Arise SG Apex is more than ready for whatever multi-surface adventure you have lined up. Based on our trusted double-butted Arise frame, with size-specific wheels so everybody has that same Bombtrack experience. We’ve also added SRAM’s excellent Apex 1 x 11 drivetrain. The 11 – 42T cassette coupled with a 40T front ring make light work of spinning up those hills, and with the Bombtrack cockpit and Tektro mechanical disc brakes, give you a commanding position going down the other side. Add in tubeless-ready WTB rims, a multitude of mounts and internal dynamo light routing, and you have the basis of a fantastic adventure companion.
| handlebar | Bombtrack CX-10 drop bar, 31.8 mm, 10° flare |
| grips | Bombtrack Command bar tape |
| stem | Bombtrack Roam forged aluminium stem, -7° |
| chain | KMC X11 chain, 1/2'' x 11/128'', 114L |
| cassette | Sram PG-1130 11-speed, 11 - 42 T |
| front hub | Bombtrack Arc sealed hub, 6-bolt disc |
| rear hub | Bombtrack Arc sealed hub, 11-speed, 6-bolt disc |
| through axle | 12 x 100 mm / 12 x 142 mm |
| front rim | WTB ST i19 double wall, TCS 2.0, 32h |
| rear rim | WTB ST i19 double wall, TCS 2.0, 32h |
| maximum rider weight | 120 kg incl. luggage |
| astm riding condition | 2 |
| headset | Neco H282 sealed external aheadset, 1.1/8'' |
| brakes | Tektro Mira post mount mechanic disc brakes |
| rotor | Tektro 180 mm front and 160 mm rear rotor |
| saddle | Bombtrack Fuzz saddle |
| seat clamp | Bombtrack Prime 29.8 mm |
| levers | Sram Apex double tap mechanic |
| shifter | Sram Apex double tap 1 x 11 |
| bb | BSA sealed BB, external cups |
| rear derailleur | Sram Apex 1, clutch, long cage |
| frame | 4130 double butted crmo, heat treated front triangle, TA sliding dropouts, rack / fender mounts, 68 mm BSA BB shell |
| crankset | Bombtrack TAF19 aluminium crank, 24 mm spindle |
| chainring | Bombtrack Ridge aluminium chainring, narrow-wide, 40 T |
| seat post | Bombtrack Beech 27.2 mm x 300 mm |
| weight | 12.25 kg (size M) |
| weight frameset | 2480 g frame (size M, incl. TA, hanger) / 1370 g fork (300 mm steerer, incl. TA) |
| fork | 4130 crmo, TA, rack / fender mounts, internal hub |
| front tire | XS - S Vee Tire Speedster 650B x 38C / |
| rear tire | XS - S Vee Tire Speedster 650B x 38C / |
| Frame Material | Steel |
| Groupset Brand | Sram |
| Groupset Model | Apex |
| Fork Material | Steel |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Ride Style | Gravel |
| Brake Type | Mechanical Disc Brake |
| Drivetrain Gearing | 1 x 11 |
| Handlebar | Bombtrack CX-10 drop bar, 31.8 mm, 10° flare |
| GRIPS | Bombtrack Command bar tape |
| Stem | Bombtrack Roam forged aluminium stem, -7° |
| Chain | KMC X11 chain, 1/2'' x 11/128'', 114L |
| Cassette | Sram PG-1130 11-speed, 11 - 42 T |
| FRONT HUB | Bombtrack Arc sealed hub, 6-bolt disc |
| REAR HUB | Bombtrack Arc sealed hub, 11-speed, 6-bolt disc |
| Through axle | 12 x 100 mm / 12 x 142 mm |
| FRONT RIM | WTB ST i19 double wall, TCS 2.0, 32h |
| REAR RIM | WTB ST i19 double wall, TCS 2.0, 32h |
| Maximum Rider Weight | 120 kg incl. luggage |
| ASTM riding condition | 2 |
| Headset | Neco H282 sealed external aheadset, 1.1/8'' |
| BRAKES | Tektro Mira post mount mechanic disc brakes |
| Rotor | Tektro 180 mm front and 160 mm rear rotor |
| Saddle | Bombtrack Fuzz saddle |
| SEAT CLAMP | Bombtrack Prime 29.8 mm |
| LEVERS | Sram Apex double tap mechanic |
| Shifter | Sram Apex double tap 1 x 11 |
| BB | BSA sealed BB, external cups |
| Rear Derailleur | Sram Apex 1, clutch, long cage |
| FRAME | 4130 double butted crmo, heat treated front triangle, TA sliding dropouts, rack / fender mounts, 68 mm BSA BB shell |
| Crankset | Bombtrack TAF19 aluminium crank, 24 mm spindle |
| CHAINRING | Bombtrack Ridge aluminium chainring, narrow-wide, 40 T |
| SEAT POST | Bombtrack Beech 27.2 mm x 300 mm |
| Weight | 12.25 kg (size M) |
| Weight frameset | 2480 g frame (size M, incl. TA, hanger) / 1370 g fork (300 mm steerer, incl. TA) |
| Fork | 4130 crmo, TA, rack / fender mounts, internal hub |
| FRONT TIRE | XS - S Vee Tire Speedster 650B x 38C / |
| REAR TIRE | XS - S Vee Tire Speedster 650B x 38C / |
