GRAVEL CRUSHER
Now lighter, smoother and more adaptable to variable conditions and terrain, this reengineered composite gravel bike combines ultra-efficient performance with next-level handling and control.
FAST AND VERSATILE
Lightweight Advanced-grade composite frame and Advanced SL composite fork combine for race-winning efficiency and smooth control. A two-position flip chip on the rear dropout lets you adjust the wheelbase: short for quicker handling, or long for added tire clearance (up to 53mm) and improved stability. You can use the included D-Fuse seatpost for more flex and compliance, or switch to a traditional 30.9mm round seatpost or dropper post.
TUNED COMPLIANCE
Dropped seatstays with small-diameter tubing absorb road shocks and vibrations on all types of gravel. The Contact SLR XR D-Fuse carbon handlebar and D-Fuse SLR seatpost help smooth out rough tracks, improving control and minimizing fatigue over long distances.
SMART INTEGRATION
Internally routed cables offer clean, uncluttered cockpit aesthetics and improved aero performance. An easily accessed storage compartment inside the top tube lets you securely carry tools, snacks and other essentials. And additional integrated mounts on the top tube, fork and rear dropout make it easy to modify with additional packs or fenders. All-new, molded, chainstay and down tube protection help defend the frame against impacts and quell noise.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| pedals | N/A |
| bottom bracket | SRAM DUB, press fit |
| spokes | Sapim Cx-Ray |
| seatpost | Giant D-Fuse SLR, composite, -5/+15mm offset |
| rims | Giant CXR 1 Carbon Disc WheelSystem |
| frame | Advanced-Grade Composite, 12x142mm thru-axle, disc, flip chip dropout |
| fork | Advanced SL-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc |
| hubs | [F] Giant AR alloy, CenterLock, 12mm thru-axle [R] Giant AR alloy, DT350 36t ratchet system, CenterLock, 12mm thru-axle |
| tires | CADEX GX, 700x40c, tubeless |
| saddle | Giant Grit SL |
| shifters | SRAM Force AXS HRD, ED-Force-E1 |
| brake levers | SRAM Force AXS HRD, ED-Force-E1 |
| cassette | SRAM Force E1 XG-1270, 12-speed, 10-36 |
| chain | SRAM Force-E1, 12-speed |
| brakes | SRAM Force AXS HRD, ED-Force-E1, SRAM PaceLine X rotors [F]160mm, [R]160mm |
| extras | Tubeless prepared, 53mm max tyre size in "long" flip chip position, 45mm max tyre size in "short" flip chip position, In frame storage bag |
| max tire clearance | 53mm in "long" position |
| bar tape | Stratus Lite 3.0 |
| front derailleur | SRAM Force AXS Wide D2 |
| rear derailleur | SRAM Force AXS, FD-Force-E-E1 |
| weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are de |
| PEDALS | N/A |
| Frame Material | Carbon |
| Fork Material | Carbon |
| Groupset Brand | Sram |
| Pedals Included | No |
| Groupset Model | Force AXS |
| Bottom Bracket | SRAM DUB, press fit |
| Ride Style | Gravel |
| SPOKES | Sapim Cx-Ray |
| Fork Brand | Giant |
| Seatpost | Giant D-Fuse SLR, composite, -5/+15mm offset |
| RIMS | Giant CXR 1 Carbon Disc WheelSystem |
| FRAME | Advanced-Grade Composite, 12x142mm thru-axle, disc, flip chip dropout |
| Fork | Advanced SL-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 2 x 12 |
| Shifting Type | Electronic |
| HUBS | [F] Giant AR alloy, CenterLock, 12mm thru-axle [R] Giant AR alloy, DT350 36t ratchet system, CenterLock, 12mm thru-axle |
| Tires | CADEX GX, 700x40c, tubeless |
| Saddle | Giant Grit SL |
| Shifters | SRAM Force AXS HRD, ED-Force-E1 |
| Brake Levers | SRAM Force AXS HRD, ED-Force-E1 |
| Cassette | SRAM Force E1 XG-1270, 12-speed, 10-36 |
| Chain | SRAM Force-E1, 12-speed |
| BRAKES | SRAM Force AXS HRD, ED-Force-E1, SRAM PaceLine X rotors [F]160mm, [R]160mm |
| EXTRAS | Tubeless prepared, 53mm max tyre size in "long" flip chip position, 45mm max tyre size in "short" flip chip position, In frame storage bag |
| Max Tire Clearance | 53mm in "long" position |
| Bar tape | Stratus Lite 3.0 |
| Front Derailleur | SRAM Force AXS Wide D2 |
| Rear Derailleur | SRAM Force AXS, FD-Force-E-E1 |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are de |
