The Madone SL 6 Gen 8 is a lightweight aero road bike that brings elite racing tech to a lower price point with a more economical OCLV 500 Carbon lay-up than its SLR sibling. A Shimano 105 Di2 electronic groupset gives you lightning-fast electronic shifting and pairs with alloy handlebars to keep the price down. Plus, it's topped off with carbon wheels for extra lightweight performance.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| saddle | Bontrager Aeolus Elite, austenite rails, 145 mm width |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| shifter | Shimano 105 R7170 Di2, 12-speed |
| front derailleur | Shimano 105 R7150 Di2, braze-on, down swing |
| battery | Shimano BT-DN300 |
| cassette | Shimano 105 7101, 11-34, 12-speed |
| max tyre size | 32mm (as measured, see manual for details) |
| chain | Shimano SLX M7100, 12-speed |
| frame | 500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle |
| rear derailleur | Shimano 105 R7150 Di2, 36T max cog |
| brake | Shimano 105 hydraulic disc, flat mount |
| handlebar tape | Trek EcoTack |
| brake rotor | Shimano CL700, CentreLock, 160 mm |
| skewer front | Bontrager Switch chamfered thru axle |
| wheel front | Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 100x12 mm thru axle |
| wheel rear | Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 50 mm rim depth, Shimano 11-speed freehub, 142x12 mm thru axle |
| max. chainring size | 1x- 54T, 2x- 56/43 |
| rotor size | Max brake rotor sizes- 180 mm front, 160 mm rear |
| crank | Shimano 105 R7100, 50/34 [Sizes XS, S- 160mm length | Sizes M, ML- 165 mm length | Sizes L, XL- 170 mm length] |
| fork | Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12x100 mm chamfered thru-axle |
| weight | Size ML – 8.16 kg/17.99 lb (with TLR sealant, no tubes) |
| handlebar | Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop [Size XS- 35 cm control width, 38 cm width | Size S- 37 cm control width, 40 cm width | Sizes M, ML, L- 39 cm control width, 42 cm width | Size XL- 41 cm control width, 44 cm |
| Frame Material | Carbon |
| Fork Material | Carbon |
| Groupset Brand | Shimano |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Pedals Included | No |
| Saddle | Bontrager Aeolus Elite, austenite rails, 145 mm width |
| Ride Style | Aero Race |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Shifter | Shimano 105 R7170 Di2, 12-speed |
| Groupset Model | 105 Di2 |
| Front Derailleur | Shimano 105 R7150 Di2, braze-on, down swing |
| Battery | Shimano BT-DN300 |
| Cassette | Shimano 105 7101, 11-34, 12-speed |
| MAX TYRE SIZE | 32mm (as measured, see manual for details) |
| Chain | Shimano SLX M7100, 12-speed |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 2 x 12 |
| Shifting Type | Electronic |
| FRAME | 500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle |
| Rear Derailleur | Shimano 105 R7150 Di2, 36T max cog |
| BRAKE | Shimano 105 hydraulic disc, flat mount |
| HANDLEBAR TAPE | Trek EcoTack |
| BRAKE ROTOR | Shimano CL700, CentreLock, 160 mm |
| Skewer front | Bontrager Switch chamfered thru axle |
| Wheel Front | Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 100x12 mm thru axle |
| Wheel Rear | Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 50 mm rim depth, Shimano 11-speed freehub, 142x12 mm thru axle |
| Max. chainring size | 1x- 54T, 2x- 56/43 |
| Rotor size | Max brake rotor sizes- 180 mm front, 160 mm rear |
| CRANK | Shimano 105 R7100, 50/34 [Sizes XS, S- 160mm length | Sizes M, ML- 165 mm length | Sizes L, XL- 170 mm length] |
| Fork | Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12x100 mm chamfered thru-axle |
| Weight | Size ML – 8.16 kg/17.99 lb (with TLR sealant, no tubes) |
| Handlebar | Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop [Size XS- 35 cm control width, 38 cm width | Size S- 37 cm control width, 40 cm width | Sizes M, ML, L- 39 cm control width, 42 cm width | Size XL- 41 cm control width, 44 cm |
Ordering a bike from Evo? If you choose the option Evo Home Delivery at the checkout your order will be personally delivered to you, by an Evo Crew Member, who will also be able to answer any questions you have about your new bike. If you choose Evo Delivery your bike will be delivered completely built, tuned and ready to ride! We are also able to offer Evo Home Delivery on previously restricted brands such as Giant & Trek!
Our home delivery charge is only $45 for 15km and $2 per km after that.
Free for all orders over $149. Orders under $149 a $8.99 flat shipping & handling fee applies. Order and pay online and collect everything from one of our showrooms. Just select which store you would like to collect from at checkout. Find out more about Click & Collect here.
LEARN MORE
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
