The perfect blend of performance, value and fun, the Bolinas Ridge is ideal for riders that are new to mountain biking or simply want a low-hassle, low-cost bike to explore off-road.
The Bolinas Ridge 1 is the best value model in the Bolinas family, offering bags of bang for very few bucks. Components include powerful Clark’s mechanical disc brakes, an SR/Suntour suspension fork and reliable and grippy off-road tires all of which are ideal to break out on the trails and push your own boundaries.
Depending on size, the Bolinas Ridge comes with either smaller 27.5” (sizes XS to M) wheels or larger (sizes M to XL) wheels to guarantee a perfect fit*
frame | Series 1 6061 Aluminum |
front suspension | SR Suntour XCE Disc, 100mm Travel, Preload Adjustment, 46mm Offset |
rim | Marin, Double Wall Alloy |
hubs | Forged Alloy, Disc, 32H |
spokes | Black Stainless Steel |
tires | MTB, 27.5/29x2.25" |
derailleur rear | Shimano Tourney, 7-Speed |
derailleur front | Shimano FD-TX500 |
shift lever | Shimano Tourney 3x7-Speed |
crankset | Alloy Crank, Steel Chainrings, 42/34/24T |
bottom bracket | Sealed Cartridge Bearings, Square Taper |
chain | KMC Z8 |
cassette | Shimano, CSHG200, 7-Speed, 11-32T |
brakes | Clark's CMD-23 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor |
brake levers | Shimano w/ Integrated Shifters |
handlebar | Marin 31.8 Riser, 12mm Rise, 780mm Width |
stem | Marin Alloy, 31.8mm, 45mm |
grips | Marin MTB, Closed End |
headset | FSA No.10-P |
seatpost | Marin Alloy, 27.2mm |
saddle | Marin MTB |
pedals | Nylon platform |
Frame Material | Alloy |
Fork Material | Suspension |
Brake Type | Hydraulic Disc Brake |
Groupset Brand | Shimano |
Groupset Model | Tourney |
Fork Brand | Suntour |
Fork Travel | 0 - 100mm |
Shifting Type | Mechanical |
Pedals Included | Yes |
Drivetrain Gearing | 3 x 7 |
Ride Style | Gravel |
FRAME | Series 1 6061 Aluminum |
FRONT SUSPENSION | SR Suntour XCE Disc, 100mm Travel, Preload Adjustment, 46mm Offset |
Rim | Marin, Double Wall Alloy |
HUBS | Forged Alloy, Disc, 32H |
SPOKES | Black Stainless Steel |
Tires | MTB, 27.5/29x2.25" |
DERAILLEUR REAR | Shimano Tourney, 7-Speed |
DERAILLEUR FRONT | Shimano FD-TX500 |
Shift Lever | Shimano Tourney 3x7-Speed |
Crankset | Alloy Crank, Steel Chainrings, 42/34/24T |
Bottom Bracket | Sealed Cartridge Bearings, Square Taper |
Chain | KMC Z8 |
Cassette | Shimano, CSHG200, 7-Speed, 11-32T |
BRAKES | Clark's CMD-23 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor |
Brake Levers | Shimano w/ Integrated Shifters |
Handlebar | Marin 31.8 Riser, 12mm Rise, 780mm Width |
Stem | Marin Alloy, 31.8mm, 45mm |
GRIPS | Marin MTB, Closed End |
Headset | FSA No.10-P |
Seatpost | Marin Alloy, 27.2mm |
Saddle | Marin MTB |
PEDALS | Nylon platform |
