Fuel EX 9.8 XT Di2 is a versatile and adaptable carbon MTB built to tackle any trail, anytime. Its OCLV Mountain Carbon frame pairs with a Fox Factory suspension package (145mm rear, 150mm front) to deliver traction and stability in the rough. Shimano’s wireless XT Di2 M8250 12-speed drivetrain gives you robust, light, and crisp customizable shifting, while 4-piston Shimano XT M8220 brakes provide excellent modulation and stop-on-a-dime power.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| rim strip | Bontrager TLR |
| stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| skewer rear | Bontrager Switch thru axle, removable lever |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| bottom bracket | Shimano BB-MT501 BSA |
| saddle | Verse Short Comp, steel rails, 145 mm width |
| handlebar | Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width |
| shifter | Shimano XT Di2 M8250, 12-speed |
| rear derailleur | Shimano XT M8250, long cage |
| cassette | Shimano XT M8200, 10-51, 12-speed |
| grips | Trek Line Elite, lock-on |
| wheel front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" |
| chain | Shimano Ultegra/XT M8100 |
| brake | Shimano XT M8220 4-piston hydraulic disc |
| head set | FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown |
| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lbs). |
| max tyre size | Frame- 29x2.50", Fork- See manufacturer |
| max. chainring size | Max- 34T (oval – 32T) Min- 30T (oval – 32T) |
| rotor size | Max brake rotor sizes - Frame- 203mm, Fork- see fork manufacturer |
| frame | OCLV Mountain Carbon, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable trav |
| fork | Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 150mm travel |
| wheel rear | Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano Micro Spline or SRAM XD freehub, Boost148, 12mm thru axle [Size S- 27.5" | Sizes M, L, XL, XXL- 29"] |
| tyre | Maxxis Minion (DHF Front / DHR II Rear) tubeless ready, 3C, EXO+ casing, folding bead [Sizes M, L, XL, XXL- 29x2.5" | Size S- 27.5x2.5" Rear, 29x2.5" Front] |
| crank | Shimano XT M8200, 30T, 55mm chainline, 165mm or 170mm length (All sizes) |
| seatpost | Bontrager Line Dropper, MaxFlow, internal routing, 34.9 mm [Size S- 150mm travel, 410 mm length | Size M- 170 mm travel, 450 mm length | Sizes L, XL, XXL- 200 mm travel, 515 mm length] |
| brake rotor | Shimano RT86, 6-bolt, 180 mm or 203 mm (All sizes) |
| Groupset Brand | Shimano |
| Fork Brand | Fox |
| Frame Material | Carbon & Alloy |
| Fork Travel | 141 - 170mm |
| Shock Travel | 141 - 170mm |
| Pedals Included | No |
| Groupset Model | XT Di2 |
| Ride Style | Trail |
| Rim strip | Bontrager TLR |
| Stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| Fork Material | Suspension |
| Skewer rear | Bontrager Switch thru axle, removable lever |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Bottom Bracket | Shimano BB-MT501 BSA |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 12 |
| Shifting Type | Electronic |
| Saddle | Verse Short Comp, steel rails, 145 mm width |
| Handlebar | Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width |
| Shifter | Shimano XT Di2 M8250, 12-speed |
| Rear Derailleur | Shimano XT M8250, long cage |
| Cassette | Shimano XT M8200, 10-51, 12-speed |
| GRIPS | Trek Line Elite, lock-on |
| Wheel Front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" |
| Chain | Shimano Ultegra/XT M8100 |
| BRAKE | Shimano XT M8220 4-piston hydraulic disc |
| Head Set | FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lbs). |
| MAX TYRE SIZE | Frame- 29x2.50", Fork- See manufacturer |
| Max. chainring size | Max- 34T (oval – 32T) Min- 30T (oval – 32T) |
| Rotor size | Max brake rotor sizes - Frame- 203mm, Fork- see fork manufacturer |
| FRAME | OCLV Mountain Carbon, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable trav |
| Fork | Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 150mm travel |
| Wheel Rear | Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano Micro Spline or SRAM XD freehub, Boost148, 12mm thru axle [Size S- 27.5" | Sizes M, L, XL, XXL- 29"] |
| Tyre | Maxxis Minion (DHF Front / DHR II Rear) tubeless ready, 3C, EXO+ casing, folding bead [Sizes M, L, XL, XXL- 29x2.5" | Size S- 27.5x2.5" Rear, 29x2.5" Front] |
| CRANK | Shimano XT M8200, 30T, 55mm chainline, 165mm or 170mm length (All sizes) |
| Seatpost | Bontrager Line Dropper, MaxFlow, internal routing, 34.9 mm [Size S- 150mm travel, 410 mm length | Size M- 170 mm travel, 450 mm length | Sizes L, XL, XXL- 200 mm travel, 515 mm length] |
| BRAKE ROTOR | Shimano RT86, 6-bolt, 180 mm or 203 mm (All sizes) |
