OUTDOOR EXERCISE & DAILY COMMUTER.
Lightweight aluminium hardtail mountain bike for outdoor exercise and every day commuters. The 3 x 7-Speed Shimano Tourney drivetrain lets you cruise over any terrain. The 100mm suspension fork adds some obstacle cushioning, while the disc brakes deliver reliable stopping power in wet and dry. The included standard kickstand and rack mounts, add convenience for your daily commute.
KEY FEATURES
RECREATION POP GEOMETRY
POP geometry engages bigger leg muscle groups for more effective climbing. The rider position on the SE:Series 7 improves traction, front wheel grip and bike control. This means that it also feels more natural, boosting confidence and skill development.
Mechanical Disc Brakes
The SE:Series 7 comes equipped with mechanical disc brakes for strong and reliable stopping power.
Hydroformed alloy frame
Hydroformed tubing, Tapered headtube, T6 - 6061 Aluminium, semi-internal cable routing, dropper post compatible, replaceable derailleur hanger, integrated 40mm direct-mount 2-bolt kickstand mounts, water bottle bosses, 135mm x 10mm QR rear hub spacing, 26, 27.5 & 29" x 2.1" tyre clearance, rack and fender mounts.
3 x 7 Drivetrain
Ample gears for your commute! A chainring guard is also included on all 3x drivetrains to help prevent clothing getting caught.
Quality Suspension Fork
The SE:Series 7 is fitted with purpose chosen 100mm suspension fork - Suntour XCE28 Coil fork with Tapered Steerer. A suspension fork improves comfort and traction on a hardtail mountain bike.
SURFACE ALLOY CONTROL PARTS
All SE:Series bicycles are fitted with Surface quality alloy control parts. This means less weight, more durability and function, and worry free ownership. Ergonomic Grips & Saddle improve comfort by relieving pressure from sensitive areas.
TUBELESS READY, WIDER RIMS & TIRES
Surface Alloy Wheels are pre-taped and tubeless ready from the box. Easy to set up tubeless, just add sealant and inflate to seat.
Water Bottle mounts
SE:Series 7 offers more water bottle mount options. Sizes M-XL have capacity for 2 bottles. (Bottle cages sold separately)
SURFACE CHAIN GUARD
Improves chain stability, helps to prevent chain drop as well as preventing clothing snags.
TYRE CLEARANCE
Designed to easily fit higher volume up to 2.1” tires with plenty of mud clearance. Bigger tires can increase contact area and thus ride comfort, control and grip.
RACK MOUNTS INTEGRATED IN FRAME.
All SE:Series models include mounting points for rear racks, allowing you to haul your gear when you commute/tour. (Rack sold separately)
| frame | Hydroformed tubing, Tapered headtube, T6 - 6061 Aluminium, external cable routing, dropper post compatible, replaceable derailleur hanger, integrated 40mm direct-mount 2-bolt kickstand mounts, water bottle bosses, 135mm x 10mm QR rear hub spacing, 27.5 & |
| headset | Semi-Integrated Threadless Headset, ZS44/28.6, ZS56/30 |
| frame axle spacing | 135x9mm |
| axle specification | QR |
| handlebar | Surface, Alloy, Ø31.8mm, 720~760mm, 9° Backsweep, 30mm Rise |
| fork | SR Suntour XCE28 Coil, 29"x2.1", 100m Travel, Preload Adjuster |
| wheelset | Surface Custom |
| hubs | Front - Joytech Alloy, 32H, 100mm OLD, 115mm QR, 6-bolt Disc / Rear - Joytech Alloy, 32H, 135mm OLD, 170mm QR, 6-bolt Disc, 7-Speed |
| rims | Front - Surface Alloy, 32H, 29" x 25mm, Symmetrical, Tubeless Ready / Rear - Surface Alloy, 32H, 29" x 25mm, Symmetrical, Tubeless Ready |
| tyres | Front - CST 1820, 29x2.10" Wire Bead / Rear - CST 1820, 29x2.10" Wire Bead |
| max tyre size | 2.1" |
| crankset | Shimano Tourney FC-TY301, 42x34x24T, 7-Speed |
| max chainring size | 42x34x24T |
| bottom bracket & type | BSA73 |
| shifter(s) | L Shimano ST-EF41-L Shift/Brake Lever, 3-Speed / Rear - Shimano ST-EF41-7R Shift/Brake Lever, 7-Speed |
| front derailleur | Shimano Tourney FD-TY600-L6, Top-Swing, 3-Speed |
| rear derailleur | Shimano Tourney RD-TY300, 6/7-Speed |
| cassette | Shimano MF-TZ510-7 Freewheel, 7-Speed, 14-28T |
| chain | KMC Z7 |
| brakes | Shimano BR-M375 Mechanical/Cable Disc, Resin Pads |
| rotors | Front - Shimano SM-RT26 Rotor, 180mm / Rear - Shimano SM-RT26 Rotor, 160mm |
| grips | Surface Single Density, 120mm |
| stem | Surface, Alloy, Ø31.8mm, ±3° Rise, 45mm Extension |
| saddle | Surface |
| seat post | Surface Alloy, Ø30.9mm |
| seatpost clamp | Alloy, 35mm, QR Clamp |
| pedals | One Piece PP, Black |
| bike weight | 16.5 Kg |
| rider weight limit | 120kg - combined weight of bike and rider (including all kit). |
| FRAME | Hydroformed tubing, Tapered headtube, T6 - 6061 Aluminium, external cable routing, dropper post compatible, replaceable derailleur hanger, integrated 40mm direct-mount 2-bolt kickstand mounts, water bottle bosses, 135mm x 10mm QR rear hub spacing, 27.5 & |
| Headset | Semi-Integrated Threadless Headset, ZS44/28.6, ZS56/30 |
| FRAME AXLE SPACING | 135x9mm |
| AXLE SPECIFICATION | QR |
| Handlebar | Surface, Alloy, Ø31.8mm, 720~760mm, 9° Backsweep, 30mm Rise |
| Fork | SR Suntour XCE28 Coil, 29"x2.1", 100m Travel, Preload Adjuster |
| Wheelset | Surface Custom |
| HUBS | Front - Joytech Alloy, 32H, 100mm OLD, 115mm QR, 6-bolt Disc / Rear - Joytech Alloy, 32H, 135mm OLD, 170mm QR, 6-bolt Disc, 7-Speed |
| RIMS | Front - Surface Alloy, 32H, 29" x 25mm, Symmetrical, Tubeless Ready / Rear - Surface Alloy, 32H, 29" x 25mm, Symmetrical, Tubeless Ready |
| TYRES | Front - CST 1820, 29x2.10" Wire Bead / Rear - CST 1820, 29x2.10" Wire Bead |
| MAX TYRE SIZE | 2.1" |
| Crankset | Shimano Tourney FC-TY301, 42x34x24T, 7-Speed |
| MAX CHAINRING SIZE | 42x34x24T |
| BOTTOM BRACKET & TYPE | BSA73 |
| Shifter(s) | L Shimano ST-EF41-L Shift/Brake Lever, 3-Speed / Rear - Shimano ST-EF41-7R Shift/Brake Lever, 7-Speed |
| Front Derailleur | Shimano Tourney FD-TY600-L6, Top-Swing, 3-Speed |
| Rear Derailleur | Shimano Tourney RD-TY300, 6/7-Speed |
| Cassette | Shimano MF-TZ510-7 Freewheel, 7-Speed, 14-28T |
| Chain | KMC Z7 |
| BRAKES | Shimano BR-M375 Mechanical/Cable Disc, Resin Pads |
| Rotors | Front - Shimano SM-RT26 Rotor, 180mm / Rear - Shimano SM-RT26 Rotor, 160mm |
| GRIPS | Surface Single Density, 120mm |
| Stem | Surface, Alloy, Ø31.8mm, ±3° Rise, 45mm Extension |
| Saddle | Surface |
| SEAT POST | Surface Alloy, Ø30.9mm |
| Seatpost Clamp | Alloy, 35mm, QR Clamp |
| PEDALS | One Piece PP, Black |
| Bike Weight | 16.5 Kg |
| Rider weight limit | 120kg - combined weight of bike and rider (including all kit). |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Mechanical Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | Tourney |
| Fork Brand | Suntour |
| Fork Travel | 0 - 100mm |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 3 x 7 |
| Ride Style | Sport |
