Designed for gravel. Ready for anything.
Our Checkpoint SL carbon gravel bike boasts a comfortable geometry, ultra-capable tyre clearance, and plenty of gear storage to take you off the beaten track for solo sightseeing excursions, epic all-day adventures, spontaneous overnighters and everything in-between.
The Checkpoint SL 7 AXS Gen 3 is a carbon gravel bike built to explore the beyond. Its lightweight carbon frame is designed with a Gravel Endurance geometry, tons of mounts and clearance for up to 50 mm tyres (as measured). Plus, IsoSpeed comfort tech helps soak up jarring vibrations so you can float over chatter and potholes. It's decked out with upgrades where you want them most, like carbon wheels and seat post, and a wireless SRAM Force AXS XPLR E1 drivetrain.
IsoSpeed comfort tech
IsoSpeed comfort tech smooths pot holes and fatiguing bumps in the road so you can ride stronger for longer.
New Gravel Endurance geometry
A new confident and comfortable Gravel Endurance geometry puts you in a more relaxed upright riding position so you can stay comfortable on even your most epic adventures.
Big ’ol tyre clearance
Roll over the rough stuff with room to fit gravel tyres up to 50 mm wide (as measured).
Bigger in-frame storage
More internal frame storage and a bigger storage door lets you fit all your flat tools inside your bike so you're always ready for whatever the gravel road throws at you.
Mounts galore
The new Checkpoint SL is equipped to carry everything you need with mounts on the frame and fork for front and rear racks, mudguards and Adventure Top Tube, Frame and Triangle Bags. Plus, the new frame has been optimised to fit extra hydration in addition to all your bags.
Suspension fork and dropper post compatible
The Checkpoint SL is now compatible with dropper posts and suspension forks with up to 40 mm of travel so you can send it on chunkier gravel and steeper descents.
PLEASE NOTE: Bottles, bags and mounts shown in photos not included.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | 500 Series OCLV Carbon, IsoSpeed, downtube storage door, hidden mudguard mounts, rack mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12 mm chamf |
| fork | Trek Checkpoint, full carbon, tapered steerer, rack mounts, mudguard mounts, flat-mount disc, 12x100 mm thru axle |
| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| battery | SRAM AXS battery pack (with charger) |
| shifter | SRAM Force AXS E1 |
| rear derailleur | SRAM Force XPLR AXS, 46T max cog |
| crank | Size - S, XS |
| bottom bracket | SRAM DUB Wide, T47 threaded, internal bearing |
| cassette | SRAM Force XPLR XG-1371, 10-46, 13-speed |
| chain | SRAM Force E1, 12/13-speed |
| max. chainring size | 1x - 44 / 2x - 46/30 |
| wheel front | Bontrager Aeolus Elite 35V, OCLV Carbon, Tubeless-Ready, 35 mm rim depth, 100x12 mm thru axle |
| wheel rear | Bontrager Aeolus Elite 35V, OCLV Carbon, Tubeless-Ready, 35 mm rim depth, SRAM XD-R driver, 142x12 mm thru axle |
| skewer front | Bontrager Switch chamfered thru axle |
| skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| tyre | Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42 mm |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| rim strip | Bontrager TLR |
| max tyre size | 50 mm without mudguards, 42 mm with mudguards (as measured, see manual for details) |
| saddle | Verse Short Elite, hollow magnesium rails, 145 mm width |
| seatpost | Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length |
| handlebar | Bontrager Pro Gravel, 40 cm width (S, XS) / 42 cm width (M, ML) / 44 cm width (L) / 46 cm width (XL) |
| handlebar tape | Bontrager Supertack Perf tape |
| stem | Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length (XS) / 80mm length (S, M) / 90mm length (L, ML) / 100mm length (XL) |
| brake | SRAM Force AXS hydraulic disc, flat mount |
| brake rotor | SRAM CentreLine X, CentreLock, round edge, 160 mm |
| rotor size | Max brake rotor sizes - 180 mm front and rear |
| bag | Bontrager BITS Internal Frame Storage Bag |
| FRAME | 500 Series OCLV Carbon, IsoSpeed, downtube storage door, hidden mudguard mounts, rack mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12 mm chamf |
| Fork | Trek Checkpoint, full carbon, tapered steerer, rack mounts, mudguard mounts, flat-mount disc, 12x100 mm thru axle |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Battery | SRAM AXS battery pack (with charger) |
| Shifter | SRAM Force AXS E1 |
| Rear Derailleur | SRAM Force XPLR AXS, 46T max cog |
| CRANK | Size - S, XS |
| Bottom Bracket | SRAM DUB Wide, T47 threaded, internal bearing |
| Cassette | SRAM Force XPLR XG-1371, 10-46, 13-speed |
| Chain | SRAM Force E1, 12/13-speed |
| Max. chainring size | 1x - 44 / 2x - 46/30 |
| Wheel Front | Bontrager Aeolus Elite 35V, OCLV Carbon, Tubeless-Ready, 35 mm rim depth, 100x12 mm thru axle |
| Wheel Rear | Bontrager Aeolus Elite 35V, OCLV Carbon, Tubeless-Ready, 35 mm rim depth, SRAM XD-R driver, 142x12 mm thru axle |
| Skewer front | Bontrager Switch chamfered thru axle |
| Skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| Tyre | Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42 mm |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Rim strip | Bontrager TLR |
| MAX TYRE SIZE | 50 mm without mudguards, 42 mm with mudguards (as measured, see manual for details) |
| Saddle | Verse Short Elite, hollow magnesium rails, 145 mm width |
| Seatpost | Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length |
| Handlebar | Bontrager Pro Gravel, 40 cm width (S, XS) / 42 cm width (M, ML) / 44 cm width (L) / 46 cm width (XL) |
| HANDLEBAR TAPE | Bontrager Supertack Perf tape |
| Stem | Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length (XS) / 80mm length (S, M) / 90mm length (L, ML) / 100mm length (XL) |
| BRAKE | SRAM Force AXS hydraulic disc, flat mount |
| BRAKE ROTOR | SRAM CentreLine X, CentreLock, round edge, 160 mm |
| Rotor size | Max brake rotor sizes - 180 mm front and rear |
| BAG | Bontrager BITS Internal Frame Storage Bag |
| Frame Material | Carbon |
| Fork Material | Carbon |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | RED AXS |
| Shifting Type | Electronic |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Gravel |
