Exhilarating performance
Dressed to impress and packing a serious performance punch, Karve EVO RS is our most affordable, unstoppable, maximum control gravity thrill machine for self-shuttled riding, bike park play, and big mountain terrain. Engineered with the confidence, capability and control to enable you to master the toughest tracks, the power to shuttle effortlessly, and the range to drop in again, and again, and again... If the biggest terrain is your playground, Karve EVO RS is your access all areas pass.
Highlights
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| stem | Whyte, 35mm Extension, 35mm Bar Bore |
| grips | Whyte Enduro lock-on |
| pedals | Fibre reinforced composite platform |
| cassette | SRAM XS 1270, T-Type, 10-52T, 12 speed |
| chain | SRAM Eagle 70, 12 speed |
| seat | Whyte Custom |
| charger | Charger 4A (230V) |
| battery | Avinox 800Wh fixed battery, mounted into the frame by 2x bolts. Removeable for maintenance by removing motor. |
| display | Avinox DPC100 OLED display mounted within the top tube, paired with the discrete bar mounted wireless controller. Also connects to the Avinox Ride smartphone app to give you even more insight and control at your fingertips. |
| seatpost | TranzX +RAD adjustable dropper post, 34.9mm, frame size specific drop (size S 150mm drop - size M 170mm drop - sizes L-XL 200mm drop) |
| rear tyre | Maxxis Minion DHR 2 WT, TR, 27.5 x 2.5in 120TPI, Double Down casing, 3C MaxxTerra, Dual Compound |
| crankset | Whyte 155mm long ISIS crank arms, SRAM direct mount, 36T chainring, T-Type |
| drive unit | Avinox M2S drive unit with 150Nm maximum torque, 1300W of peak power and 250W of nominal power. Features five power mode settings including Auto and Boost. |
| frame | Uni-directional carbon mainframe, ZS56 top and bottom head tube, internal cable routing, 6061 alloy swing arm, Shape.it Link V2 and 12mm x 148mm Boost dropouts |
| fork | RockShox ZEB Select, 180mm travel, 44mm offset, Linear XL, Delta RC damper, Fast Black coating, tapered steerer, 110mm x 15mm Boost, Maxle stealth |
| rear shock | RockShox Super Deluxe Select RT, DebonAir, Fast Black coating, adjustable rebound, 230 x 62.5mm, custom tuned for Whyte |
| headset | ZS56 upper / lower headset cups for 1 1/18in upper and 1.5in lower with sealed bearings |
| rear hub | Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, nine degree micro engagement four pawl, 32 hole, HG freehub |
| front hub | Alloy, double sealed cartridge bearings, 12mm x 100mm thru axle, 32 hole |
| spokes | 14g stainless black, brass nipples |
| rims | Whyte eMTB sleeved rims, 30mm internal width, tubeless ready, 29in front, 27.5in rear |
| front tyres | Maxxis Assegai WT, TR, 29 x 2.5in 120TPI, EXO+ Sidewall Protection, 3C MaxxGrip, Dual Compound, folding bead |
| shift levers | SRAM Eagle 90, 12 speed |
| rear mech | SRAM Eagle 70 T-Type mechanical, 12 speed |
| bar | Whyte Custom 7050 alloy, 40mm rise, 35mm bar bore, 800mm wide |
| brakes front | SRAM Maven Base hydraulic disc brake, four piston, sintered metal pads, 220mm six bolt Centreline rotors |
| brakes rear | SRAM Maven Base hydraulic disc brake, four piston, sintered metal pads, 200mm six bolt Centreline rotors |
| brake levers | SRAM Maven Base |
| Groupset Brand | Sram |
| Fork Brand | Rockshox |
| Frame Material | Carbon & Alloy |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Max Assisted Speed | 32km/h |
| Ride Style | Enduro |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 12 |
| Motor Type | Mid-Drive Motor |
| Groupset Model | Eagle 70 T-Type |
| Frame Style | Step-Over |
| Motor Brand | DJI Avinox |
| Battery Brand | DJI Avinox |
| Stem | Whyte, 35mm Extension, 35mm Bar Bore |
| GRIPS | Whyte Enduro lock-on |
| PEDALS | Fibre reinforced composite platform |
| Cassette | SRAM XS 1270, T-Type, 10-52T, 12 speed |
| Chain | SRAM Eagle 70, 12 speed |
| SEAT | Whyte Custom |
| Charger | Charger 4A (230V) |
| Battery | Avinox 800Wh fixed battery, mounted into the frame by 2x bolts. Removeable for maintenance by removing motor. |
| Display | Avinox DPC100 OLED display mounted within the top tube, paired with the discrete bar mounted wireless controller. Also connects to the Avinox Ride smartphone app to give you even more insight and control at your fingertips. |
| Seatpost | TranzX +RAD adjustable dropper post, 34.9mm, frame size specific drop (size S 150mm drop - size M 170mm drop - sizes L-XL 200mm drop) |
| REAR TYRE | Maxxis Minion DHR 2 WT, TR, 27.5 x 2.5in 120TPI, Double Down casing, 3C MaxxTerra, Dual Compound |
| Crankset | Whyte 155mm long ISIS crank arms, SRAM direct mount, 36T chainring, T-Type |
| DRIVE UNIT | Avinox M2S drive unit with 150Nm maximum torque, 1300W of peak power and 250W of nominal power. Features five power mode settings including Auto and Boost. |
| FRAME | Uni-directional carbon mainframe, ZS56 top and bottom head tube, internal cable routing, 6061 alloy swing arm, Shape.it Link V2 and 12mm x 148mm Boost dropouts |
| Fork | RockShox ZEB Select, 180mm travel, 44mm offset, Linear XL, Delta RC damper, Fast Black coating, tapered steerer, 110mm x 15mm Boost, Maxle stealth |
| REAR SHOCK | RockShox Super Deluxe Select RT, DebonAir, Fast Black coating, adjustable rebound, 230 x 62.5mm, custom tuned for Whyte |
| Headset | ZS56 upper / lower headset cups for 1 1/18in upper and 1.5in lower with sealed bearings |
| REAR HUB | Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, nine degree micro engagement four pawl, 32 hole, HG freehub |
| FRONT HUB | Alloy, double sealed cartridge bearings, 12mm x 100mm thru axle, 32 hole |
| SPOKES | 14g stainless black, brass nipples |
| RIMS | Whyte eMTB sleeved rims, 30mm internal width, tubeless ready, 29in front, 27.5in rear |
| Front tyres | Maxxis Assegai WT, TR, 29 x 2.5in 120TPI, EXO+ Sidewall Protection, 3C MaxxGrip, Dual Compound, folding bead |
| SHIFT LEVERS | SRAM Eagle 90, 12 speed |
| Rear Mech | SRAM Eagle 70 T-Type mechanical, 12 speed |
| BAR | Whyte Custom 7050 alloy, 40mm rise, 35mm bar bore, 800mm wide |
| Brakes Front | SRAM Maven Base hydraulic disc brake, four piston, sintered metal pads, 220mm six bolt Centreline rotors |
| Brakes Rear | SRAM Maven Base hydraulic disc brake, four piston, sintered metal pads, 200mm six bolt Centreline rotors |
| Brake Levers | SRAM Maven Base |
Ordering a bike from Evo? If you choose the option Evo Home Delivery at the checkout your order will be personally delivered to you, by an Evo Crew Member, who will also be able to answer any questions you have about your new bike. If you choose Evo Delivery your bike will be delivered completely built, tuned and ready to ride! We are also able to offer Evo Home Delivery on previously restricted brands such as Giant & Trek!
Our home delivery charge is only $45 for 15km and $2 per km after that.
Free for all orders over $149. Orders under $149 a $8.99 flat shipping & handling fee applies. Order and pay online and collect everything from one of our showrooms. Just select which store you would like to collect from at checkout. Find out more about Click & Collect here.
LEARN MORE
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
