Designed to help riders explore farther and progress with confidence, the Embolden E+ pairs full-suspension control with smooth, intuitive electric support. From forest roads to real mountain singletrack, it makes new terrain feel welcoming and longer rides feel achievable—with less stress and more fun.
The E+ System is a fusion of advanced technology and purposeful design, integrated in perfect harmony for your choices, your goals, your ride. Whether you want to climb higher, go farther, or enjoy the trail ahead, these user-friendly components and technologies—including motors, control units, battery packs and more—seamlessly blend electric power with human power to deliver a smart, natural, powerful and secure ride experience.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| sizes | XS, S, M, L |
| stem | Giant Contact SL 35 |
| spokes | Sapim Race |
| lock | Torx 25 Battery Lock with built-in Torque limiter |
| brake levers | Shimano Deore XT BL-M8100 |
| extras | Tubeless kit (liquid, valves, levers, manual, tool) |
| controller | Giant RideControl Dash 2, Smart Assist automatic mode, 5 support levels |
| colors | Atmosphere |
| display | Giant RideControl Dash 2, full color LCD display |
| battery | Giant EnergyPak 800Wh |
| charger | Giant EnergyPak 4A smart charger |
| frame | ALUXX SL-grade aluminum, 140mm travel FlexPoint linkage driven suspension system, 148x12 Boost rear axle, UDHTM Universal Derailleur hanger, KSA40 compatible, 185x52.5mm shock, 1.5~1.8" headset (ZS62/ZS72) |
| pedals | Large platform pedal, 28-pins, PP cage, Steel axle |
| shifters | Shimano Cues LinkGlide |
| chain | Shimano LinkGlide |
| fender/chainguard | MRP 1x HD guide, CS e-Mount, 32~38T Adjustable |
| fork | Fox 36 Rhythm Air, 150mm travel, Grip damper 110x15mm thru-axle |
| rear derailleur | Shimano Deore XT 11-speed Shadow+ |
| cassette | Shimano Cues LinkGlide, 11-speed, 11-50T |
| motor | Giant SyncDrive Pro 3X 100Nm, PedalPlus 6-Sensor technology |
| shock | Fox Float X, 185x52.5mm, Sag recommendation - 30% (15.75mm) |
| handlebar | Giant Connect TR35, 20mm rise, 35x750mm [XS, S], 35X780mm [M, L] |
| grips | Liv Tactal Pro single lock-on |
| seatpost | Giant Contact Switch AT travel adjust dropper seatpost (XS, S - 110-140mm, M -140-170mm, L - 170-200mm) |
| saddle | Liv Contact Ergo Trail |
| brakes | Shimano Deore XT, BR-M8120, hydraulic disc 4-piston, 220mm [F], 203mm [R] |
| crankset | Direct-mount steel 36T (maximum - 38T), Forged aluminum crank arms |
| rims | Giant TRA2 27.5" (XS), 29"(S, M, L) tubeless ready, 30mm inner width |
| hubs | Giant E-Drive 260Nm, 72T engagement, e-bike optimized, sealed bearing, Boost Thru-axle 110x15 [F] , 148x 12mm [R] |
| tires | Maxxis Minion DHF 27x2.5" (XS), 29x2.50" (S, M, L) foldable, TLR EXO [F}, Maxxis Dissector 27.5x2.4" (XS), 29x2.40" (S, M, L) foldable WT, TLR, EXO [R] |
| combined maximum load limit | 140kg |
| SIZES | XS, S, M, L |
| Groupset Brand | Shimano |
| Frame Material | Alloy |
| Fork Brand | Fox |
| Groupset Model | XT |
| Motor Brand | Giant |
| Shifting Type | Mechanical |
| Battery Brand | Giant |
| Pedals Included | No |
| Stem | Giant Contact SL 35 |
| Max Assisted Speed | 32km/h |
| Ride Style | Trail |
| SPOKES | Sapim Race |
| Lock | Torx 25 Battery Lock with built-in Torque limiter |
| Fork Material | Suspension |
| Brake Levers | Shimano Deore XT BL-M8100 |
| EXTRAS | Tubeless kit (liquid, valves, levers, manual, tool) |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 11 |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| CONTROLLER | Giant RideControl Dash 2, Smart Assist automatic mode, 5 support levels |
| COLORS | Atmosphere |
| Display | Giant RideControl Dash 2, full color LCD display |
| Battery | Giant EnergyPak 800Wh |
| Charger | Giant EnergyPak 4A smart charger |
| FRAME | ALUXX SL-grade aluminum, 140mm travel FlexPoint linkage driven suspension system, 148x12 Boost rear axle, UDHTM Universal Derailleur hanger, KSA40 compatible, 185x52.5mm shock, 1.5~1.8" headset (ZS62/ZS72) |
| PEDALS | Large platform pedal, 28-pins, PP cage, Steel axle |
| Shifters | Shimano Cues LinkGlide |
| Chain | Shimano LinkGlide |
| Fender/Chainguard | MRP 1x HD guide, CS e-Mount, 32~38T Adjustable |
| Fork | Fox 36 Rhythm Air, 150mm travel, Grip damper 110x15mm thru-axle |
| Rear Derailleur | Shimano Deore XT 11-speed Shadow+ |
| Cassette | Shimano Cues LinkGlide, 11-speed, 11-50T |
| Motor | Giant SyncDrive Pro 3X 100Nm, PedalPlus 6-Sensor technology |
| Shock | Fox Float X, 185x52.5mm, Sag recommendation - 30% (15.75mm) |
| Handlebar | Giant Connect TR35, 20mm rise, 35x750mm [XS, S], 35X780mm [M, L] |
| GRIPS | Liv Tactal Pro single lock-on |
| Seatpost | Giant Contact Switch AT travel adjust dropper seatpost (XS, S - 110-140mm, M -140-170mm, L - 170-200mm) |
| Saddle | Liv Contact Ergo Trail |
| BRAKES | Shimano Deore XT, BR-M8120, hydraulic disc 4-piston, 220mm [F], 203mm [R] |
| Crankset | Direct-mount steel 36T (maximum - 38T), Forged aluminum crank arms |
| RIMS | Giant TRA2 27.5" (XS), 29"(S, M, L) tubeless ready, 30mm inner width |
| HUBS | Giant E-Drive 260Nm, 72T engagement, e-bike optimized, sealed bearing, Boost Thru-axle 110x15 [F] , 148x 12mm [R] |
| Tires | Maxxis Minion DHF 27x2.5" (XS), 29x2.50" (S, M, L) foldable, TLR EXO [F}, Maxxis Dissector 27.5x2.4" (XS), 29x2.40" (S, M, L) foldable WT, TLR, EXO [R] |
| Combined Maximum Load Limit | 140kg |
Ordering a bike from Evo? If you choose the option Evo Home Delivery at the checkout your order will be personally delivered to you, by an Evo Crew Member, who will also be able to answer any questions you have about your new bike. If you choose Evo Delivery your bike will be delivered completely built, tuned and ready to ride! We are also able to offer Evo Home Delivery on previously restricted brands such as Giant & Trek!
Our home delivery charge is only $45 for 15km and $2 per km after that.
Free for all orders over $149. Orders under $149 a $8.99 flat shipping & handling fee applies. Order and pay online and collect everything from one of our showrooms. Just select which store you would like to collect from at checkout. Find out more about Click & Collect here.
LEARN MORE
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
