GRAVEL RIDING
Fully loaded bike-packing, fast and light off-road adventures, gravel and CX racing… or simply exploring your favorite tracks and trails. The Headlands is a high-tech, high-spec carbon fiber gravel and adventure bike that’s made to be lightning-fast, confidence-inspiring and super comfortable on all surfaces.
We’ve taken our own unidirectional carbon fiber frame, added mountain bike-inspired geometry, loads of tire clearance and a whole heap of mounting points for gear and fenders to create a super versatile, super capable all-terrain dart of a bike. Go 700c with room for up to 45mm tires or 650b up to 47mm.
The Headlands 2 is our no-compromise, top-spec, top-performance gravel and adventure bike.
Gravel-specific Shimano GRX 12-speed drivetrain, 45mm Vee Tire Co tires and Marin wheels and finishing kit all add up to a whole mountain of fun and adventure. Last but not least, we’ve added a TranzX dropper seat post to really push you and your Headlands’ limits on the trails.
| stem | Marin 3D Forged Alloy |
| pedals | - |
| chain | KMC X12 |
| fork | Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets |
| headset | FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” |
| derailleur front | - |
| tires | Vee Tire Co., QuikStyk, 700x45,Folding Bead, Tubeless Compatible |
| spokes nipples | Double Butted Stainless |
| handlebar | Marin Butted Alloy, Compact 16ş Flared Drop |
| grips | Marin Shock Absorbing Tape |
| seatpost | TranzX YSP38J, Size 49-54 70mm, Size 56-60 110mm Travel, 27.2mm |
| saddle | Marin Beyond Road Concept Elite |
| extras | Bear Box Storage Bag |
| frame | Unidirectional Carbon Beyond Road Platform, 1x Drivetrain Specific, 700c x 50mm Compatible, Flat Mount Disc, 142x12mm Thru-Axle, UDH Dropout, Internal Housing Routing, Mudguard and Rear Carrier Mounti |
| rim | Marin Aluminum Double Wall, 21mm Inner, 21mm Tall, Disc Specific, Tubeless Compatible |
| hub rear | Forged Aluminum Alloy, Disc, 28H |
| hub front | Forged Aluminum Alloy, Disc, 28H |
| derailleur rear | Shimano GRX RDX822, 12-Speed, Shadow Plus w/ Clutch |
| shift lever | Shimano GRX RX820, 12-Speed |
| crankset | Shimano GRX FCRX8020, 1x12, HollowTech 2, 42T |
| bottom bracket | Shimano BB-RS500, BSA, Sealed Cartridge Bearings |
| cassette | Shimano CSM7100, 12-Speed, 10-51T |
| brakes front | Shimano GRX, RX820, Hydraulic Disc, 160mm Rotor |
| brakes rear | Shimano GRX, RX820, Hydraulic Disc, 160mm Rotor |
| brake levers | Shimano GRX w/ Integrated Shifter |
| Stem | Marin 3D Forged Alloy |
| Frame Material | Carbon |
| Fork Material | Carbon |
| Groupset Brand | Shimano |
| Shifting Type | Mechanical |
| Pedals Included | No |
| PEDALS | - |
| Ride Style | Gravel |
| Chain | KMC X12 |
| Groupset Model | GRX |
| Fork | Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets |
| Headset | FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 12 |
| DERAILLEUR FRONT | - |
| Tires | Vee Tire Co., QuikStyk, 700x45,Folding Bead, Tubeless Compatible |
| Spokes Nipples | Double Butted Stainless |
| Handlebar | Marin Butted Alloy, Compact 16ş Flared Drop |
| GRIPS | Marin Shock Absorbing Tape |
| Seatpost | TranzX YSP38J, Size 49-54 70mm, Size 56-60 110mm Travel, 27.2mm |
| Saddle | Marin Beyond Road Concept Elite |
| EXTRAS | Bear Box Storage Bag |
| FRAME | Unidirectional Carbon Beyond Road Platform, 1x Drivetrain Specific, 700c x 50mm Compatible, Flat Mount Disc, 142x12mm Thru-Axle, UDH Dropout, Internal Housing Routing, Mudguard and Rear Carrier Mounti |
| Rim | Marin Aluminum Double Wall, 21mm Inner, 21mm Tall, Disc Specific, Tubeless Compatible |
| Hub Rear | Forged Aluminum Alloy, Disc, 28H |
| Hub Front | Forged Aluminum Alloy, Disc, 28H |
| DERAILLEUR REAR | Shimano GRX RDX822, 12-Speed, Shadow Plus w/ Clutch |
| Shift Lever | Shimano GRX RX820, 12-Speed |
| Crankset | Shimano GRX FCRX8020, 1x12, HollowTech 2, 42T |
| Bottom Bracket | Shimano BB-RS500, BSA, Sealed Cartridge Bearings |
| Cassette | Shimano CSM7100, 12-Speed, 10-51T |
| Brakes Front | Shimano GRX, RX820, Hydraulic Disc, 160mm Rotor |
| Brakes Rear | Shimano GRX, RX820, Hydraulic Disc, 160mm Rotor |
| Brake Levers | Shimano GRX w/ Integrated Shifter |
