Lightweight & Durable Entry-Level Hardtail
The CASCADE is built for the rider who doesn't want to be limited by the pavement. From city commutes to weekend explorations on forest paths, the CASCADE is built around a lightweight AL6 alloy frame and comes with a 100mm suspension fork to smooth out the bumps and disc brakes for confident stopping power.
| rear derailleur | Shimano Tourney RD-TY300 |
| fork | SUNTOUR XCE28 100MM TRAVEL |
| wheel set | ALLOY DOUBLE WALL |
| saddle | MTB SADDLE, STEEL ø7mm |
| frameset | AL6 XC Sport Frame |
| bb | SQUARE BB, 68mm |
| crank | WHEELTOP 42X34X24T |
| cassette | 14-28T |
| chain | MEILE M70 |
| seatpost | STEEL, 27.2x350mm |
| headset | ZERO STACK W/ SEALED BEARING, ZS 44/28.6 | 44/30 |
| brake lever | SHIMANO TOURNEY |
| shifter | SHIMANO ST-EF41, 3x7 SPEED TRIGGER |
| handlebar | STEEL RISE, W- 680MM, B- 31.8MM, R/D- 40MM |
| handlestem | ALLOY, E- 45MM, B- 31.8MM, R/D- 3 |
| tire | 27.5"x2.25" |
| rim | ALLOY DOUBLE WALL H-20mm W- 21mm 584 32H FOR TYRE 584-57 |
| hub | F- ALLOY, M9x100mm 32H QR / R- ALLOY, M10x145mm 32H QR |
| spokes | 14G STAINLESS NDS-272mm / DS-270mm, 12mm NIPPLE BRASS |
| brake caliper | MECHANICAL DISC BRAKE |
| rotor | 6-BOLTS 160mm |
| Groupset Brand | Shimano |
| Frame Material | Alloy |
| Fork Brand | Suntour |
| Groupset Model | Tourney |
| Fork Travel | 0 - 100mm |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Rear Derailleur | Shimano Tourney RD-TY300 |
| Ride Style | Sport |
| Fork | SUNTOUR XCE28 100MM TRAVEL |
| Fork Material | Suspension |
| Wheel Set | ALLOY DOUBLE WALL |
| Saddle | MTB SADDLE, STEEL ø7mm |
| Frameset | AL6 XC Sport Frame |
| Brake Type | Mechanical Disc Brake |
| Drivetrain Gearing | 3 x 7 |
| BB | SQUARE BB, 68mm |
| CRANK | WHEELTOP 42X34X24T |
| Cassette | 14-28T |
| Chain | MEILE M70 |
| Seatpost | STEEL, 27.2x350mm |
| Headset | ZERO STACK W/ SEALED BEARING, ZS 44/28.6 | 44/30 |
| Brake lever | SHIMANO TOURNEY |
| Shifter | SHIMANO ST-EF41, 3x7 SPEED TRIGGER |
| Handlebar | STEEL RISE, W- 680MM, B- 31.8MM, R/D- 40MM |
| Handlestem | ALLOY, E- 45MM, B- 31.8MM, R/D- 3 |
| TIRE | 27.5"x2.25" |
| Rim | ALLOY DOUBLE WALL H-20mm W- 21mm 584 32H FOR TYRE 584-57 |
| Hub | F- ALLOY, M9x100mm 32H QR / R- ALLOY, M10x145mm 32H QR |
| SPOKES | 14G STAINLESS NDS-272mm / DS-270mm, 12mm NIPPLE BRASS |
| BRAKE CALIPER | MECHANICAL DISC BRAKE |
| Rotor | 6-BOLTS 160mm |
