The Top Fuel 9.8 is a lightweight carbon trail bike built to rip up climbs and stay playful on descents. It gives you the confidence you want through roots and rocks, thanks to a 120 mm/130 mm (rear/front) RockShox suspension package with a Pike Select+ fork and Deluxe Ultimate shock. Plus, you get ultra-smooth and fast shifts from a 12-speed Shimano XT Di2 wireless drivetrain.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| rim strip | Bontrager TLR |
| shock | RockShox Deluxe Ultimate RCT, 185 mm x 50 mm |
| skewer rear | Bontrager Switch thru axle, removable lever |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| bottom bracket | Shimano BB-MT501 BSA |
| max tyre size | Frame - 29x2.50", Fork - See manufacturer |
| max. chainring size | 1x - 34T, min 30T |
| handlebar | Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width |
| saddle | Verse Short Comp, steel rails, 145 mm width |
| stem | Bontrager Line Pro, 35 mm, Blendr-compatible, 0-degree, 35 mm length |
| shifter | Shimano XT Di2 M8250, 12-speed |
| rear derailleur | Shimano XT M8250, long cage |
| crank | Shimano XT 8200, 30T, 55 mm chain-line, 170 mm length |
| cassette | Shimano XT M8200, 10-51, 12-speed |
| grips | Trek Line Elite, lock-on |
| fork | RockShox Pike Select+, DebonAir spring, Charger 3.1 RC2 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 130 mm travel |
| brake rotor | Shimano RT86, 6-bolt, 180 mm |
| weight | M - 14.00 kg / 30.86 lbs (with TLR sealant, no tubes) |
| chain | Shimano Ultegra/XT M8100 |
| wheel front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 27.5" (S) / 29" (M, ML, L, XL) |
| wheel rear | Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano Micro Spline freehub, Boost148, 12 mm thru-axle, 27.5" (S) / 29" (M, ML, L, XL) |
| tyre | Bontrager Gunnison RSL XT, Tubeless-Ready, triple compound, aramid bead, 120 tpi, 27.5x2.40" (S) / 29x2.40" (M, ML, L, XL) |
| seatpost | Bontrager Line Dropper, 100mm travel (S) / 170 mm travel (M, ML) / 200 mm travel (L, XL), MaxFlow, internal routing, 34.9 mm |
| brake | Shimano XT M8220 4-piston hydraulic disc |
| rotor size | Max brake rotor sizes – Frame - 200 mm, min 180 mm |
| Groupset Brand | Shimano |
| Fork Brand | Rockshox |
| Groupset Model | XT |
| Frame Material | Carbon & Alloy |
| Fork Travel | 121 - 140mm |
| Shock Travel | 101 - 120mm |
| Pedals Included | No |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| Ride Style | Trail |
| Rim strip | Bontrager TLR |
| Fork Material | Suspension |
| Shock | RockShox Deluxe Ultimate RCT, 185 mm x 50 mm |
| Skewer rear | Bontrager Switch thru axle, removable lever |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Bottom Bracket | Shimano BB-MT501 BSA |
| MAX TYRE SIZE | Frame - 29x2.50", Fork - See manufacturer |
| Max. chainring size | 1x - 34T, min 30T |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 12 |
| Shifting Type | Electronic |
| Handlebar | Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width |
| Saddle | Verse Short Comp, steel rails, 145 mm width |
| Stem | Bontrager Line Pro, 35 mm, Blendr-compatible, 0-degree, 35 mm length |
| Shifter | Shimano XT Di2 M8250, 12-speed |
| Rear Derailleur | Shimano XT M8250, long cage |
| CRANK | Shimano XT 8200, 30T, 55 mm chain-line, 170 mm length |
| Cassette | Shimano XT M8200, 10-51, 12-speed |
| GRIPS | Trek Line Elite, lock-on |
| Fork | RockShox Pike Select+, DebonAir spring, Charger 3.1 RC2 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 130 mm travel |
| BRAKE ROTOR | Shimano RT86, 6-bolt, 180 mm |
| Weight | M - 14.00 kg / 30.86 lbs (with TLR sealant, no tubes) |
| Chain | Shimano Ultegra/XT M8100 |
| Wheel Front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 27.5" (S) / 29" (M, ML, L, XL) |
| Wheel Rear | Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano Micro Spline freehub, Boost148, 12 mm thru-axle, 27.5" (S) / 29" (M, ML, L, XL) |
| Tyre | Bontrager Gunnison RSL XT, Tubeless-Ready, triple compound, aramid bead, 120 tpi, 27.5x2.40" (S) / 29x2.40" (M, ML, L, XL) |
| Seatpost | Bontrager Line Dropper, 100mm travel (S) / 170 mm travel (M, ML) / 200 mm travel (L, XL), MaxFlow, internal routing, 34.9 mm |
| BRAKE | Shimano XT M8220 4-piston hydraulic disc |
| Rotor size | Max brake rotor sizes – Frame - 200 mm, min 180 mm |
