This bike’s built tough with Columbus Cromor steel tubing, giving it a smooth ride and loads of durability. We’ve loaded it up with all the mounts you’ll need to carry your gear - racks, cages, whatever you want. The WTB Ranger 27.5 x 2.0” tires grip the trail like a champ, making it a blast when you leave the pavement behind. Thanks to the SRAM Apex Eagle 1x setup, shifting and braking feel solid and simple, with a wide gear range to tackle anything from steep climbs to fast flats. The Seido MGV carbon fork also has plenty of mounts and room for big tires, plus neat hidden cables to keep things looking clean. Basically, the EXT is ready to roll wherever your ride takes you — whether it’s a quick spin around the neighbourhood or a weekend off-road mission.
| through axle | 12 x 100 mm / 12 x 142 mm |
| saddle | Seido Comp saddle |
| astm riding condition | 2 |
| stem | Seido Meander forged aluminium stem, -6° |
| fork | Seido MGV full carbon, TA, 1.1/2'' - 1.1/8'', fender / triple cage mounts, 180 mm max rotor size, lowrider rack compatible, internal hub dynamo cable routing |
| front tire | WTB Ranger TCS Light / Fast Rolling 27.5'' x 2.0'', tubeless ready |
| rear tire | WTB Ranger TCS Light / Fast Rolling 27.5'' x 2.0'', tubeless ready |
| maximum rider weight | 130 kg incl. luggage |
| frame | Columbus Cromor double butted, TA, rack / fender mounts, internal light cable routing, rear light mount, ED coated, 85.5 mm T47 BB shell |
| handlebar | Seido Tackle drop bar, 31.8 mm, 16° flare |
| rear derailleur | Sram Apex Eagle, clutch, long cage |
| headset | Seido Pro EC sealed external headset, 1.1/2'' - 1.1/8'' |
| levers | Sram Apex Eagle double tap hydraulic |
| shifter | Sram Apex Eagle double tap 1x12 |
| brakes | Sram Apex flat mount hydraulic disc brakes |
| rotor | Sram Centerline 180 mm front and 160 mm rear rotor |
| crankset | Sram Apex Wide, DUB spindle |
| bb | Seido T47 Pro 85.5 mm for 30 mm spindle |
| chain | Sram Apex, flattop, 1/2'' x 11/128'', 112L |
| cassette | Sram NX Eagle PG-1230 12-speed, 11 - 50 T |
| front hub | Seido Tau sealed hub, 6-bolt disc |
| rear hub | Seido Tau sealed hub, HG driver, 6-bolt disc |
| front rim | Seido Sinus i25 double wall asymmetric, tubeless ready, 32h |
| rear rim | Seido Sinus i25 double wall asymmetric, tubeless ready, 32h |
| seat post | Seido Yew aluminium seatpost, 27.2 mm x 350 mm |
| seat clamp | Bombtrack Prime 29.8 mm |
| weight | 11.7 kg (size M) |
| weight frameset | 2710 g frame (size L, incl. TA, hanger) / 550 g fork (300 mm steerer, incl. TA) |
| Fork Material | Carbon |
| Frame Material | Steel |
| Groupset Brand | Sram |
| Groupset Model | Apex |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Ride Style | Gravel |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 12 |
| Through axle | 12 x 100 mm / 12 x 142 mm |
| Saddle | Seido Comp saddle |
| ASTM riding condition | 2 |
| Stem | Seido Meander forged aluminium stem, -6° |
| Fork | Seido MGV full carbon, TA, 1.1/2'' - 1.1/8'', fender / triple cage mounts, 180 mm max rotor size, lowrider rack compatible, internal hub dynamo cable routing |
| FRONT TIRE | WTB Ranger TCS Light / Fast Rolling 27.5'' x 2.0'', tubeless ready |
| REAR TIRE | WTB Ranger TCS Light / Fast Rolling 27.5'' x 2.0'', tubeless ready |
| Maximum Rider Weight | 130 kg incl. luggage |
| FRAME | Columbus Cromor double butted, TA, rack / fender mounts, internal light cable routing, rear light mount, ED coated, 85.5 mm T47 BB shell |
| Handlebar | Seido Tackle drop bar, 31.8 mm, 16° flare |
| Rear Derailleur | Sram Apex Eagle, clutch, long cage |
| Headset | Seido Pro EC sealed external headset, 1.1/2'' - 1.1/8'' |
| LEVERS | Sram Apex Eagle double tap hydraulic |
| Shifter | Sram Apex Eagle double tap 1x12 |
| BRAKES | Sram Apex flat mount hydraulic disc brakes |
| Rotor | Sram Centerline 180 mm front and 160 mm rear rotor |
| Crankset | Sram Apex Wide, DUB spindle |
| BB | Seido T47 Pro 85.5 mm for 30 mm spindle |
| Chain | Sram Apex, flattop, 1/2'' x 11/128'', 112L |
| Cassette | Sram NX Eagle PG-1230 12-speed, 11 - 50 T |
| FRONT HUB | Seido Tau sealed hub, 6-bolt disc |
| REAR HUB | Seido Tau sealed hub, HG driver, 6-bolt disc |
| FRONT RIM | Seido Sinus i25 double wall asymmetric, tubeless ready, 32h |
| REAR RIM | Seido Sinus i25 double wall asymmetric, tubeless ready, 32h |
| SEAT POST | Seido Yew aluminium seatpost, 27.2 mm x 350 mm |
| SEAT CLAMP | Bombtrack Prime 29.8 mm |
| Weight | 11.7 kg (size M) |
| Weight frameset | 2710 g frame (size L, incl. TA, hanger) / 550 g fork (300 mm steerer, incl. TA) |
