Built for City Trails and First Adventures
The Evo Hardtail MTB is your perfect entry into the world of mountain biking. Designed for recreational riders and everyday adventurers, it’s ideal for navigating local trails, gravel paths, and urban shortcuts. With a lightweight alloy frame, reliable Shimano 2x8 drivetrain, and confidence-inspiring hydraulic disc brakes, this bike is ready for anything from weekend rides to after-work trail laps.
Whether you're exploring your first green-grade trail or commuting with style, the Evo MTB blends comfort, performance, and unbeatable value.
Key features:
| frame | Alloy disc brake |
| fork | Suntour SF23-XCM32-DS NLO disc 27.5, 100mm, coil with preload adjuster and hydraulic speed lockout |
| head set | Alloy cone, threadless, semi-integrated, 44/56mm, 1-1/8" |
| handle bar | Alloy riser, 740mm, 20mm, 6deg, 31.8mm clamp |
| stem | Alloy, 45mm, 3deg, 1-1/8", 31.8mm clamp |
| grips | Gel black, 130/130 close end |
| saddle | Black steel rail, w/o clamp |
| seat post | Alloy/alloy clamp, 27.2mm, 350mm with min.insertion laser mark |
| seat clamp | Alloy, 31.8mm |
| crankset | Prowheel 9sp, 170mm, alloy, 36x22, steel |
| bottom bracket | Alloy body, steel/steel(cup), cartridge sealed bearing, square, 68mmx122.5mm |
| pedal | Black/black cage with reflector |
| chain | KMC 1/2"x3/32", 12000link, w/ connector link |
| cassette | Shimano CS-HG200-8 8 sp, sprocket, 12-32T |
| shifting lever left | Shimano SL-M315-2L Altus 2sp, flat bar, rapid fire shifter |
| shifting lever right | Shimano SL-M315-8R Altus 8sp, flat bar, rapid fire shifter |
| front derailleur | Shimano FD-M315-TS Altus 7/8sp, for double, 14-36T, dual pull, top swing |
| rear derailleur | Shimano Altus RD-M310-L 7/8-sp |
| tires | Maxxis Rekon wire bead (27.5) 27.5x2.25 / (29) 29x2.25, 60TPI |
| front brake | Tektro HD-M275 hydraulic disc, alloy, metal pad (w/o fin) |
| rear brake | Tektro HD-M275 hydraulic disc, alloy, metal pad (w/o fin) |
| disc rotors | 6 bolts, 160mm |
| FRAME | Alloy disc brake |
| Fork | Suntour SF23-XCM32-DS NLO disc 27.5, 100mm, coil with preload adjuster and hydraulic speed lockout |
| Head Set | Alloy cone, threadless, semi-integrated, 44/56mm, 1-1/8" |
| HANDLE BAR | Alloy riser, 740mm, 20mm, 6deg, 31.8mm clamp |
| Stem | Alloy, 45mm, 3deg, 1-1/8", 31.8mm clamp |
| GRIPS | Gel black, 130/130 close end |
| Saddle | Black steel rail, w/o clamp |
| SEAT POST | Alloy/alloy clamp, 27.2mm, 350mm with min.insertion laser mark |
| SEAT CLAMP | Alloy, 31.8mm |
| Crankset | Prowheel 9sp, 170mm, alloy, 36x22, steel |
| Bottom Bracket | Alloy body, steel/steel(cup), cartridge sealed bearing, square, 68mmx122.5mm |
| PEDAL | Black/black cage with reflector |
| Chain | KMC 1/2"x3/32", 12000link, w/ connector link |
| Cassette | Shimano CS-HG200-8 8 sp, sprocket, 12-32T |
| Shifting lever left | Shimano SL-M315-2L Altus 2sp, flat bar, rapid fire shifter |
| Shifting lever right | Shimano SL-M315-8R Altus 8sp, flat bar, rapid fire shifter |
| Front Derailleur | Shimano FD-M315-TS Altus 7/8sp, for double, 14-36T, dual pull, top swing |
| Rear Derailleur | Shimano Altus RD-M310-L 7/8-sp |
| Tires | Maxxis Rekon wire bead (27.5) 27.5x2.25 / (29) 29x2.25, 60TPI |
| Front Brake | Tektro HD-M275 hydraulic disc, alloy, metal pad (w/o fin) |
| Rear Brake | Tektro HD-M275 hydraulic disc, alloy, metal pad (w/o fin) |
| Disc rotors | 6 bolts, 160mm |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | Altus |
| Fork Brand | Suntour |
| Fork Travel | 0 - 100mm |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 2 x 8 |
| Ride Style | Sport |
