Say yes to adventure with the Checkpoint+ SL electric gravel bike. No more stopping where the road surface ends. No more opting out of the scenic route. No mo’ FOMO. Get all the tyre clearance, mounts and capability you need for long gravel adventures, plus an ultra-quiet, lightweight TQ motor with a natural-feeling 28 mph (45 km/h) assist to help you venture even further. Plus, a carbon frame with IsoSpeed comfort tech helps you roll smoothly over the rough stuff.
The Checkpoint+ SL 5 is an electric gravel bike built to take you the distance. You get a TQ HPR60 motor with a smooth and quiet boost and a 360 Wh battery that keeps going on your biggest rides. It comes ready to roll with an OCLV Carbon frame, durable alloy wheels, 12-speed Shimano GRX 1x shifting and endurance geometry to keep you comfortable for the long haul.
Powerful and discreet e-system
The industry-leading TQ HPR 60 harmonic pin ring motor is super efficient with an amazing range-to-weight-to-speed ratio. It's ultra-compact, whisper-quiet and offers a natural-feeling assist up to 28 mph (45 kph in New Zealand) with 50 miles of range (in Eco mode). Plus, choose how much boost you get and when you get it with three assist modes.
Optional Range Extender
Explore even further with an optional 160 Wh Range Extender that fits neatly in your bottle cage and gives you an extra 44% more range.
Road-smoothing IsoSpeed
IsoSpeed technology soaks up fatiguing bumps in the road so you can ride stronger longer.
Relaxed Gravel Endurance geometry
Confident and comfortable Gravel Endurance geometry puts you in a more relaxed upright riding position to tackle even the most epic, all-day adventures.
Big ol' tyre clearance
Room for tyres of up to 50 mm wide (as measured) lets you roll right over the big stuff.
Mounts to haul it all
Carry everything you need with mounts on the frame and fork for front and rear racks, mudguards and Adventure Frame and Triangle Bags. Plus, the Checkpoint+ was designed to fit extra hydration in additon to all your bags.
Compatible with a suspension fork and dropper post
Add a suspension fork with up to 40 mm of travel and a dropper post so you can send it with more comfort and confidence. Or opt for the Checkpoint+ SL 7, which already comes equipped with a suspension fork. *Suspension fork available on all sizes except XS
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | 500 Series OCLV Carbon, TQ drive system, tapered head tube, IsoSpeed, internal routing, flat-mount disc, mudguard mounts, UDH, 142x12 mm chamfered thru axle |
| fork | Checkpoint full carbon, tapered carbon steerer, mudguard mounts, triple rack mounts, flat-mount disc, 12x100 mm chamfered thru axle |
| weight | ML - 13.81 kg / 30.45 lbs (with TLR sealant, no tubes) |
| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| battery | TQ 360Wh |
| charger | TQ 4A charger |
| computer | TQ LED display with Bluetooth & ANT+ connectivity |
| motor | TQ-HPR60, 60 Nm, 250 watt maximum continuous rated power, 350 watt peak power |
| e-bike classification | Class 3 |
| shifter | Shimano GRX RX820, 12-speed |
| rear derailleur | Shimano GRX RX822, 51T max cog |
| crank | Praxis Alloy, 165 mm (XS, S) / 170 mm (M, ML) / 172.5 mm (L, XL) |
| cassette | Shimano XT M8100, 10-51, 12-speed |
| chain | Shimano XT M8100, 12-speed |
| max. chainring size | 1x 44T |
| wheel front | Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle |
| wheel rear | Bontrager Paradigm Comp 25, Tubeless-Ready, 25 mm rim width, Shimano Micro Spline freehub, 142x12 thru axle |
| skewer front | Bontrager Switch chamfered thru axle |
| skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| tyre | Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42 mm |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| rim strip | Bontrager TLR |
| max tyre size | 50 mm without mudguards, 42 mm with mudguards (as measured, see manual for details) |
| saddle | Verse Short Comp, steel rails, 145 mm width |
| seatpost | Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length |
| handlebar | Bontrager Elite Gravel, alloy, 40 cm (XS, S) / 42 cm (M, ML) / 44 cm (L) / 46 cm (XL) |
| handlebar tape | Bontrager Supertack Perf tape |
| stem | Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm (XS) / 80 mm (S, M) / 90mm (ML, L) / 100mm (XL) |
| brake rotor | Shimano CL800, CentreLock, 160 mm |
| brake lever | Shimano GRX RX820, 12-speed |
| rotor size | Max brake rotor sizes - 180 mm front and rear |
| FRAME | 500 Series OCLV Carbon, TQ drive system, tapered head tube, IsoSpeed, internal routing, flat-mount disc, mudguard mounts, UDH, 142x12 mm chamfered thru axle |
| Fork | Checkpoint full carbon, tapered carbon steerer, mudguard mounts, triple rack mounts, flat-mount disc, 12x100 mm chamfered thru axle |
| Weight | ML - 13.81 kg / 30.45 lbs (with TLR sealant, no tubes) |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Battery | TQ 360Wh |
| Charger | TQ 4A charger |
| Computer | TQ LED display with Bluetooth & ANT+ connectivity |
| Motor | TQ-HPR60, 60 Nm, 250 watt maximum continuous rated power, 350 watt peak power |
| E-bike Classification | Class 3 |
| Shifter | Shimano GRX RX820, 12-speed |
| Rear Derailleur | Shimano GRX RX822, 51T max cog |
| CRANK | Praxis Alloy, 165 mm (XS, S) / 170 mm (M, ML) / 172.5 mm (L, XL) |
| Cassette | Shimano XT M8100, 10-51, 12-speed |
| Chain | Shimano XT M8100, 12-speed |
| Max. chainring size | 1x 44T |
| Wheel Front | Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle |
| Wheel Rear | Bontrager Paradigm Comp 25, Tubeless-Ready, 25 mm rim width, Shimano Micro Spline freehub, 142x12 thru axle |
| Skewer front | Bontrager Switch chamfered thru axle |
| Skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| Tyre | Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42 mm |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Rim strip | Bontrager TLR |
| MAX TYRE SIZE | 50 mm without mudguards, 42 mm with mudguards (as measured, see manual for details) |
| Saddle | Verse Short Comp, steel rails, 145 mm width |
| Seatpost | Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length |
| Handlebar | Bontrager Elite Gravel, alloy, 40 cm (XS, S) / 42 cm (M, ML) / 44 cm (L) / 46 cm (XL) |
| HANDLEBAR TAPE | Bontrager Supertack Perf tape |
| Stem | Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm (XS) / 80 mm (S, M) / 90mm (ML, L) / 100mm (XL) |
| BRAKE ROTOR | Shimano CL800, CentreLock, 160 mm |
| Brake lever | Shimano GRX RX820, 12-speed |
| Rotor size | Max brake rotor sizes - 180 mm front and rear |
| Frame Material | Carbon |
| Fork Material | Carbon |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | GRX |
| Motor Brand | TQ |
| Max Assisted Speed | 45km/h |
| Battery Brand | TQ |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 2 x 12 |
| Ride Style | Gravel |
