Ride beyond expectations
Our mid-range Kado RS is a capable and confidence-inspiring full-power, full-torque eMTB that will help you realise your riding dreams.
With an empowering ride; confidence-inspiring handling; the range to go for miles and miles; Bosch’s refined and reliable motor; an easy to remove 800Wh internal battery; our game-changing low centre of gravity design; meticulously tuned suspension for perfect control; specially curated parts, and more, Kado RS is ready to help you ride beyond your expectations – everywhere.
Highlights
Rides like a dream
We’ve poured everything into Kado RS to give you the best handling and ride performance possible: an optimised low centre of gravity to give you exceptional cornering agility and balanced handling on any terrain; custom-tuned suspension for the very best grip, feedback and control; confidence-inspiring geometry, and much more. All masterfully combined to help you realise your riding dreams.
Charge time: 50% in 2.3hrs from empty, and to 100% in 6.9hrs with 4A Charger.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| weight | 25.4Kg (size M, without pedals, with innertubes) |
| cassette | SRAM XS 1270, T-Type, 10-52T, 12 speed |
| chain | SRAM Eagle 70, 12 speed |
| crankset | Whyte 155mm long ISIS crank arms, SRAM direct mount 36T chainring, T-Type |
| bottom bracket | N/A |
| seatpost | TranzX +RAD adjustable dropper post, 34.9mm, frame size specific drop (size S 150mm drop; size M 170mm drop; sizes L-XL 200mm drop) |
| seat | Whyte Custom |
| bar | Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide |
| stem | Whyte, 35mm Extension, 35mm Bar Bore |
| brakes front | SRAM DB8 Stealth, four piston hydraulic disc brake, organic pads, 220mm six bolt Centreline rotor |
| brakes rear | SRAM DB8 Stealth, four piston hydraulic disc brake, organic pads, 200mm six bolt Centreline rotor |
| brake levers | SRAM DB8 Stealth |
| pedals | Fibre reinforced composite platform |
| drive unit | Bosch Performance Line CX (Smart System) drive unit with 100Nm maximum torque, 750W of peak power and 250W of nominal power. Features four power mode settings including Tour+ and eMTB+. |
| battery | Bosch PowerTube 800Wh, perfectly integrated into the frame with an intuitive lockable mechanism for easy removal. Bosch PowerMore 250Wh range extender compatible. |
| display | Bosch System controller mounted within the top tube, paired with the discrete bar mounted Mini Remote. Also connects to the Bosch eBike Flow smartphone app to give you even more insight and control at your fingertips. |
| charger | Charger 4A (230V) |
| Weight | 25.4Kg (size M, without pedals, with innertubes) |
| Cassette | SRAM XS 1270, T-Type, 10-52T, 12 speed |
| Chain | SRAM Eagle 70, 12 speed |
| Crankset | Whyte 155mm long ISIS crank arms, SRAM direct mount 36T chainring, T-Type |
| Bottom Bracket | N/A |
| Seatpost | TranzX +RAD adjustable dropper post, 34.9mm, frame size specific drop (size S 150mm drop; size M 170mm drop; sizes L-XL 200mm drop) |
| SEAT | Whyte Custom |
| BAR | Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide |
| Stem | Whyte, 35mm Extension, 35mm Bar Bore |
| Brakes Front | SRAM DB8 Stealth, four piston hydraulic disc brake, organic pads, 220mm six bolt Centreline rotor |
| Brakes Rear | SRAM DB8 Stealth, four piston hydraulic disc brake, organic pads, 200mm six bolt Centreline rotor |
| Brake Levers | SRAM DB8 Stealth |
| PEDALS | Fibre reinforced composite platform |
| DRIVE UNIT | Bosch Performance Line CX (Smart System) drive unit with 100Nm maximum torque, 750W of peak power and 250W of nominal power. Features four power mode settings including Tour+ and eMTB+. |
| Battery | Bosch PowerTube 800Wh, perfectly integrated into the frame with an intuitive lockable mechanism for easy removal. Bosch PowerMore 250Wh range extender compatible. |
| Display | Bosch System controller mounted within the top tube, paired with the discrete bar mounted Mini Remote. Also connects to the Bosch eBike Flow smartphone app to give you even more insight and control at your fingertips. |
| Charger | Charger 4A (230V) |
| Frame Material | Carbon & Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Groupset Model | Eagle 70 T-Type |
| Fork Brand | Rockshox |
| Motor Brand | Bosch |
| Max Assisted Speed | 32km/h |
| Battery Brand | Bosch |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 11 |
| Ride Style | Enduro |
Ordering a bike from Evo? If you choose the option Evo Home Delivery at the checkout your order will be personally delivered to you, by an Evo Crew Member, who will also be able to answer any questions you have about your new bike. If you choose Evo Delivery your bike will be delivered completely built, tuned and ready to ride! We are also able to offer Evo Home Delivery on previously restricted brands such as Giant & Trek!
Our home delivery charge is only $45 for 15km and $2 per km after that.
Free for all orders over $149. Orders under $149 a $8.99 flat shipping & handling fee applies. Order and pay online and collect everything from one of our showrooms. Just select which store you would like to collect from at checkout. Find out more about Click & Collect here.
LEARN MORE
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
