Designed to help riders explore farther and progress with confidence, the Embolden E+ pairs full-suspension control with smooth, intuitive electric support. From forest roads to real mountain singletrack, it makes new terrain feel welcoming and longer rides feel achievable—with less stress and more fun.
The E+ System is a fusion of advanced technology and purposeful design, integrated in perfect harmony for your choices, your goals, your ride. Whether you want to climb higher, go farther, or enjoy the trail ahead, these user-friendly components and technologies—including motors, control units, battery packs and more—seamlessly blend electric power with human power to deliver a smart, natural, powerful and secure ride experience.
CONFIDENT TRAIL CAPABILITY
With 150mm of front travel and 140mm at the rear, the suspension system is designed and tuned specifically for the Embolden E+ to deliver stability, traction, and predictable handling when trails get rough. The lightweight ALUXX SL-grade aluminum frame helps keep the bike manageable on climbs and more intuitive on singletrack, while the new FlexPoint Suspension design keeps the rear wheel active and controlled over uneven surfaces—helping the bike stay composed and easier to manage as trails get more technical.
POWER YOU CAN RELY ON
The SyncDrive Pro 3X motor delivers up to 100Nm with a smooth, natural response that closely follows rider input—making steep climbs and long days feel more manageable. Paired with Smart Assist and high-capacity EnergyPak Smart batteries, the system supports a trail range of approximately 50–120 km depending on terrain, elevation, and support mode, with the option to add an EnergyPak Plus range extender for longer adventures. This gives riders the practical freedom to explore new areas, ride longer loops, and confidently plan full trail days without range anxiety.
SMART INTEGRATION, BUILT TO LAST
Every part of the E+ System is developed to work together—from motor to battery to software—supporting durability, serviceability, and long-term value. Through the RideControl Dash 2 and RideControl app, riders can personalize how the bike responds and which ride data they see, making it easy to fine-tune support modes and power delivery to match terrain, fitness, and riding style. The system is fully supported through Liv retailers with diagnostics and firmware updates, while the in-house developed, industry leading battery chemistry delivers up to 2300 charge cycles, improving resale value and reducing waste. Integrated technologies, including Aegis tire pressure monitoring, e-locking and Apple Find My, add everyday security on and off the trail.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| spokes | Stainless Steel |
| sizes | XS, S, M, L |
| stem | Giant Contact SL 35 |
| lock | Torx 25 Battery Lock with built-in Torque limiter |
| extras | Tubeless kit (liquid, valves, levers, manual, tool) |
| controller | Giant RideControl Dash 2, Smart Assist automatic mode, 5 support levels |
| display | Giant RideControl Dash 2, full color LCD display |
| battery | Giant EnergyPak 800Wh |
| charger | Giant EnergyPak 4A smart charger |
| frame | ALUXX SL-grade aluminum, 140mm travel FlexPoint linkage driven suspension system, 148x12 Boost rear axle, UDHTM Universal Derailleur hanger, KSA40 compatible, 185x52.5mm shock, 1.5~1.8" headset (ZS62/ZS72) |
| fork | Giant STL 36 Air, 150mm travel, 5-position compression adjust, tapered steerer, 72mm crown, e-bike optimized, 110x15mm Boost axle, full fender compatible |
| pedals | Large platform pedal, 28-pins, PP cage, Steel axle |
| shifters | Shimano Cues LinkGlide |
| rear derailleur | Shimano Cues LinkGlide, 10-speed, Shadow+ |
| brake levers | Shimano Deore, BL-M401 |
| cassette | Shimano Cues LinkGlide, 10-speed, 11-48T |
| chain | Shimano LinkGlide |
| fender/chainguard | MRP 1x HD guide, CS e-Mount, 32~38T Adjustable |
| motor | Giant SyncDrive Pro 3X 100Nm, PedalPlus 6-Sensor technology |
| handlebar | Giant Connect TR35, 20mm rise, 35x750mm [XS, S], 35X780mm [M, L] |
| seatpost | Giant Contact Switch AT travel adjust dropper seatpost (XS, S - 110-140mm, M -140-170mm, L - 170-200mm) |
| saddle | Liv Contact Ergo Trail |
| crankset | Direct-mount steel 36T (maximum - 38T), Forged aluminum crank arms |
| tires | Maxxis Minion DHF 27x2.5" (XS), 29x2.50" (S, M, L) foldable, TLR EXO [F}, Maxxis Dissector 27.5x2.4" (XS), 29x2.40" (S, M, L) foldable WT, TLR, EXO [R] |
| colors | Pale Moss |
| shock | Giant Crest FloTrac, 3-position lever, e-bike optimized, 185x52.5mm, Sag recommendation - 30% (15.75mm) |
| grips | Liv Tactal Pro Single Lock-On Grips |
| brakes | Shimano Deore, BR-M420, hydraulic disc, 4-piston, 220mm [F], 203mm [R] |
| rims | Giant AM 27.5" (XS), 29"(S, M, L), Tubeless ready, 30mm inner width |
| hubs | Shimano TC500 Boost, center-lock, 15x110mm [F], 12x148mm [R] |
| SPOKES | Stainless Steel |
| SIZES | XS, S, M, L |
| Groupset Brand | Shimano |
| Frame Material | Alloy |
| Groupset Model | Deore |
| Motor Brand | Giant |
| Shifting Type | Mechanical |
| Battery Brand | Giant |
| Pedals Included | Yes |
| Stem | Giant Contact SL 35 |
| Max Assisted Speed | 32km/h |
| Ride Style | Trail |
| Fork Brand | Giant |
| Lock | Torx 25 Battery Lock with built-in Torque limiter |
| Fork Material | Suspension |
| EXTRAS | Tubeless kit (liquid, valves, levers, manual, tool) |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 10 |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| CONTROLLER | Giant RideControl Dash 2, Smart Assist automatic mode, 5 support levels |
| Display | Giant RideControl Dash 2, full color LCD display |
| Battery | Giant EnergyPak 800Wh |
| Charger | Giant EnergyPak 4A smart charger |
| FRAME | ALUXX SL-grade aluminum, 140mm travel FlexPoint linkage driven suspension system, 148x12 Boost rear axle, UDHTM Universal Derailleur hanger, KSA40 compatible, 185x52.5mm shock, 1.5~1.8" headset (ZS62/ZS72) |
| Fork | Giant STL 36 Air, 150mm travel, 5-position compression adjust, tapered steerer, 72mm crown, e-bike optimized, 110x15mm Boost axle, full fender compatible |
| PEDALS | Large platform pedal, 28-pins, PP cage, Steel axle |
| Shifters | Shimano Cues LinkGlide |
| Rear Derailleur | Shimano Cues LinkGlide, 10-speed, Shadow+ |
| Brake Levers | Shimano Deore, BL-M401 |
| Cassette | Shimano Cues LinkGlide, 10-speed, 11-48T |
| Chain | Shimano LinkGlide |
| Fender/Chainguard | MRP 1x HD guide, CS e-Mount, 32~38T Adjustable |
| Motor | Giant SyncDrive Pro 3X 100Nm, PedalPlus 6-Sensor technology |
| Handlebar | Giant Connect TR35, 20mm rise, 35x750mm [XS, S], 35X780mm [M, L] |
| Seatpost | Giant Contact Switch AT travel adjust dropper seatpost (XS, S - 110-140mm, M -140-170mm, L - 170-200mm) |
| Saddle | Liv Contact Ergo Trail |
| Crankset | Direct-mount steel 36T (maximum - 38T), Forged aluminum crank arms |
| Tires | Maxxis Minion DHF 27x2.5" (XS), 29x2.50" (S, M, L) foldable, TLR EXO [F}, Maxxis Dissector 27.5x2.4" (XS), 29x2.40" (S, M, L) foldable WT, TLR, EXO [R] |
| COLORS | Pale Moss |
| Shock | Giant Crest FloTrac, 3-position lever, e-bike optimized, 185x52.5mm, Sag recommendation - 30% (15.75mm) |
| GRIPS | Liv Tactal Pro Single Lock-On Grips |
| BRAKES | Shimano Deore, BR-M420, hydraulic disc, 4-piston, 220mm [F], 203mm [R] |
| RIMS | Giant AM 27.5" (XS), 29"(S, M, L), Tubeless ready, 30mm inner width |
| HUBS | Shimano TC500 Boost, center-lock, 15x110mm [F], 12x148mm [R] |
Ordering a bike from Evo? If you choose the option Evo Home Delivery at the checkout your order will be personally delivered to you, by an Evo Crew Member, who will also be able to answer any questions you have about your new bike. If you choose Evo Delivery your bike will be delivered completely built, tuned and ready to ride! We are also able to offer Evo Home Delivery on previously restricted brands such as Giant & Trek!
Our home delivery charge is only $45 for 15km and $2 per km after that.
Free for all orders over $149. Orders under $149 a $8.99 flat shipping & handling fee applies. Order and pay online and collect everything from one of our showrooms. Just select which store you would like to collect from at checkout. Find out more about Click & Collect here.
LEARN MORE
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
