"Riding with Xtrada, feels like running as a wolf," they said. As an XC bike should be, Xtrada is born to run the game with you. Impeccably versatile, effortlessly fast, and obsessively comfortable. The Xtrada is a true cross country mountain bike with a geometry built for speed and stability coupled with tough, trail-ready components. It is perfect for hitting the local single track or an all-day mountain adventure.
Features
| frameset | ALX XC 29 |
| fork | X-FUSION MIGO LO DAMPER 32 120mm TRAVEL BOOST THRU AXLE |
| frame color | Charcoal black |
| decal color | RED BLACK |
| shifter | SHIMANO DEORE SL-M6100 1x12-SPEED TRIGGER |
| crank | SAMOX RAC61C-018S-C55 32T |
| cassette | SHIMANO CS-M6100 12-SPEED 10-51T |
| rear derailleur | SHIMANO DEORE RD-M6100 DIRECT ATTACH |
| bb | SAMOX 2-PIECE CRANKSET BSA THREADED |
| chain | KMC X-12 |
| pedal | ONE PIECE PP BODY |
| saddle | LINC VOID SADDLE, STEEL ø7mm |
| seatpost | X-FUSION MANIC LC 150mm TRAVEL, DXL - 30.9 x 429mm, OFFSET - 0mm, SEAT CLAMP - 34.9mm BOLT TYPE |
| handlebar | POLYGON SPORT ALLOY, W - 760mm, BB - 31.8mm, R/D - 20mm, B - 9degree |
| handlestem | POLYGON SPORT ALLOY, EXT - 40mm, BB - 31.8mm, R/D - 7degree |
| headset | ZERO STACK W/ SEALED BEARING, ZS 44/28.6 | ZS 56/40 |
| wheel set | ALLOY WHEELS |
| tire | WTB TRAIL BOSS 29"X2.25" |
| rim | F - ALLOY DOUBLE WALL H -19mm W - 23mm 32H FOR TYRE 622-68 / R - ALLOY DOUBLE WALL H -19mm W - 23mm 32H FOR TYRE 622-68 |
| hub | F - SHIMANO HB-TC500 THRU AXLE 15x110mm 32H CENTERLOCK / R - SHIMANO HB-TC500 THRU AXLE 12x148mm 32H CENTERLOCK FOR MICROSPLINE |
| spokes | F - 14G STAINLESS NDS - 294mm DS - 292mm 12MM NIPPLE BRASS / R - 14G STAINLESS NDS - 292mm DS - 290 12MM NIPPLE BRASS |
| brake lever | SHIMANO BL-MT200 |
| brake caliper | SHIMANO MT200 HYDRAULIC DISC BRAKE |
| rotor | SHIMANO SM-RT10 F - 180mm R - 160mm CENTERLOCK |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | Deore |
| Fork Brand | Xfusion |
| Fork Travel | 101 - 120mm |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Cross Country |
| Frameset | ALX XC 29 |
| Fork | X-FUSION MIGO LO DAMPER 32 120mm TRAVEL BOOST THRU AXLE |
| FRAME COLOR | Charcoal black |
| DECAL COLOR | RED BLACK |
| Shifter | SHIMANO DEORE SL-M6100 1x12-SPEED TRIGGER |
| CRANK | SAMOX RAC61C-018S-C55 32T |
| Cassette | SHIMANO CS-M6100 12-SPEED 10-51T |
| Rear Derailleur | SHIMANO DEORE RD-M6100 DIRECT ATTACH |
| BB | SAMOX 2-PIECE CRANKSET BSA THREADED |
| Chain | KMC X-12 |
| PEDAL | ONE PIECE PP BODY |
| Saddle | LINC VOID SADDLE, STEEL ø7mm |
| Seatpost | X-FUSION MANIC LC 150mm TRAVEL, DXL - 30.9 x 429mm, OFFSET - 0mm, SEAT CLAMP - 34.9mm BOLT TYPE |
| Handlebar | POLYGON SPORT ALLOY, W - 760mm, BB - 31.8mm, R/D - 20mm, B - 9degree |
| Handlestem | POLYGON SPORT ALLOY, EXT - 40mm, BB - 31.8mm, R/D - 7degree |
| Headset | ZERO STACK W/ SEALED BEARING, ZS 44/28.6 | ZS 56/40 |
| Wheel Set | ALLOY WHEELS |
| TIRE | WTB TRAIL BOSS 29"X2.25" |
| Rim | F - ALLOY DOUBLE WALL H -19mm W - 23mm 32H FOR TYRE 622-68 / R - ALLOY DOUBLE WALL H -19mm W - 23mm 32H FOR TYRE 622-68 |
| Hub | F - SHIMANO HB-TC500 THRU AXLE 15x110mm 32H CENTERLOCK / R - SHIMANO HB-TC500 THRU AXLE 12x148mm 32H CENTERLOCK FOR MICROSPLINE |
| SPOKES | F - 14G STAINLESS NDS - 294mm DS - 292mm 12MM NIPPLE BRASS / R - 14G STAINLESS NDS - 292mm DS - 290 12MM NIPPLE BRASS |
| Brake lever | SHIMANO BL-MT200 |
| BRAKE CALIPER | SHIMANO MT200 HYDRAULIC DISC BRAKE |
| Rotor | SHIMANO SM-RT10 F - 180mm R - 160mm CENTERLOCK |
