Feel the Rifty Love!
Our take on the ultimate do-it-all trail bike, the Marin Rift Zone is made to party, whatever your jam might be. Your ideal partner for everything from all-day epics, to local shred laps to big mountain adventures, the Rifty is Made For Fun.
The Rift Zone features 130mm of rear travel, a lightweight aluminum frame and our super-plush MultiTrac suspension platform for endless good times on the trails. Available with either 27.5" or 29" wheels, depending on frame size, ensuring the perfect balance of playfulness and efficiency. This bike comes with 29" wheels.*
The Marin Rift Zone 1 is your gateway to the Rifty family, made to push the limits of your riding but not your bank balance. It's built with super reliable X-Fusion suspension, an X-Fusion Manic dropper post, grippy Vee Crown Gem tires, plenty of Shimano and a hand-picked selection of our favorite Marin components.
| frame | Series 3 6061 Aluminum, 130mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB w/ ISCG05 Tabs |
| fork | X-Fusion Slide (29") or Sweep (27.5") Boost RC, 140mm Travel, Compression and Rebound Adjustment, 44mm Offset |
| shock | X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom |
| rims | Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible |
| hub rear | Shimano HB-MT200B, 141 QR, Centerlock, Standard Freehub Body |
| hub front | Shimano HF-MT400B, 110x15mm, Centerlock |
| spokes | 14g Black Stainless Steel |
| tires | Vee Tire Co. Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless Compatible |
| derailleur rear | Shimano Deore, 11-Speed, SGS |
| shift lever | Shimano Deore, 11-Speed, SL-5100R |
| crankset | Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing |
| bottom bracket | External Sealed Cartridge Bearing |
| chain | KMC X-11 Silver and Black |
| cassette | Sunrace, 11-Speed, 11-51T, ED Black |
| brakes front | Tektro HD-M280 Hydraulic, 180mm Rotor |
| brakes rear | Tektro HD-M280 Hydraulic, 180mm Rotor |
| brake levers | Tektro HD-M280 |
| handlebar | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back |
| stem | Marin 3D Forged Alloy, 35mm |
| grips | Marin MTN, Closed End |
| headset | FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| seatpost | X-Fusion Manic, 1x Composite Remote, Size XS-S 150mm Travel, Size M-XL 170mm Travel, 30.9mm |
| saddle | Marin Speed Concept |
| extras | Closed 9-12 Thru-Axle Bolt On System |
| FRAME | Series 3 6061 Aluminum, 130mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB w/ ISCG05 Tabs |
| Fork | X-Fusion Slide (29") or Sweep (27.5") Boost RC, 140mm Travel, Compression and Rebound Adjustment, 44mm Offset |
| Shock | X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom |
| RIMS | Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible |
| Hub Rear | Shimano HB-MT200B, 141 QR, Centerlock, Standard Freehub Body |
| Hub Front | Shimano HF-MT400B, 110x15mm, Centerlock |
| SPOKES | 14g Black Stainless Steel |
| Tires | Vee Tire Co. Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless Compatible |
| DERAILLEUR REAR | Shimano Deore, 11-Speed, SGS |
| Shift Lever | Shimano Deore, 11-Speed, SL-5100R |
| Crankset | Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing |
| Bottom Bracket | External Sealed Cartridge Bearing |
| Chain | KMC X-11 Silver and Black |
| Cassette | Sunrace, 11-Speed, 11-51T, ED Black |
| Brakes Front | Tektro HD-M280 Hydraulic, 180mm Rotor |
| Brakes Rear | Tektro HD-M280 Hydraulic, 180mm Rotor |
| Brake Levers | Tektro HD-M280 |
| Handlebar | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back |
| Stem | Marin 3D Forged Alloy, 35mm |
| GRIPS | Marin MTN, Closed End |
| Headset | FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| Seatpost | X-Fusion Manic, 1x Composite Remote, Size XS-S 150mm Travel, Size M-XL 170mm Travel, 30.9mm |
| Saddle | Marin Speed Concept |
| EXTRAS | Closed 9-12 Thru-Axle Bolt On System |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | Deore |
| Fork Brand | Xfusion |
| Fork Travel | 121 - 140mm |
| Shock Travel | 121 - 140mm |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 11 |
| Ride Style | Trail |
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
