BORN TO BURN
The Flame CRB is an electric bike designed for high performance on demanding routes. Equipped with a powerful Bosch motor and a lightweight carbon frame, it combines power, speed, and agility to tackle any terrain. The motor delivers smooth, efficient assistance, while the carbon frame ensures lightness, stiffness, and stability. Its optimized geometry guarantees precise and comfortable handling, ideal for riders seeking control and performance on mountain adventures.
KEY FEATURES
Advanced Carbon Construction
The Flame CRB combines lightness and stiffness for optimal mountain performance. Its high-quality carbon fiber frame, with minimal weight, improves agility and handling on technical terrain. Its rigid structure ensures efficient power transfer, optimizing each pedal stroke and easing steep climbs.
The frame geometry balances control and comfort, ensuring stability on uneven surfaces, descents, and tight corners.
A clean and sophisticated design for riders seeking top performance on every route.
GO FURTHER!
The Flame CRB, equipped with the powerful Bosch motor and 800 Wh PowerTube battery, offers impressive energy capacity, expandable up to 1,050 Wh with the 250 Wh PowerMore. This combination ensures exceptional range for long and demanding rides.
The extension system is designed to deliver top performance on every ride, allowing you to tackle steep climbs, technical descents, and long days without worrying about battery life.
MAXIMUM RANGE WITH POWERMORE
The combination of the motor with the 800 Wh PowerTube battery and 250 Wh PowerMore extension creates an advanced system designed for exceptional range. With a total of 1,050 Wh, you can go further and longer without worrying about battery life. You’ll have all the capacity needed for long rides, tough climbs, and technical descents — maximizing every kilometer with no limits.
MORE THAN BOSCH, FLAME CRB
In a market where many bikes look alike, the FLAME CRB stands out with unique features: an advanced design combining an attractive aesthetic with a lightweight carbon frame, cutting-edge components, and optimized geometry for outstanding performance.
It offers practical options such as Mullet compatibility and expandable battery, adapting to each rider’s needs. Its weight is optimized for the lightness Enduro demands without sacrificing strength. Plus, it boasts class-leading range with up to 1,050 Wh capacity for longer, limitless adventures.
*Bosch motor firmware upgrade required.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| rear derailleur | Shimano XT M8100, Shadow Plus 12-Speed |
| tires | Maxxis Front - 29 x 2.5 Assegai, Rear - 29 x 2.4 Minion DHR II |
| stem | Satori New Ursa 35mm |
| seatpost | Megamo Ø 31,6mm telescopic seat post, remote adjustment S size 125 mm Drop / M size 150 mm Drop / L size 170 mm Drop |
| brakes | Shimano XT BR-M8220, hydraulic disc 4-Piston, 203/203mm |
| battery | Bosch PowerTube 800 |
| crankset | FSA Bosch Direct Mount Chainring 34t CL55 12-Speed, Crankset 320 165mm |
| handlebar | Megamo Alloy Butted 31,8 x 780 mm, 12 mm Rise, 6º Back Sweep |
| seat | Fizik Terra Aidon X5 |
| frame | Full Carbon Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel - 170/160 mm |
| headset | Acros AZX-286R1 ZS56 blocklock 150º |
| display | Bosch Display Kiox 400C (BRC3200) |
| fork | Fox 36 Performance 160mm, Grip, 3 Positions, Rake - 44mm |
| shock | Fox Float Performance Elite, 2pos, Evol LV, 230x60mm |
| shifters | Shimano XT 8100, 12-Speed |
| cassette | Shimano XT M8100, 10-51T |
| hubs | DT Swiss 370 Ratchet LN 18, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST |
| wheels | DT Swiss M 1900 SP, 30mm Tubeless ready Aluminium rim |
| motor | Bosch Performance Line CX, 5gen BDU384Y, Smart System / 100Nm 750W |
| Frame Material | Carbon |
| Groupset Brand | Shimano |
| Fork Brand | Fox |
| Groupset Model | XT |
| Motor Brand | Bosch |
| Battery Brand | Bosch |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Max Assisted Speed | 32km/h |
| Ride Style | Enduro |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 12 |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| Rear Derailleur | Shimano XT M8100, Shadow Plus 12-Speed |
| Tires | Maxxis Front - 29 x 2.5 Assegai, Rear - 29 x 2.4 Minion DHR II |
| Stem | Satori New Ursa 35mm |
| Seatpost | Megamo Ø 31,6mm telescopic seat post, remote adjustment S size 125 mm Drop / M size 150 mm Drop / L size 170 mm Drop |
| BRAKES | Shimano XT BR-M8220, hydraulic disc 4-Piston, 203/203mm |
| Battery | Bosch PowerTube 800 |
| Crankset | FSA Bosch Direct Mount Chainring 34t CL55 12-Speed, Crankset 320 165mm |
| Handlebar | Megamo Alloy Butted 31,8 x 780 mm, 12 mm Rise, 6º Back Sweep |
| SEAT | Fizik Terra Aidon X5 |
| FRAME | Full Carbon Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel - 170/160 mm |
| Headset | Acros AZX-286R1 ZS56 blocklock 150º |
| Display | Bosch Display Kiox 400C (BRC3200) |
| Fork | Fox 36 Performance 160mm, Grip, 3 Positions, Rake - 44mm |
| Shock | Fox Float Performance Elite, 2pos, Evol LV, 230x60mm |
| Shifters | Shimano XT 8100, 12-Speed |
| Cassette | Shimano XT M8100, 10-51T |
| HUBS | DT Swiss 370 Ratchet LN 18, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST |
| Wheels | DT Swiss M 1900 SP, 30mm Tubeless ready Aluminium rim |
| Motor | Bosch Performance Line CX, 5gen BDU384Y, Smart System / 100Nm 750W |
