Goodbye range anxiety, hello horizon. The eONE-SIXTY 875 marries a full-power drive unit with a user-removable 712 Wh battery and optional 360 Wh range extender, all wrapped up in our durable aluminium frame. With our proven, low-maintenance FAST suspension platform, you can run mixed wheel sizes as standard or switch to full 29" without compromise, while we've combined the no-compromise suspension performance of a RockShox Zeb fork and Super Deluxe shock with Shimano's durable XT Linkglide drivetrain.
With the latest eONE-SIXTY, the next descent is always about to start. With an all-aluminium frame, it offers maximum value and maximum battery range, thanks to a powerful drive unit paired with a removable 712 Wh battery and optional 360 Wh range extender. The only reason to stop will be because you have to. With our incredibly capable geometry derived from the award-winning ONE-SIXTY enduro range, we've got handling that'll help you conquer the toughest climbs as well as the most grin-inducing descents, while our proven FAST kinematic suspension will take care of anything the trail throws at it. This low-maintenance flexstay design offers 174 mm of rear wheel travel to go with 170 mm at the front, with size-tuned progression to maximise performance for all sizes of riders. You can run it with the latest coil shocks without any worries too. With mixed size 29" front and 27.5" rear wheels as standard for playful handling, you can switch to a focused full 29er setup without messing up the geometry, thanks to our flip chip design. With low standover heights across all sizes, you can choose between a longer frame for more stable handling or a shorter one for an agile feel, while some models feature our ground-breaking 30-230 mm travel-adjustable dropper post. *except eONE-SIXTY 400
Features:
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | eONE-SIXTY LITE IV, MAT aluminium, 160 STR, 29x2.6" max. WHS, 148x12 AST |
| shock | Rock Shox Super Deluxe Select |
| fork | Rock Shox ZEB Select, Air, 170 STR, Tapered, 44mm fork offset, 29x2.8" max WHS |
| brake front | Shimano XT, 4 piston |
| brake rear | Shimano XT, 4 piston |
| rotor front | Shimano RT64, 220 mm |
| rotor rear | Shimano RTEM600, 203 mm |
| chain | LG500 |
| crankset | FSA 1x Steel Chainring, 36t |
| crank length | Shimano FC-E8150 165 mm all sizes |
| derailleur rear | Shimano XT RDM8130 LinkGlide 11 |
| cassette | Shimano LG700, 11-50,11 |
| pedal | VP VPE-527 |
| grip | MERIDA EXPERT EC |
| handlebar | MERIDA EXPERT eTR, 780 WHB |
| stem | MERIDA EXPERT eTR II, MAT aluminium, 35 DSH, 0 ASD, Supernova mount |
| stem size | 40 mm all sizes |
| headset | Acros ICR MERIDA EXTERNAL neck w/ Blocklock |
| hub front | Shimano XT, 110x15 WHF, 32 SPH, Centerlock |
| hub rear | Shimano XT, 148x12 WHR, 32 SPH, Centerlock |
| rim | Reynolds 309 Enduro Comp, 30 IWR, MAT aluminium, Tubeless ready (tubeless tape installed), front 29", rear 27.5" |
| saddle | PROXIM ALTIUS Steel, V-mount adapter, incl. MERIDA minitool |
| seat clamp | MERIDA EXPERT |
| seat post | MERIDA TEAM TR II, 34.9 DSP, 0 SSB, all sizes 30-230mm travel |
| shifter front | Shimano SL -MT500-IL |
| shifter rear | Shimano XT M8130 11 |
| tyre front | Maxxis Assegai, 29x2.5 ", fold, TR EXO+ 3C MaxxGrip |
| tyre rear | Maxxis Minion DHR II, 27.5x2.4 ", fold, 3C DD TR MaxxTerra |
| light front | Lezyne Hekto StVZO E350+ Reverse, reverse MERIDA Custom Mount |
| light rear | LEZYNE LED FEMTO USB REAR STVZO |
| drive unit | Shimano EP801, 85Nm |
| battery | Shimano BT-EN817, 712Wh |
| display | Shimano SC-EM800 |
| FRAME | eONE-SIXTY LITE IV, MAT aluminium, 160 STR, 29x2.6" max. WHS, 148x12 AST |
| Shock | Rock Shox Super Deluxe Select |
| Fork | Rock Shox ZEB Select, Air, 170 STR, Tapered, 44mm fork offset, 29x2.8" max WHS |
| Brake Front | Shimano XT, 4 piston |
| Brake Rear | Shimano XT, 4 piston |
| ROTOR FRONT | Shimano RT64, 220 mm |
| ROTOR REAR | Shimano RTEM600, 203 mm |
| Chain | LG500 |
| Crankset | FSA 1x Steel Chainring, 36t |
| Crank Length | Shimano FC-E8150 165 mm all sizes |
| DERAILLEUR REAR | Shimano XT RDM8130 LinkGlide 11 |
| Cassette | Shimano LG700, 11-50,11 |
| PEDAL | VP VPE-527 |
| Grip | MERIDA EXPERT EC |
| Handlebar | MERIDA EXPERT eTR, 780 WHB |
| Stem | MERIDA EXPERT eTR II, MAT aluminium, 35 DSH, 0 ASD, Supernova mount |
| Stem Size | 40 mm all sizes |
| Headset | Acros ICR MERIDA EXTERNAL neck w/ Blocklock |
| Hub Front | Shimano XT, 110x15 WHF, 32 SPH, Centerlock |
| Hub Rear | Shimano XT, 148x12 WHR, 32 SPH, Centerlock |
| Rim | Reynolds 309 Enduro Comp, 30 IWR, MAT aluminium, Tubeless ready (tubeless tape installed), front 29", rear 27.5" |
| Saddle | PROXIM ALTIUS Steel, V-mount adapter, incl. MERIDA minitool |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | MERIDA TEAM TR II, 34.9 DSP, 0 SSB, all sizes 30-230mm travel |
| SHIFTER FRONT | Shimano SL -MT500-IL |
| SHIFTER REAR | Shimano XT M8130 11 |
| Tyre Front | Maxxis Assegai, 29x2.5 ", fold, TR EXO+ 3C MaxxGrip |
| Tyre Rear | Maxxis Minion DHR II, 27.5x2.4 ", fold, 3C DD TR MaxxTerra |
| LIGHT FRONT | Lezyne Hekto StVZO E350+ Reverse, reverse MERIDA Custom Mount |
| LIGHT REAR | LEZYNE LED FEMTO USB REAR STVZO |
| DRIVE UNIT | Shimano EP801, 85Nm |
| Battery | Shimano BT-EN817, 712Wh |
| Display | Shimano SC-EM800 |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | XT |
| Fork Brand | Rockshox |
| Motor Brand | Shimano |
| Max Assisted Speed | 25km/h |
| Battery Brand | Shimano |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 1 x 11 |
| Ride Style | Enduro |
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
