Marlin 5 is a trail-worthy daily rider that's perfectly suited for everyday adventures, on and off the trail. It features a trail-savvy frame with a suspension fork, 9-speed Shimano CUES shifting and mounts for a rack and kickstand that make it an ideal choice for trail riders or anyone looking for a comfortable, stable commuter with the ruggedness of a real mountain bike.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| pedal | VP-536 nylon platform |
| brake | Shimano MT200 hydraulic disc |
| head set | Semi-integrated, 1-1/8" |
| brake set | Shimano MT200 hydraulic disc |
| hub front | Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
| hub rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| rim | Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve |
| frame | Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew |
| spokes | 14 g stainless steel, black |
| saddle | Bontrager Verse Short, stainless steel rails |
| chain | Shimano LG500 |
| shifter | Shimano U4000, 9-speed |
| rear derailleur | Shimano CUES U4000 |
| cassette | Shimano LINKGLIDE LG300, 11-46, 9-speed |
| seatpost | Bontrager alloy, 31.6 mm, 12 mm offset |
| fork | SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" (XS, S) / 29" wheel (M, ML, L, XL, XXL), 100 mm QR, 100 mm travel |
| skewer rear | Trek Thru-Skew |
| tyre | Bontrager Montrose comp, wire bead, 30 tpi, 27.5x2.40" (XS, S) / 29x2.40" (M, ML, L, XL, XXL) |
| crank | Shimano CUES U4001, 32T, 52mm chain line, 170 mm length (XS , S , M , ML) / 175mm length (L , XL , XXL) |
| bottom bracket | Shimano, 73 mm, threaded cartridge, 122.5 mm spindle |
| handlebar | Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width (XS) / 720 mm width (S) / 750 mm width (M , ML , L , XL , XXL) |
| grips | Trek Line Comp, nylon lock-on |
| stem | Bontrager Comp, 31.8 mm, 7-degree, 35 mm length (XS , S) / 50 mm length (M , ML , L) / 60 mm length (XL) / 70 mm length (XXL) |
| brake rotor | Shimano RT26, 6-bolt, 160 mm / 180 mm |
| weight | M - 15.10 kg / 33.29 lbs |
| Groupset Brand | Shimano |
| Frame Material | Alloy |
| Fork Brand | Suntour |
| Fork Travel | 0 - 100mm |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| PEDAL | VP-536 nylon platform |
| BRAKE | Shimano MT200 hydraulic disc |
| Head Set | Semi-integrated, 1-1/8" |
| BRAKE SET | Shimano MT200 hydraulic disc |
| Ride Style | Sport |
| Hub Front | Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
| Hub Rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| Rim | Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve |
| Fork Material | Suspension |
| FRAME | Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew |
| SPOKES | 14 g stainless steel, black |
| Groupset Model | CUES |
| Saddle | Bontrager Verse Short, stainless steel rails |
| Chain | Shimano LG500 |
| Shifter | Shimano U4000, 9-speed |
| Rear Derailleur | Shimano CUES U4000 |
| Cassette | Shimano LINKGLIDE LG300, 11-46, 9-speed |
| Brake Type | Hydraulic Disc Brake |
| Drivetrain Gearing | 1 x 9 |
| Seatpost | Bontrager alloy, 31.6 mm, 12 mm offset |
| Fork | SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" (XS, S) / 29" wheel (M, ML, L, XL, XXL), 100 mm QR, 100 mm travel |
| Skewer rear | Trek Thru-Skew |
| Tyre | Bontrager Montrose comp, wire bead, 30 tpi, 27.5x2.40" (XS, S) / 29x2.40" (M, ML, L, XL, XXL) |
| CRANK | Shimano CUES U4001, 32T, 52mm chain line, 170 mm length (XS , S , M , ML) / 175mm length (L , XL , XXL) |
| Bottom Bracket | Shimano, 73 mm, threaded cartridge, 122.5 mm spindle |
| Handlebar | Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width (XS) / 720 mm width (S) / 750 mm width (M , ML , L , XL , XXL) |
| GRIPS | Trek Line Comp, nylon lock-on |
| Stem | Bontrager Comp, 31.8 mm, 7-degree, 35 mm length (XS , S) / 50 mm length (M , ML , L) / 60 mm length (XL) / 70 mm length (XXL) |
| BRAKE ROTOR | Shimano RT26, 6-bolt, 160 mm / 180 mm |
| Weight | M - 15.10 kg / 33.29 lbs |
Ordering a bike from Evo? If you choose the option Evo Home Delivery at the checkout your order will be personally delivered to you, by an Evo Crew Member, who will also be able to answer any questions you have about your new bike. If you choose Evo Delivery your bike will be delivered completely built, tuned and ready to ride! We are also able to offer Evo Home Delivery on previously restricted brands such as Giant & Trek!
Our home delivery charge is only $45 for 15km and $2 per km after that.
Free for all orders over $149. Orders under $149 a $8.99 flat shipping & handling fee applies. Order and pay online and collect everything from one of our showrooms. Just select which store you would like to collect from at checkout. Find out more about Click & Collect here.
LEARN MORE
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
