The Audax AL Sword is an allroad bike designed for long miles, mixed surfaces and everyday reliability. Its lightweight aluminium frame with a T47 bottom bracket delivers a strong, responsive ride, while the full carbon fork with bottle cage mounts boosts versatility for endurance adventures. Equipped with Microshift’s Sword 10-speed wide-range drivetrain and an 11 – 48T cassette, you’ll have all the gears you need for steep climbs and fast flats. The clutched Sword rear derailleur with a replaceable cage ensures smooth, secure shifting, even on rough terrain. A Bombtrack Lyer 30 mm aluminium crankset with a 40T narrow-wide chainring adds durability and chain retention. Rolling on tubeless-ready WTB ST i21 rims with plush 650B x 47C WTB Horizon tires, the Audax AL Sword is ready for the road less travelled.
| front derailleur | - |
| pedals | - |
| handlebar | Bombtrack CX-10 drop bar, 31.8 mm, 10° flare |
| grips | Bombtrack Command bar tape |
| stem | Bombtrack Roam forged aluminium stem, -7° |
| headset | Sealed integrated aheadset, 1.1/2'' - 1.1/8'' |
| bb | Bombtrack T47 internal sealed BB for 30 mm spindle |
| chain | KMC X11 chain, 1/2'' x 11/128'', 114L |
| chainring | CNC machined aluminium, narrow-wide, 40 T |
| front hub | Bombtrack Arc sealed hub, 6-bolt disc |
| rear hub | Bombtrack Arc sealed hub, 11-speed, 6-bolt disc |
| through axle | 12 x 100 mm / 12 x 142 mm |
| saddle | Seido Comp saddle |
| seat post | Bombtrack Beech 27.2 mm x 400 mm |
| seat clamp | Bombtrack Origin 31.8 mm |
| fender | - |
| rack | - |
| kickstand | - |
| light | - |
| maximum rider weight | 120 kg incl. luggage |
| astm riding condition | 2 |
| front rim | WTB ST i21 double wall, TCS 2.0, 32h |
| rear rim | WTB ST i21 double wall, TCS 2.0, 32h |
| fork | Full carbon, TA, 1.1/2'' - 1.1/8'', with fender / cage mounts |
| frame | 6061-T6 double butted aluminium, TA, fender mounts, 86.5 mm T47 BB shell |
| brakes | TRP Spyre C flat mount mechanic disc brakes |
| rotor | TRP 160 mm rotors |
| front tire | WTB Horizon 650B x 47C |
| rear tire | WTB Horizon 650B x 47C |
| weight frameset | 1810 g frame (size M, incl. TA, hanger) / 530 g fork (300 mm steerer, incl. TA) |
| levers | Microshift SB-M110 Dual Control Lever mechanic |
| shifter | Microshift SB-M110 Dual Control Lever 1 x 11 |
| crankset | Bombtrack Lyer forged aluminium crank, direct mount interface (Sram compatible),30 mm spindle |
| cassette | Microshift CS-HG113 11-speed, 11 - 46 T |
| rear derailleur | Microshift RD-M6655, clutch, medium cage |
| weight | 10.4 kg (size M) |
| Fork Material | Carbon |
| Frame Material | Alloy |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Front Derailleur | - |
| PEDALS | - |
| Ride Style | Gravel |
| Groupset Brand | Microshift |
| Brake Type | Mechanical Disc Brake |
| Drivetrain Gearing | 1 x 10 |
| Handlebar | Bombtrack CX-10 drop bar, 31.8 mm, 10° flare |
| GRIPS | Bombtrack Command bar tape |
| Stem | Bombtrack Roam forged aluminium stem, -7° |
| Headset | Sealed integrated aheadset, 1.1/2'' - 1.1/8'' |
| BB | Bombtrack T47 internal sealed BB for 30 mm spindle |
| Chain | KMC X11 chain, 1/2'' x 11/128'', 114L |
| CHAINRING | CNC machined aluminium, narrow-wide, 40 T |
| FRONT HUB | Bombtrack Arc sealed hub, 6-bolt disc |
| REAR HUB | Bombtrack Arc sealed hub, 11-speed, 6-bolt disc |
| Through axle | 12 x 100 mm / 12 x 142 mm |
| Saddle | Seido Comp saddle |
| SEAT POST | Bombtrack Beech 27.2 mm x 400 mm |
| SEAT CLAMP | Bombtrack Origin 31.8 mm |
| FENDER | - |
| Rack | - |
| Kickstand | - |
| LIGHT | - |
| Maximum Rider Weight | 120 kg incl. luggage |
| ASTM riding condition | 2 |
| FRONT RIM | WTB ST i21 double wall, TCS 2.0, 32h |
| REAR RIM | WTB ST i21 double wall, TCS 2.0, 32h |
| Fork | Full carbon, TA, 1.1/2'' - 1.1/8'', with fender / cage mounts |
| FRAME | 6061-T6 double butted aluminium, TA, fender mounts, 86.5 mm T47 BB shell |
| BRAKES | TRP Spyre C flat mount mechanic disc brakes |
| Rotor | TRP 160 mm rotors |
| FRONT TIRE | WTB Horizon 650B x 47C |
| REAR TIRE | WTB Horizon 650B x 47C |
| Weight frameset | 1810 g frame (size M, incl. TA, hanger) / 530 g fork (300 mm steerer, incl. TA) |
| LEVERS | Microshift SB-M110 Dual Control Lever mechanic |
| Shifter | Microshift SB-M110 Dual Control Lever 1 x 11 |
| Crankset | Bombtrack Lyer forged aluminium crank, direct mount interface (Sram compatible),30 mm spindle |
| Cassette | Microshift CS-HG113 11-speed, 11 - 46 T |
| Rear Derailleur | Microshift RD-M6655, clutch, medium cage |
| Weight | 10.4 kg (size M) |
