The ONE-SIXTY 700 gets all the cutting edge enduro performance of our radical test and award-winning design but with a high-value and fully featured all-aluminium frame. That means hard-hitting modern geometry with our FAST kinematic suspension that delivers a chaos taming ride alongside quality RockShox suspension. SRAM’s proven 12-speed wide-range drivetrain means reliable shifts time after time, while four-piston brakes make short work of keeping everything under control.
Evolution or revolution? How about both? The ONE-SIXTY is a radical, award-winning design that pushes our hard-hitting enduro platform to new heights. Just as well, because once it’s there it’s ready to rip the longest, toughest descents too. Our proven suspension system uses a flexstay design with an adjustable rocker, so whether you choose to run it as a full 29er (162 mm travel) or mixed 29/27.5” setup (171 mm travel), the geometry is preserved. There’s a radically steep 79° seat tube angle for goat-like climbing and slack 64° head angle plus 170 mm fork to deal with downhill trail chaos. Our AGILOMETER sizing allows riders to run a longer or shorter reach frame independently of their height, while suspension becomes more progressive as you size up, all with long-travel dropper posts. WIRE PORT cable routing plus reliable threaded bottom bracket round out the package, while carbon frames offer on-board tool storage and FidLock magnetic bottle cages.
Features:
| frame | ONE-SIXTY LITE III, 171 STR mullet / 162 STR 29", MAT aluminium, 29x2.5" max. WHS, 148x12 AST, BSA BBR, |
| shock | Rock Shox Vivid Select, platform |
| fork | Rock Shox Zeb Select, Air, 170 STR, Tapered, 44mm fork offset, 29x2.6" max. WHS, |
| brake front | Sram Maven, 4 piston |
| brake rear | Sram Maven, 4 piston |
| rotor front | Sram CenterLine, 200mm |
| rotor rear | Sram CenterLine, 200mm |
| chain | Sram Eagle 70 Transmission, Flattop |
| crankset | Sram Eagle 70 Transmission, 32t, 1 guard, |
| crank length | 165 mm for all sizes, |
| bb set | Sram DUB BSA 73 MTB Wide, |
| derailleur rear | Sram Eagle 90 Transmission, T-Type |
| cassette | Sram XS-1270 Eagle Transmission, 11-52t, 12sp |
| handlebar | MERIDA EXPERT TR II, MAT aluminium, 780 WHB, 30 RHB |
| stem | MERIDA EXPERT eTRII, MAT aluminium, 35 DSH, 0 ASD |
| stem size | 40 mm, |
| headset | Acros ICR MERIDA EXTERNAL neck, Upper and lower IPS sealing |
| hub front | Shimano TC500-B, 110x15 WHF, 32 SPH, Centerlock |
| hub rear | Shimano TC600-HM-B, 148x12 WHR, 32 SPH, Centerlock |
| rim | Reynolds 309 Enduro Comp, 30 IWR, MAT aluminium, Tubeless ready (tubeless tape installed), rear 27.5" up to Size M / L & XL rear full 29", |
| saddle | MERIDA COMP SL, 25% recycled material, V-mount, incl. MERIDA minitool |
| seat clamp | MERIDA EXPERT, |
| shifter front | Sram Dropper Lever MMX, |
| shifter rear | Sram Eagle 90 Transmission MMX, |
| tyre front | Continental Kryptotal-F, 29x2.4", fold, TR, Enduro casing, Soft compund, |
| tyre rear | Continental Kryptotal-R, 27.5x2.4" XS/S/M 29x2.4" L/XL, fold, Enduro casing, soft compound, |
| FRAME | ONE-SIXTY LITE III, 171 STR mullet / 162 STR 29", MAT aluminium, 29x2.5" max. WHS, 148x12 AST, BSA BBR, |
| Shock | Rock Shox Vivid Select, platform |
| Fork | Rock Shox Zeb Select, Air, 170 STR, Tapered, 44mm fork offset, 29x2.6" max. WHS, |
| Brake Front | Sram Maven, 4 piston |
| Brake Rear | Sram Maven, 4 piston |
| ROTOR FRONT | Sram CenterLine, 200mm |
| ROTOR REAR | Sram CenterLine, 200mm |
| Chain | Sram Eagle 70 Transmission, Flattop |
| Crankset | Sram Eagle 70 Transmission, 32t, 1 guard, |
| Crank Length | 165 mm for all sizes, |
| BB Set | Sram DUB BSA 73 MTB Wide, |
| DERAILLEUR REAR | Sram Eagle 90 Transmission, T-Type |
| Cassette | Sram XS-1270 Eagle Transmission, 11-52t, 12sp |
| Handlebar | MERIDA EXPERT TR II, MAT aluminium, 780 WHB, 30 RHB |
| Stem | MERIDA EXPERT eTRII, MAT aluminium, 35 DSH, 0 ASD |
| Stem Size | 40 mm, |
| Headset | Acros ICR MERIDA EXTERNAL neck, Upper and lower IPS sealing |
| Hub Front | Shimano TC500-B, 110x15 WHF, 32 SPH, Centerlock |
| Hub Rear | Shimano TC600-HM-B, 148x12 WHR, 32 SPH, Centerlock |
| Rim | Reynolds 309 Enduro Comp, 30 IWR, MAT aluminium, Tubeless ready (tubeless tape installed), rear 27.5" up to Size M / L & XL rear full 29", |
| Saddle | MERIDA COMP SL, 25% recycled material, V-mount, incl. MERIDA minitool |
| SEAT CLAMP | MERIDA EXPERT, |
| SHIFTER FRONT | Sram Dropper Lever MMX, |
| SHIFTER REAR | Sram Eagle 90 Transmission MMX, |
| Tyre Front | Continental Kryptotal-F, 29x2.4", fold, TR, Enduro casing, Soft compund, |
| Tyre Rear | Continental Kryptotal-R, 27.5x2.4" XS/S/M 29x2.4" L/XL, fold, Enduro casing, soft compound, |
| Frame Material | Alloy |
| Fork Material | Alloy |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Groupset Model | NX Eagle |
| Fork Brand | Rockshox |
| Fork Travel | 141 - 170mm |
| Shock Travel | 141 - 170mm |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Downhill |
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
