Passenger ready and capable of carrying up to 180kg
The new Fatboy front suspension is an industry first for fat-tire e-bikes
Big power and great range with the 1040Wh / 52V Samsung Battery
Our upgraded braking system uses custom components built specifically for Fatboy bikes
The Scrambler V3 stays true to what made it famous. Rugged, playful, and built for the long way around. Look closer and you’ll feel the evolution: smoother suspension, rock-solid reliability, and refined power that moves with purpose. Efficient, capable, and made to keep you outside longer and more often.
INTRODUCING FBX
Developed alongside Bafang, FBX is a unified power architecture that connects the battery, motor and controller into one intelligent ecosystem. The result is a smoother ride, unrivalled efficiency and a new level of control built into the core of every Fatboy V3.
UNREAL SUSPENSION
The new Fatboy front suspension is an industry first for fat-tire e-bikes. Built from our own tooling, they are engineered to match the weight and geometry of every Fatboy V3. The front suspension includes preload, compression and rebound tuning, allowing precise control over how the bike feels on every ride.
The Harlem, Scrambler and Bagus now feature fully adjustable front and rear suspension, giving you the freedom to fine tune your setup for any terrain.
UPGRADED BRAKES
Our upgraded braking system uses custom components built specifically for Fatboy bikes. Instead of off-the-shelf parts, our 4-piston calipers run metal sintered pads with custom-designed cooling fins to manage heat at high speeds and deliver consistent performance in all conditions.
Paired with Fatboy moulded brake levers and heavy-duty 203mm discs now 2.9mm thick, the system delivers stronger, longer-lasting and more controlled stopping power on every ride.
ENHANCED ERGONOMICS
From the first sketch to the final ride, comfort shaped the V3. A lower-profile seat welcomes more riders, new bars and grips set a comfortable posture, and a refined crank ratio keeps high-speed pedalling smooth and effortless.
FEATURES:
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| motor | 52V BAFANG 300W HUB Motor |
| gears | SHIMANO 7 Speed |
| crank | High Quality Ounce Alloy Crank |
| charge time | 4-6 Hours Full Charge. |
| warranty | 2 Years Complete Bike Warranty. |
| brakes | Custom 4-Piston brakes with cooling fins. |
| weight capacity | 180 kgs Carrying Weight |
| suspension | Industry leading front and rear suspension. |
| bike weight | 45KG including battery |
| battery | 52V 20AH SAMSUNG Lithium-ion Battery. |
| display | Water & Dirt Resistant LCD Colour Display w. Phone Charging. |
| drive mode | Cadence Sensing Pedal Assist 1-9 + Twist Throttle w. Isolator |
| Groupset Brand | Shimano |
| Frame Material | Alloy |
| Fork Material | Alloy |
| Battery Brand | Samsung |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Max Assisted Speed | 45km/h |
| Ride Style | Urban |
| Motor Brand | Bafang |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 7 |
| Motor | 52V BAFANG 300W HUB Motor |
| GEARS | SHIMANO 7 Speed |
| CRANK | High Quality Ounce Alloy Crank |
| Motor Type | Hub-Drive Motor |
| 180kg Capacity | Passenger ready and capable of carrying up to 180kg |
| Frame Style | Step-Over |
| Charge time | 4-6 Hours Full Charge. |
| WARRANTY | 2 Years Complete Bike Warranty. |
| BRAKES | Custom 4-Piston brakes with cooling fins. |
| Weight capacity | 180 kgs Carrying Weight |
| Suspension | Industry leading front and rear suspension. |
| Bike Weight | 45KG including battery |
| Unreal Suspension | The new Fatboy front suspension is an industry first for fat-tire e-bikes |
| Battery | 52V 20AH SAMSUNG Lithium-ion Battery. |
| Display | Water & Dirt Resistant LCD Colour Display w. Phone Charging. |
| 1040Wh Battery | Big power and great range with the 1040Wh / 52V Samsung Battery |
| DRIVE MODE | Cadence Sensing Pedal Assist 1-9 + Twist Throttle w. Isolator |
| UPGRADED BRAKES | Our upgraded braking system uses custom components built specifically for Fatboy bikes |
