he Checkmate SLR 9 AXS is our fastest and lightest gravel race bike, built to chase podiums down rowdy roads. It combines a lightweight aero design with IsoSpeed road-smoothing tech and new Gravel Race geometry that keeps you poised for the attack without eating up your energy. To keep you at the front of the pack, it's equipped with top-tier parts, like carbon wheels and SRAM's latest ergonomic RED AXS XPLR wireless drivetrain.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| rim strip | Bontrager TLR |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| wheel front | Bontrager Aeolus RSL 37V, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 100 x 12mm thru axle |
| wheel rear | Bontrager Aeolus RSL 37V, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 142 x 12mm thru axle |
| skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| fork | Checkmate SLR full carbon, tapered carbon steerer, hidden mudguard mounts, flat-mount disc, 12x100 mm thru axle |
| tyre | Bontrager Girona RSL GR, Tubeless-Ready, aramid bead, 220 tpi, 700x38 mm |
| handlebar tape | Trek EcoTack |
| battery | SRAM AXS battery pack (with charger) |
| skewer front | Bontrager Switch chamfered thru axle |
| shifter | SRAM RED AXS E1 |
| chain | SRAM RED E1, 12/13-speed |
| saddle | Aeolus RSL, carbon rails, 145 mm width |
| frame | 800 Series OCLV Carbon, IsoSpeed, hidden mudguard mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12 mm chamfered thru axle |
| weight | ML – 7.55 kg/16.65 lb (with TLR sealant, no tubes) |
| rear derailleur | SRAM RED XPLR eTap AXS, 46T max cog |
| cassette | SRAM XG-1391, 10-46T, 13-speed |
| max tyre size | 45 mm without mudguards, 38 mm with mudguards (as measured, see manual for details) |
| seatpost | KVF aero carbon seat post, 5 mm offset, 280 mm length |
| handlebar/stem (integrated) | Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 100 mm stem length |
| brake rotor | SRAM Paceline X, rounded, CentreLock, 160 mm |
| Frame Material | Carbon |
| Fork Material | Carbon |
| Groupset Brand | Sram |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Pedals Included | No |
| Ride Style | Gravel |
| Groupset Model | RED AXS |
| Rim strip | Bontrager TLR |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Wheel Front | Bontrager Aeolus RSL 37V, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 100 x 12mm thru axle |
| Wheel Rear | Bontrager Aeolus RSL 37V, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 142 x 12mm thru axle |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 12 |
| Shifting Type | Electronic |
| Skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| Fork | Checkmate SLR full carbon, tapered carbon steerer, hidden mudguard mounts, flat-mount disc, 12x100 mm thru axle |
| Tyre | Bontrager Girona RSL GR, Tubeless-Ready, aramid bead, 220 tpi, 700x38 mm |
| HANDLEBAR TAPE | Trek EcoTack |
| Battery | SRAM AXS battery pack (with charger) |
| Skewer front | Bontrager Switch chamfered thru axle |
| Shifter | SRAM RED AXS E1 |
| Chain | SRAM RED E1, 12/13-speed |
| Saddle | Aeolus RSL, carbon rails, 145 mm width |
| FRAME | 800 Series OCLV Carbon, IsoSpeed, hidden mudguard mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12 mm chamfered thru axle |
| Weight | ML – 7.55 kg/16.65 lb (with TLR sealant, no tubes) |
| Rear Derailleur | SRAM RED XPLR eTap AXS, 46T max cog |
| Cassette | SRAM XG-1391, 10-46T, 13-speed |
| MAX TYRE SIZE | 45 mm without mudguards, 38 mm with mudguards (as measured, see manual for details) |
| Seatpost | KVF aero carbon seat post, 5 mm offset, 280 mm length |
| Handlebar/stem (integrated) | Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 100 mm stem length |
| BRAKE ROTOR | SRAM Paceline X, rounded, CentreLock, 160 mm |
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
