Naturally, our steel Hook is something special, being built from double-butted Columbus Cromor tubing, with a tapered headtube and a T47 bottom bracket. XS and S sizes feature 650B wheels, M - XL have 700C options and both run WTB tubeless rims and tyres on sealed hubs. A Shimano GRX groupset with a subcompact 46 / 30T crankset, combined with an 11 - 36T cassette helps to keep you spinning up and over the hills, and GRX 400 callipers deliver powerful braking on the descents. The frameset is bedecked with mounts for every scenario, including a top tube bag, triple cage mounts and bottle mount options, as well as internal dynamo routing on the full carbon fork.
| handlebar | Bombtrack CX-10 drop bar, 31.8 mm, 10° flare |
| stem | Bombtrack Roam forged aluminium stem, -7° |
| through axle | 12 x 100 mm / 12 x 142 mm |
| front rim | WTB ST i19 double wall, TCS 2.0, 32h |
| rear rim | WTB ST i19 double wall, TCS 2.0, 32h |
| saddle | Seido Comp saddle |
| maximum rider weight | 120 kg incl. luggage |
| astm riding condition | 2 |
| frame | Columbus Cromor double butted, TA dropout, rack / fender mounts, ED coated, 86.5 mm T47 BB shell |
| fork | Full carbon, TA, 1.1/2'' - 1.1/8'', triple cage mounts (can double as fender mounts),internal hub dynamo cable routing |
| headset | Sealed external aheadset, 1.1/2'' - 1.1/8'' |
| levers | Shimano GRX ST-RX400 STI Hydraulic |
| shifter | Shimano GRX ST-RX400 STI 2 x 10 |
| brakes | Shimano GRX BR-RX400 hydraulic disc brakes |
| rotor | Shimano SM-RT66 160 mm rotors |
| crankset | Shimano GRX FC-RX600-10, 24 mm spindle |
| bb | Bombtrack T47 internal sealed BB for 24 mm spindle |
| chain | KMC X10 EPT Anti Rust chain, 1/2'' x 11/128'', XS - S 112L, M - XL 114L |
| chainring | Shimano GRX, 46 T / 30 T |
| cassette | Shimano CS-HG50 10-speed, 11 - 36 T |
| front derailleur | Shimano GRX FD-RX400-F |
| rear derailleur | Shimano GRX RD-RX400, clutch |
| front hub | Bombtrack Tau sealed hub, 6-bolt disc |
| rear hub | Bombtrack Tau sealed hub, 11-speed, 6-bolt disc |
| seat post | Bombtrack Beech 27.2 mm x 415 mm size XL; 315 mm size XS - L |
| seat clamp | Bombtrack Origin 29.8 mm |
| front tire | XS - S WTB Resolute 650B x 42C / |
| rear tire | XS - S WTB Resolute 650B x 42C / |
| weight | 11.1 kg (size M) |
| weight frameset | 2420 g frame (size M, incl. TA, hanger) / 600 g fork (300 mm steerer, incl. TA) |
| grips | Bombtrack Escape bar tape |
| Fork Material | Carbon |
| Groupset Brand | Shimano |
| Frame Material | Steel |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Ride Style | Gravel |
| Groupset Model | GRX |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 2 x 11 |
| Handlebar | Bombtrack CX-10 drop bar, 31.8 mm, 10° flare |
| Stem | Bombtrack Roam forged aluminium stem, -7° |
| Through axle | 12 x 100 mm / 12 x 142 mm |
| FRONT RIM | WTB ST i19 double wall, TCS 2.0, 32h |
| REAR RIM | WTB ST i19 double wall, TCS 2.0, 32h |
| Saddle | Seido Comp saddle |
| Maximum Rider Weight | 120 kg incl. luggage |
| ASTM riding condition | 2 |
| FRAME | Columbus Cromor double butted, TA dropout, rack / fender mounts, ED coated, 86.5 mm T47 BB shell |
| Fork | Full carbon, TA, 1.1/2'' - 1.1/8'', triple cage mounts (can double as fender mounts),internal hub dynamo cable routing |
| Headset | Sealed external aheadset, 1.1/2'' - 1.1/8'' |
| LEVERS | Shimano GRX ST-RX400 STI Hydraulic |
| Shifter | Shimano GRX ST-RX400 STI 2 x 10 |
| BRAKES | Shimano GRX BR-RX400 hydraulic disc brakes |
| Rotor | Shimano SM-RT66 160 mm rotors |
| Crankset | Shimano GRX FC-RX600-10, 24 mm spindle |
| BB | Bombtrack T47 internal sealed BB for 24 mm spindle |
| Chain | KMC X10 EPT Anti Rust chain, 1/2'' x 11/128'', XS - S 112L, M - XL 114L |
| CHAINRING | Shimano GRX, 46 T / 30 T |
| Cassette | Shimano CS-HG50 10-speed, 11 - 36 T |
| Front Derailleur | Shimano GRX FD-RX400-F |
| Rear Derailleur | Shimano GRX RD-RX400, clutch |
| FRONT HUB | Bombtrack Tau sealed hub, 6-bolt disc |
| REAR HUB | Bombtrack Tau sealed hub, 11-speed, 6-bolt disc |
| SEAT POST | Bombtrack Beech 27.2 mm x 415 mm size XL; 315 mm size XS - L |
| SEAT CLAMP | Bombtrack Origin 29.8 mm |
| FRONT TIRE | XS - S WTB Resolute 650B x 42C / |
| REAR TIRE | XS - S WTB Resolute 650B x 42C / |
| Weight | 11.1 kg (size M) |
| Weight frameset | 2420 g frame (size M, incl. TA, hanger) / 600 g fork (300 mm steerer, incl. TA) |
| GRIPS | Bombtrack Escape bar tape |
