The Flame CRB is an electric bike designed for high performance on demanding routes. Equipped with a powerful Bosch motor and a lightweight carbon frame, it combines power, speed, and agility to tackle any terrain. The motor delivers smooth, efficient assistance, while the carbon frame ensures lightness, stiffness, and stability. Its optimized geometry guarantees precise and comfortable handling, ideal for riders seeking control and performance on mountain adventures.
KEY FEATURES
Advanced Carbon Construction
The Flame CRB combines lightness and stiffness for optimal mountain performance. Its high-quality carbon fiber frame, with minimal weight, improves agility and handling on technical terrain. Its rigid structure ensures efficient power transfer, optimizing each pedal stroke and easing steep climbs.
The frame geometry balances control and comfort, ensuring stability on uneven surfaces, descents, and tight corners.
A clean and sophisticated design for riders seeking top performance on every route.
Bosch Performance Line CX
GO FURTHER!
The Flame CRB, equipped with the powerful Bosch motor and 800 Wh PowerTube battery, offers impressive energy capacity, expandable up to 1,050 Wh with the 250 Wh PowerMore. This combination ensures exceptional range for long and demanding rides.
The extension system is designed to deliver top performance on every ride, allowing you to tackle steep climbs, technical descents, and long days without worrying about battery life.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| fork | Rock Shox 35 Psylo Silver RC, 150mm Travel, 15x110mm BOOST, 1.8" Tapered, 44mm offset |
| shock | Rock Shox Deluxe Select R, 230x60mm |
| headset | Acros AZX-286R1 ZS56 blocklock 150º |
| motor | Bosch Performance Line CX, 5gen BDU384Y, Smart System / 100Nm 750W |
| battery | Bosch PowerTube 800 |
| display | Bosch Display Kiox 400C (BRC3200) |
| rear derailleur | Shimano XT M8100, Shadow Plus 12-Speed |
| shifters | Shimano Deore 6100 Speed Rapidfire Plus 12-Speed |
| crankset | FSA Bosch Direct Mount Chainring 34t CL55 12-Speed, Crankset 320 165mm |
| cassette | Shimano Deore 6100 10-51T |
| brakes | Shimano MT520 hydraulic disc 4-Piston, 203mm |
| hubs | Megamo Hubs, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST EBIKE+ |
| wheels | Megamo 29 SL 30 ASY, Aluminium Rim, 15x110/12x148 mm |
| handlebar | Megamo Alloy Butted 31,8 x 780 mm, 12 mm Rise, 6º Back Sweep |
| stem | Satori New Ursa 35mm |
| seatpost | Megamo Ø 31,6mm telescopic seat post, remote adjustment S size 125 mm Drop / M size 150 mm Drop / L size 170 mm Drop |
| seat | Fizik Terra Aidon X5 |
| tires | Maxxis Front - 29 x 2.5 Assegai, Rear - 29 x 2.4 Minion DHR II |
| Frame Material | Carbon |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | XT |
| Fork Brand | Rockshox |
| Motor Brand | Bosch |
| Max Assisted Speed | 32km/h |
| Battery Brand | Bosch |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Trail |
| Fork | Rock Shox 35 Psylo Silver RC, 150mm Travel, 15x110mm BOOST, 1.8" Tapered, 44mm offset |
| Shock | Rock Shox Deluxe Select R, 230x60mm |
| Headset | Acros AZX-286R1 ZS56 blocklock 150º |
| Motor | Bosch Performance Line CX, 5gen BDU384Y, Smart System / 100Nm 750W |
| Battery | Bosch PowerTube 800 |
| Display | Bosch Display Kiox 400C (BRC3200) |
| Rear Derailleur | Shimano XT M8100, Shadow Plus 12-Speed |
| Shifters | Shimano Deore 6100 Speed Rapidfire Plus 12-Speed |
| Crankset | FSA Bosch Direct Mount Chainring 34t CL55 12-Speed, Crankset 320 165mm |
| Cassette | Shimano Deore 6100 10-51T |
| BRAKES | Shimano MT520 hydraulic disc 4-Piston, 203mm |
| HUBS | Megamo Hubs, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST EBIKE+ |
| Wheels | Megamo 29 SL 30 ASY, Aluminium Rim, 15x110/12x148 mm |
| Handlebar | Megamo Alloy Butted 31,8 x 780 mm, 12 mm Rise, 6º Back Sweep |
| Stem | Satori New Ursa 35mm |
| Seatpost | Megamo Ø 31,6mm telescopic seat post, remote adjustment S size 125 mm Drop / M size 150 mm Drop / L size 170 mm Drop |
| SEAT | Fizik Terra Aidon X5 |
| Tires | Maxxis Front - 29 x 2.5 Assegai, Rear - 29 x 2.4 Minion DHR II |
