Madone SLR 7 Gen 8 is an aero, featherlight road bike built to race. Its 900 Series OCLV Carbon frame cuts weight and adds aero gains, while IsoFlow tech boosts comfort without sacrificing speed. It’s race-ready with a wireless 2x12 Shimano Ultegra Di2 groupset, Bontrager Aeolus Pro 51 wheels, a Trek Aero RSL one-piece bar/stem, and RSL Aero Bottles and Cages for added drag reduction.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| bottom bracket | Praxis, T47 threaded, internal bearing |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| front derailleur | Shimano Ultegra R8150 Di2, braze-on, down swing |
| wheel front | Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12 mm thru axle |
| battery | Shimano BT-DN300 |
| brake rotor | Shimano CL800, CentreLock, 160 mm |
| max tyre size | 32mm (as measured, see manual for details) |
| rear derailleur | Shimano Ultegra R8150 Di2, 34T max cog |
| wheel rear | Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12 mm thru axle |
| cassette | Shimano Ultegra R8101, 11-30, 12-speed |
| skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| fork | Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100 mm chamfered thru axle |
| skewer front | Bontrager Switch chamfered thru axle |
| frame with fork | 900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle |
| seatpost | Madone aero carbon seat post, 0 mm offset, short length |
| chain | Shimano Ultegra/XT M8100 |
| weight | Size ML - 7.52 kg/16.58 lb (with TLR sealant, no tubes, no bottles/cages) |
| shifter | Shimano Ultegra R8170 Di2 or R8171 Di2, 12-speed (All sizes) |
| crank | Shimano Ultegra R8100, 52/36 [Sizes XS, S- 160mm or 165mm length | Sizes M, ML- 165mm, 170mm, or 172.5mm length | Size L- 170mm or 172.5mm length | Size XL- 170mm, 172.5mm, or 175mm length] |
| max. chainring size | 1x- 54T, 2x- 56/43 |
| tyre | Bontrager Aeolus RSL RD, Pirelli P Zero Race, or Pirelli P Zero Race TLR RS, 700x28 mm (All sizes) |
| tube | Pirelli P Zero SmarTube, TPU |
| saddle | Bontrager Aeolus Pro or Trek Aeolus Pro, carbon rails, 145 mm width (All sizes) |
| handlebar tape | Trek EcoTack or Trek gel cork (All sizes) |
| rotor size | Max brake rotor sizes- 180 mm front, 160 mm rear |
| handlebar/stem (integrated) | Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop [Size XS- 35cm control/38cm drop width, 80mm stem | Size S- 37cm control/40cm drop width, 90mm stem | Size M- 39cm control/42cm drop width, 90mm stem | Sizes ML, L- 39 |
| Frame Material | Carbon |
| Fork Material | Carbon |
| Groupset Brand | Shimano |
| Groupset Model | Ultegra Di2 |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Pedals Included | No |
| Ride Style | Aero Race |
| Bottom Bracket | Praxis, T47 threaded, internal bearing |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Front Derailleur | Shimano Ultegra R8150 Di2, braze-on, down swing |
| Wheel Front | Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12 mm thru axle |
| Battery | Shimano BT-DN300 |
| BRAKE ROTOR | Shimano CL800, CentreLock, 160 mm |
| MAX TYRE SIZE | 32mm (as measured, see manual for details) |
| Rear Derailleur | Shimano Ultegra R8150 Di2, 34T max cog |
| Wheel Rear | Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12 mm thru axle |
| Cassette | Shimano Ultegra R8101, 11-30, 12-speed |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 2 x 12 |
| Shifting Type | Electronic |
| Skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| Fork | Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100 mm chamfered thru axle |
| Skewer front | Bontrager Switch chamfered thru axle |
| Frame with Fork | 900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle |
| Seatpost | Madone aero carbon seat post, 0 mm offset, short length |
| Chain | Shimano Ultegra/XT M8100 |
| Weight | Size ML - 7.52 kg/16.58 lb (with TLR sealant, no tubes, no bottles/cages) |
| Shifter | Shimano Ultegra R8170 Di2 or R8171 Di2, 12-speed (All sizes) |
| CRANK | Shimano Ultegra R8100, 52/36 [Sizes XS, S- 160mm or 165mm length | Sizes M, ML- 165mm, 170mm, or 172.5mm length | Size L- 170mm or 172.5mm length | Size XL- 170mm, 172.5mm, or 175mm length] |
| Max. chainring size | 1x- 54T, 2x- 56/43 |
| Tyre | Bontrager Aeolus RSL RD, Pirelli P Zero Race, or Pirelli P Zero Race TLR RS, 700x28 mm (All sizes) |
| TUBE | Pirelli P Zero SmarTube, TPU |
| Saddle | Bontrager Aeolus Pro or Trek Aeolus Pro, carbon rails, 145 mm width (All sizes) |
| HANDLEBAR TAPE | Trek EcoTack or Trek gel cork (All sizes) |
| Rotor size | Max brake rotor sizes- 180 mm front, 160 mm rear |
| Handlebar/stem (integrated) | Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop [Size XS- 35cm control/38cm drop width, 80mm stem | Size S- 37cm control/40cm drop width, 90mm stem | Size M- 39cm control/42cm drop width, 90mm stem | Sizes ML, L- 39 |
