****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | Reason AL Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel- 140 mm |
| fork | FOX 34 Float AWL, 140 mm Travel, Rail 2.0, Sweep-Adjust, Kabolt Axle 110, 1.5 Tapered, 44mm offset |
| shock | Fox Float Rhythm, Evol LV, 210x47,5mm, 2 Position |
| headset | Acros AZX-589 ZS56 blocklock 150º |
| motor | DJI Avinox M1, 120Nm 1000W (Boost mode) / 105Nm 1000W, 5 assistance modes, 150rpm |
| battery | DJI Avinox 800 Wh, 35,9V, IP56 |
| display | DJI Avinox DP100, pantalla táctil OLED a todo color de 2 pulgadas, 800nits, 326ppi |
| rear derailleur | Shimano XT M8100, Shadow Plus 12-Speed |
| shifters | Shimano Deore 6100 Speed Rapidfire Plus 12-Speed |
| crankset | 34T BCD 104mm with chainring bolt / Forged AL6061/T6 165mm beat blasted anodized black |
| cassette | Shimano Deore 6100 10-51T |
| brakes | Shimano XT BR-M8220, hydraulic disc 4-Piston, 203/203mm |
| tires | Front- Pirelli Scorpion 29x2.4 MTB scM Trail ProWALL SmartGRIP / Rear- Pirelli Scorpion 29x2.4 MTB scR Trail ProWALL SmartGRIP |
| wheels | Megamo 29 SL 30 ASY - Micro, 30 mm Tubeless ready Aluminium rim |
| handlebar | Megamo Alloy Butted 35 x 800 mm, 12 mm Rise, 6º Back Sweep |
| stem | Megamo 3D Forged Alloy, ±7º Rise, S size 60 mm / M size 60 mm / L size 70 mm |
| seatpost | Megamo Ø 31,6mm telescopic seat post, remote adjustment S size 125 mm Drop / M size 150 mm Drop / L size 170 mm Drop |
| seat | Selle Royal SRX Open |
| FRAME | Reason AL Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel- 140 mm |
| Fork | FOX 34 Float AWL, 140 mm Travel, Rail 2.0, Sweep-Adjust, Kabolt Axle 110, 1.5 Tapered, 44mm offset |
| Shock | Fox Float Rhythm, Evol LV, 210x47,5mm, 2 Position |
| Headset | Acros AZX-589 ZS56 blocklock 150º |
| Motor | DJI Avinox M1, 120Nm 1000W (Boost mode) / 105Nm 1000W, 5 assistance modes, 150rpm |
| Battery | DJI Avinox 800 Wh, 35,9V, IP56 |
| Display | DJI Avinox DP100, pantalla táctil OLED a todo color de 2 pulgadas, 800nits, 326ppi |
| Rear Derailleur | Shimano XT M8100, Shadow Plus 12-Speed |
| Shifters | Shimano Deore 6100 Speed Rapidfire Plus 12-Speed |
| Crankset | 34T BCD 104mm with chainring bolt / Forged AL6061/T6 165mm beat blasted anodized black |
| Cassette | Shimano Deore 6100 10-51T |
| BRAKES | Shimano XT BR-M8220, hydraulic disc 4-Piston, 203/203mm |
| Tires | Front- Pirelli Scorpion 29x2.4 MTB scM Trail ProWALL SmartGRIP / Rear- Pirelli Scorpion 29x2.4 MTB scR Trail ProWALL SmartGRIP |
| Wheels | Megamo 29 SL 30 ASY - Micro, 30 mm Tubeless ready Aluminium rim |
| Handlebar | Megamo Alloy Butted 35 x 800 mm, 12 mm Rise, 6º Back Sweep |
| Stem | Megamo 3D Forged Alloy, ±7º Rise, S size 60 mm / M size 60 mm / L size 70 mm |
| Seatpost | Megamo Ø 31,6mm telescopic seat post, remote adjustment S size 125 mm Drop / M size 150 mm Drop / L size 170 mm Drop |
| SEAT | Selle Royal SRX Open |
| Frame Material | Alloy |
| Fork Material | Alloy |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | XT |
| Fork Brand | Fox |
| Motor Brand | DJI |
| Battery Brand | DJI |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Trail |
