Whyte’s most affordable ELyte 150 trail bike. Fast, light and powerful, the ELyte 150 RS is equipped with Bosch’s SX motor and blends the very best natural mountain bike handling and ride feel with the power and capability of full-power electric mountain bikes. All wrapped up in an even better value package for trail riders who want support - not a whole new sport.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| e-bike motor | Bosch Performance Line SX drive unit, 55Nm maximum torque and 600W of peak power. Features four power settings including Tour+, that allows you to focus on riding whilst being economic on power usage, and eMTB mode which automatically adjusts the power as |
| e-bike display | Bosch System controller mounted within the top tube, paired with the discrete bar mounted Mini Remote. Also connects to the Bosch e-Bike Flow smartphone app to give you even more insight and control at your fingertips. |
| e-bike battery | Bosch Compact PowerTube 400Wh, integrated within the downtube of the frame at the lowest point for stability and control. |
| colour | Gloss deep purple with black |
| frame | Uni-directional carbon mainframe and seatstays, tapered head tube, ISCG 2 guide mounts, internal cable routing, Shape.it Link V2 and 12mm x 148mm Boost dropouts |
| cassette | SRAM XS 1270, T-Type, 10-52T, 12 speed |
| rear shock | RockShox Deluxe Select + RT, DebonAir, Fast Black coating, adjustable rebound and two position compression adjustment, custom tuned for Whyte |
| headset | FSA No. 69/56/SRS, 1-1/8in upper and 1.5in lower with sealed angular contact bearing (ACB) cartridge bearings, with side entry internal routing |
| rear hub | Alloy, light assist e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, 32 hole |
| front hub | Alloy, double sealed cartridge bearings, 15mm x 110mm Boost spacing, 28 hole |
| spokes | DT Swiss elemental |
| rims | WTB ST Tough, 30mm internal |
| bar | Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide |
| shift levers | SRAM AXS Pod, right, MMX, 12 speed |
| front derailleur | N/A |
| rear derailleur | SRAM S1000 T-Type AXS, 12 speed |
| chain | SRAM GX T-Type, 12 speed |
| crankset | Whyte 155mm ISIS arms, 36T chainring, T-Type |
| bottom bracket | N/A |
| seatpost | TranzX +RAD 30.9mm, Adjustable, (150 drop (S), 170mm drop (M), 200mm drop (L&XL)) |
| seat | Whyte Custom |
| stem | Whyte Trail full CNC, 32mm extension, 35mm bar bore |
| grips | Whyte Enduro lock-on |
| front brakes | SRAM Code Bronze Stealth, four piston hydraulic, 200mm diameter disc rotor |
| rear brakes | SRAM Code Bronze Stealth, four piston hydraulic, 200mm diameter disc rotor |
| brake levers | SRAM Code Bronze Stealth |
| Frame Material | Carbon |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Fork Brand | Rockshox |
| Motor Brand | Bosch |
| Max Assisted Speed | 32km/h |
| Battery Brand | Bosch |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| Shifting Type | Electronic |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Trail |
| E-bike motor | Bosch Performance Line SX drive unit, 55Nm maximum torque and 600W of peak power. Features four power settings including Tour+, that allows you to focus on riding whilst being economic on power usage, and eMTB mode which automatically adjusts the power as |
| E-bike display | Bosch System controller mounted within the top tube, paired with the discrete bar mounted Mini Remote. Also connects to the Bosch e-Bike Flow smartphone app to give you even more insight and control at your fingertips. |
| E-bike battery | Bosch Compact PowerTube 400Wh, integrated within the downtube of the frame at the lowest point for stability and control. |
| COLOUR | Gloss deep purple with black |
| FRAME | Uni-directional carbon mainframe and seatstays, tapered head tube, ISCG 2 guide mounts, internal cable routing, Shape.it Link V2 and 12mm x 148mm Boost dropouts |
| Cassette | SRAM XS 1270, T-Type, 10-52T, 12 speed |
| REAR SHOCK | RockShox Deluxe Select + RT, DebonAir, Fast Black coating, adjustable rebound and two position compression adjustment, custom tuned for Whyte |
| Headset | FSA No. 69/56/SRS, 1-1/8in upper and 1.5in lower with sealed angular contact bearing (ACB) cartridge bearings, with side entry internal routing |
| REAR HUB | Alloy, light assist e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, 32 hole |
| FRONT HUB | Alloy, double sealed cartridge bearings, 15mm x 110mm Boost spacing, 28 hole |
| SPOKES | DT Swiss elemental |
| RIMS | WTB ST Tough, 30mm internal |
| BAR | Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide |
| SHIFT LEVERS | SRAM AXS Pod, right, MMX, 12 speed |
| Front Derailleur | N/A |
| Rear Derailleur | SRAM S1000 T-Type AXS, 12 speed |
| Chain | SRAM GX T-Type, 12 speed |
| Crankset | Whyte 155mm ISIS arms, 36T chainring, T-Type |
| Bottom Bracket | N/A |
| Seatpost | TranzX +RAD 30.9mm, Adjustable, (150 drop (S), 170mm drop (M), 200mm drop (L&XL)) |
| SEAT | Whyte Custom |
| Stem | Whyte Trail full CNC, 32mm extension, 35mm bar bore |
| GRIPS | Whyte Enduro lock-on |
| Front Brakes | SRAM Code Bronze Stealth, four piston hydraulic, 200mm diameter disc rotor |
| Rear Brakes | SRAM Code Bronze Stealth, four piston hydraulic, 200mm diameter disc rotor |
| Brake Levers | SRAM Code Bronze Stealth |
| Groupset Model | Eagle S1000 T-Type AXS |
