The ultimate thrill ride
For the toughest tracks. The supreme self-shuttle machine. With the power of Avinox inside. Karve EVO is the chaos-crushing, climb-shrinking electric mountain bike (eMTB) for self-shuttled riding and big mountain terrain. If having the best time dropping in on the biggest terrain is why you ride, Karve EVO RSX is ready.
Highlights
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| brake levers | SRAM Maven Silver |
| stem | Whyte, 35mm Extension, 35mm Bar Bore |
| grips | Whyte Enduro lock-on |
| pedals | Fibre reinforced composite platform |
| seat | Whyte Custom |
| shift levers | SRAM AXS Pod, right, MMX, 12 speed |
| chain | SRAM GX T-Type, 12 speed |
| cassette | SRAM XS 1275, T-Type, 10-52T, 12 speed |
| spokes | DT Swiss elemental |
| drive unit | Avinox M2S drive unit with 150Nm maximum torque, 1300W of peak power and 250W of nominal power. Features five power mode settings including Auto and Boost. AXS derailleur powered off motor and featuring SmoothShift. |
| battery | Avinox 800Wh fixed battery, mounted into the frame by 2x bolts. Removeable for maintenance by removing motor. |
| display | Avinox DPC100 OLED display mounted within the top tube, paired with the discrete bar mounted wireless controller. Also connects to the Avinox Ride smartphone app to give you even more insight and control at your fingertips. |
| seatpost | TranzX +RAD adjustable dropper post, 34.9mm, frame size specific drop (size S 150mm drop - size M 170mm drop - sizes L-XL 200mm drop) |
| front tyre | Maxxis Assegai WT, TR, 29 x 2.5in 120TPI, EXO+ Sidewall Protection, 3C MaxxGrip, Dual Compound, folding bead |
| rear tyre | Maxxis Minion DHR 2 WT, TR, 27.5 x 2.5in 120TPI, Double Down casing, 3C MaxxTerra, Dual Compound |
| brakes rear | SRAM Maven Silver hydraulic disc brake, four piston, sintered metal pads, 200mm six bolt HS2 rotors |
| crankset | Whyte 155mm long ISIS crank arms, SRAM direct mount, 36T chainring, T-Type |
| charger | Charger 12A (230V) |
| Groupset Brand | Sram |
| Fork Brand | Rockshox |
| Frame Material | Carbon & Alloy |
| Pedals Included | No |
| Max Assisted Speed | 32km/h |
| Ride Style | Enduro |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 12 |
| Shifting Type | Electronic |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| Brake Levers | SRAM Maven Silver |
| Motor Brand | DJI Avinox |
| Battery Brand | DJI Avinox |
| Stem | Whyte, 35mm Extension, 35mm Bar Bore |
| GRIPS | Whyte Enduro lock-on |
| PEDALS | Fibre reinforced composite platform |
| SEAT | Whyte Custom |
| SHIFT LEVERS | SRAM AXS Pod, right, MMX, 12 speed |
| Chain | SRAM GX T-Type, 12 speed |
| Cassette | SRAM XS 1275, T-Type, 10-52T, 12 speed |
| Groupset Model | Eagle S1000 T-Type AXS |
| SPOKES | DT Swiss elemental |
| DRIVE UNIT | Avinox M2S drive unit with 150Nm maximum torque, 1300W of peak power and 250W of nominal power. Features five power mode settings including Auto and Boost. AXS derailleur powered off motor and featuring SmoothShift. |
| Battery | Avinox 800Wh fixed battery, mounted into the frame by 2x bolts. Removeable for maintenance by removing motor. |
| Display | Avinox DPC100 OLED display mounted within the top tube, paired with the discrete bar mounted wireless controller. Also connects to the Avinox Ride smartphone app to give you even more insight and control at your fingertips. |
| Seatpost | TranzX +RAD adjustable dropper post, 34.9mm, frame size specific drop (size S 150mm drop - size M 170mm drop - sizes L-XL 200mm drop) |
| FRONT TYRE | Maxxis Assegai WT, TR, 29 x 2.5in 120TPI, EXO+ Sidewall Protection, 3C MaxxGrip, Dual Compound, folding bead |
| REAR TYRE | Maxxis Minion DHR 2 WT, TR, 27.5 x 2.5in 120TPI, Double Down casing, 3C MaxxTerra, Dual Compound |
| Brakes Rear | SRAM Maven Silver hydraulic disc brake, four piston, sintered metal pads, 200mm six bolt HS2 rotors |
| Crankset | Whyte 155mm long ISIS crank arms, SRAM direct mount, 36T chainring, T-Type |
| Charger | Charger 12A (230V) |
