The Fuel EX 8 is a confident and versatile trail bike built to get after it. It comes ready to rip with an Alpha NEXT Platinum frame, Fox performance suspension package with 145 mm/150 mm travel (rear, front), alloy Bontrager Line wheels and a SRAM Eagle 70 transmission that keeps shifts smooth, even under load. It's topped off with 4-piston SRAM DB 8 hydraulic disc brakes to keep you stopping on a penny.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| rim strip | Bontrager TLR |
| stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| bottom bracket | SRAM DUB MTB Wide, 73 m, BSA threaded |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| max tyre size | Frame - 29x2.50", Fork - See manufacturer |
| brake | SRAM DB 8 4-piston hydraulic disc |
| saddle | Bontrager Verse P3, chromoly rails |
| grips | Trek Line Comp, nylon lock-on |
| rotor size | Max brake rotor sizes – Frame - 203 mm, min 180 mm, Fork - see fork manufacturer |
| weight | M - 16.89 kg / 37.24 lbs (with TLR sealant, no tubes) |
| max. chainring size | Max - 34T (oval – 32T) Min - 30T (oval – 32T) |
| shifter | SRAM Eagle 70, 12-speed |
| rear derailleur | SRAM Eagle 70, T-Type |
| crank | SRAM Eagle 70, DUB, 30T steel, T-Type, 55 mm chainline, 170 mm length |
| cassette | SRAM Eagle XS-1270, T-Type,10-52, 12-speed |
| chain | SRAM Eagle 70, T-Type, 12-speed |
| handlebar | Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width |
| frame | Alpha NEXT Platinum aluminum, internal storage, ZS headset, adjustable leverage rate, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145mm-160mm |
| fork | Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt X axle, 150mm travel |
| rear shock | Fox Performance Float X, 2-position damper, 205mm x 60mm |
| tyres | Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.50" (S) / 29x2.50" (M, L, XL) |
| seatpost | Bontrager Line Dropper, 150mm travel (S) / 170 mm travel (M) / 200 mm travel (L, XL), MaxFlow, internal routing, 34.9 mm, 410 mm length |
| head set | FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown |
| brake rotor | SRAM CenterLine 2.0, 6-bolt, 200mm / 180mm |
| Frame Material | Alloy |
| Groupset Brand | Sram |
| Fork Brand | Fox |
| Fork Travel | 141 - 170mm |
| Shock Travel | 141 - 170mm |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| Ride Style | Trail |
| Rim strip | Bontrager TLR |
| Stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| Fork Material | Suspension |
| Bottom Bracket | SRAM DUB MTB Wide, 73 m, BSA threaded |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| MAX TYRE SIZE | Frame - 29x2.50", Fork - See manufacturer |
| BRAKE | SRAM DB 8 4-piston hydraulic disc |
| Saddle | Bontrager Verse P3, chromoly rails |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 12 |
| Groupset Model | Eagle 70 T-Type |
| GRIPS | Trek Line Comp, nylon lock-on |
| Rotor size | Max brake rotor sizes – Frame - 203 mm, min 180 mm, Fork - see fork manufacturer |
| Weight | M - 16.89 kg / 37.24 lbs (with TLR sealant, no tubes) |
| Max. chainring size | Max - 34T (oval – 32T) Min - 30T (oval – 32T) |
| Shifter | SRAM Eagle 70, 12-speed |
| Rear Derailleur | SRAM Eagle 70, T-Type |
| CRANK | SRAM Eagle 70, DUB, 30T steel, T-Type, 55 mm chainline, 170 mm length |
| Cassette | SRAM Eagle XS-1270, T-Type,10-52, 12-speed |
| Chain | SRAM Eagle 70, T-Type, 12-speed |
| Handlebar | Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width |
| FRAME | Alpha NEXT Platinum aluminum, internal storage, ZS headset, adjustable leverage rate, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145mm-160mm |
| Fork | Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt X axle, 150mm travel |
| REAR SHOCK | Fox Performance Float X, 2-position damper, 205mm x 60mm |
| TYRES | Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.50" (S) / 29x2.50" (M, L, XL) |
| Seatpost | Bontrager Line Dropper, 150mm travel (S) / 170 mm travel (M) / 200 mm travel (L, XL), MaxFlow, internal routing, 34.9 mm, 410 mm length |
| Head Set | FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown |
| BRAKE ROTOR | SRAM CenterLine 2.0, 6-bolt, 200mm / 180mm |
Ordering a bike from Evo? If you choose the option Evo Home Delivery at the checkout your order will be personally delivered to you, by an Evo Crew Member, who will also be able to answer any questions you have about your new bike. If you choose Evo Delivery your bike will be delivered completely built, tuned and ready to ride! We are also able to offer Evo Home Delivery on previously restricted brands such as Giant & Trek!
Our home delivery charge is only $45 for 15km and $2 per km after that.
Free for all orders over $149. Orders under $149 a $8.99 flat shipping & handling fee applies. Order and pay online and collect everything from one of our showrooms. Just select which store you would like to collect from at checkout. Find out more about Click & Collect here.
LEARN MORE
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
