm |
| crankarms | Shimano |
| shifters | Shimano Altus |
| b/b | FSA 68mm |
| pedals | Kona JS2 |
| chain | KMC Z8.3 |
| freewheel | Shimano Altus 11-34t 8spd |
| chainguide | n/a |
| f/d | Shimano Tourney |
| r/d | Shimano Tourney |
| brake calipers | Tektro HDM275 Hydraulic |
| front brake rotor | Tektro TR160 160mm |
| rear brake rotor | Tektro TR160 160mm |
| brake levers | Tektro HDM275 hydraulic |
| headset | Feimin FP-H863 |
| handlebar | Kona Aluminum Riser |
| stem | Kona Control |
| seatpost | Kona Thumb w/Offset 31.6mm |
| seat clamp | Kona Clamp |
| grips | Kona Key Grip Slip on |
| saddle | Kona Crosstrail |
| front hub | Formula 100x9mm |
| rear hub | Formula 135x10mm |
| spokes | Stainless Black 14g |
| rims | Double wall alloy |
| front tire | WTB Venture 700x50c |
| rear tire | WTB Venture 700x50c |
| paint color | Satin Metallic Gose Blue w/ Metallic Mint & Metallic Silver Decals |
| Fork Material | Suspension |
| Groupset Brand | Shimano |
| Groupset Model | Tourney |
| Fork Brand | Suntour |
| Ride Style | Urban |
| SIZES | S, M, L, XL |
| REAR SHOCK | N/A |
| Fork | Suntour NEX Coil Spring 80mm |
| CRANKARMS | Shimano |
| Shifters | Shimano Altus |
| B/B | FSA 68mm |
| PEDALS | Kona JS2 |
| Chain | KMC Z8.3 |
| FREEWHEEL | Shimano Altus 11-34t 8spd |
| CHAINGUIDE | n/a |
| F/D | Shimano Tourney |
| R/D | Shimano Tourney |
| Brake Calipers | Tektro HDM275 Hydraulic |
| FRONT BRAKE ROTOR | Tektro TR160 160mm |
| Rear brake rotor | Tektro TR160 160mm |
| Brake Levers | Tektro HDM275 hydraulic |
| Headset | Feimin FP-H863 |
| Handlebar | Kona Aluminum Riser |
| Stem | Kona Control |
| Seatpost | Kona Thumb w/Offset 31.6mm |
| SEAT CLAMP | Kona Clamp |
| GRIPS | Kona Key Grip Slip on |
| Saddle | Kona Crosstrail |
| FRONT HUB | Formula 100x9mm |
| REAR HUB | Formula 135x10mm |
| SPOKES | Stainless Black 14g |
| RIMS | Double wall alloy |
| FRONT TIRE | WTB Venture 700x50c |
| REAR TIRE | WTB Venture 700x50c |
| PAINT COLOR | Satin Metallic Gose Blue w/ Metallic Mint & Metallic Silver Decals |
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
