Room for up to 56 mm/2.2″ tires let your customers tackle the gnarly stuff with confidence.
The CheckOUT’s all-new Gravel Adventure geo increases stability and comfort on multi-surface, multi-day adventures.
Your fast-and-far customers can pack heavy and still ride light with a 500 Series OCLV carbon frame tested to robust MTB standards.
The CheckOUT SL 5 is an adventure-ready full-suspension gravel bike for getting far, far out there. Its carbon frame delivers 55 mm of rear travel from a RockShox SIDluxe IsoStrut shock, while a RockShox Rudy XL fork smooths rowdy roads and trails with 60 mm of travel. It comes ready to explore with Bontrager Paradigm Comp wheels, a 12-speed Shimano GRX drivetrain and TranzX dropper post.
Built for bikepacking
Haul it all with 18* frame mounts, an integrated rear rack that works with the bike's suspension and dropper post, and Adjustable Multi-Mounts that let riders position bottles and gear exactly where
they want ‘em. *size ML and up
The ultimate off-road drop bar
The CheckOUT is designed to be faster than a mountain bike on tarmac roads and champagne gravel thanks to a new GR CheckOUT drop bar that’s quick on the hoods and has an extra wide flare and ergonomic back sweep for more comfort and control.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | 500 Series OCLV Carbon, integrated frame bag mounts, integrated rack, T47, UDH, 142x12 mm chamfered thru axle, 55 mm travel |
| fork | RockShox Rudy XL Ultimate, Charger Race Day 2 Solo Air spring, tapered steerer, 45 mm offset, 12x100 mm thru axle, 60 mm travel |
| shock | RockShox SIDluxe Ultimate 3P, 170 mm x 27.5 mm |
| weight | ML - 12.74 kg / 28.09 lbs (with TLR sealant, no tubes, excluding rear rack) |
| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| shifter | Shimano GRX RX820, 12-speed |
| rear derailleur | Shimano GRX RX822, 51T max cog |
| crank | Shimano GRX RX610, 38T, 160 mm length (S) / 170 mm length (M, ML) / 172.5 mm length (L, XL) |
| bottom bracket | Praxis, T47 threaded, internal bearing |
| cassette | Shimano XT M8200, 10-51, 12-speed |
| chain | Shimano XT M8100, 12-speed |
| max. chainring size | 1x - 38T |
| wheel front | Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle |
| wheel rear | Bontrager Paradigm Comp 25, Tubeless-Ready, 25 mm rim width, SRAM XD-R 12-speed freehub, 142x12 thru axle |
| skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| tyre | Bontrager Betasso RSL GX, Tubeless ready, aramid bead, 60 tpi, 700x50 mm |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| rim strip | Bontrager TLR |
| max tyre size | 56 mm/2.20" (as measured, see manual for details) |
| saddle | Verse Short Comp, steel rails, 145 mm width |
| seatpost | TranzX JD-YSI36, 100 mm travel, internal routing, 31.6 mm, 328 mm length |
| handlebar | Bontrager GR Checkout, 42 cm (S) / 44 cm (M, ML, L) / 48 cm (XL) |
| handlebar tape | Bontrager Supertack Perf tape |
| stem | Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length (S, M) / 70 mm length (ML, L) / 80 mm length (XL) |
| brake rotor | Shimano CL800, CentreLock, 160 mm |
| cargo rack | Checkout rear rack |
| FRAME | 500 Series OCLV Carbon, integrated frame bag mounts, integrated rack, T47, UDH, 142x12 mm chamfered thru axle, 55 mm travel |
| Fork | RockShox Rudy XL Ultimate, Charger Race Day 2 Solo Air spring, tapered steerer, 45 mm offset, 12x100 mm thru axle, 60 mm travel |
| Shock | RockShox SIDluxe Ultimate 3P, 170 mm x 27.5 mm |
| Weight | ML - 12.74 kg / 28.09 lbs (with TLR sealant, no tubes, excluding rear rack) |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Shifter | Shimano GRX RX820, 12-speed |
| Rear Derailleur | Shimano GRX RX822, 51T max cog |
| CRANK | Shimano GRX RX610, 38T, 160 mm length (S) / 170 mm length (M, ML) / 172.5 mm length (L, XL) |
| Bottom Bracket | Praxis, T47 threaded, internal bearing |
| Cassette | Shimano XT M8200, 10-51, 12-speed |
| Chain | Shimano XT M8100, 12-speed |
| Max. chainring size | 1x - 38T |
| Wheel Front | Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle |
| Wheel Rear | Bontrager Paradigm Comp 25, Tubeless-Ready, 25 mm rim width, SRAM XD-R 12-speed freehub, 142x12 thru axle |
| Skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| Tyre | Bontrager Betasso RSL GX, Tubeless ready, aramid bead, 60 tpi, 700x50 mm |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Rim strip | Bontrager TLR |
| MAX TYRE SIZE | 56 mm/2.20" (as measured, see manual for details) |
| Saddle | Verse Short Comp, steel rails, 145 mm width |
| Seatpost | TranzX JD-YSI36, 100 mm travel, internal routing, 31.6 mm, 328 mm length |
| Handlebar | Bontrager GR Checkout, 42 cm (S) / 44 cm (M, ML, L) / 48 cm (XL) |
| HANDLEBAR TAPE | Bontrager Supertack Perf tape |
| Stem | Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length (S, M) / 70 mm length (ML, L) / 80 mm length (XL) |
| BRAKE ROTOR | Shimano CL800, CentreLock, 160 mm |
| Cargo rack | Checkout rear rack |
| Frame Material | Carbon |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | GRX |
| Fork Brand | Rockshox |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Gravel |
| Massive tyre clearance | Room for up to 56 mm/2.2″ tires let your customers tackle the gnarly stuff with confidence. |
| Confidence-inspiring geometry | The CheckOUT’s all-new Gravel Adventure geo increases stability and comfort on multi-surface, multi-day adventures. |
| Trail-tested carbon frame | Your fast-and-far customers can pack heavy and still ride light with a 500 Series OCLV carbon frame tested to robust MTB standards. |
