For All-Round Adventure.
By combining the power of our Dyname™ 4.0 drive system and the all around user friendliness of the Fusion, the Fusion Powerplay opens up a new world of exploration, from trails to the city. Stability, comfort, safety and ease of use are the names of the game here.
range | Check Manufacturer Site |
frame | FORM™ Alloy | Press Fit BB |Integrated Display | Internal Cable Routing | Boost 148mm | Tapered Zerostack Headtube | Dropper Post Compatible. Rear Triangle |
fork | RockShox Recon Gold RL 29 = 120mm 42mm Offset | 27.5 = 100mm 37mm Offset |
front travel | 120 |
headset | FSA Orbit NO.57E ZS44|56 | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
stem | Rocky Mountain 31.8 XC | 7° Rise | All Sizes = 50mm |
handlebar | Rocky Mountain XC | 760mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
grips | Rocky Mountain Lock On Light |
brakes | Shimano MT4100 2 Piston | Resin Pads |
shifters | Shimano Deore 12spd |
rear derailleur | Shimano SLX |
bottom bracket | Shimano SM-BBMT500 |
cassette | Shimano Deore 10-51T 12spd |
chain | Shimano M6100 |
front hub | Shimano MT410 | 15mm Boost |
rear hub | Shimano MT410 Boost 148mm |
spokes | 2.0 Stainless |
rims | WTB ST i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl |
seatpost | X Fusion Manic Composire 30.9mm | XS = 100mm | SM = 100mm | MD = 125mm | LG - XL = 150mm |
saddle | WTB Volt 142 |
drive system | Dyname 4.0 Mountain Bike Drive | 700W Max Power | 250W Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada |
remote | Rocky Mountain Micro Remote |
display | Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration |
charger | Rocky Mountain Powerplay FAST Charger V1 | 4A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4) |
weight | 48.906|22.23 KGS |
cranks & chainring | Race Face Ride Cinch 34T | 24mm Spindle | Crank Length SM - MD = 165mm | LG - XL = 170mm |
battery | Sizes S-XL 720 Wh | Size XS 480 Wh | Removable Integrated Li-Ion |
tires | F- Maxxis Rekon 2.4 WT EXO Tubeless Ready // R- Maxxis Rekon 2.4 WT EXO Tubeless Ready // |
Frame Material | Alloy |
Brake Type | Hydraulic Disc Brake |
Groupset Brand | Shimano |
Groupset Model | Deore |
Fork Brand | Rockshox |
Shifting Type | Mechanical |
Pedals Included | No |
Drivetrain Gearing | 1 x 12 |
Ride Style | Trail |
Range | Check Manufacturer Site |
FRAME | FORM™ Alloy | Press Fit BB |Integrated Display | Internal Cable Routing | Boost 148mm | Tapered Zerostack Headtube | Dropper Post Compatible. Rear Triangle |
Fork | RockShox Recon Gold RL 29 = 120mm 42mm Offset | 27.5 = 100mm 37mm Offset |
FRONT TRAVEL | 120 |
Headset | FSA Orbit NO.57E ZS44|56 | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
Stem | Rocky Mountain 31.8 XC | 7° Rise | All Sizes = 50mm |
Handlebar | Rocky Mountain XC | 760mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
GRIPS | Rocky Mountain Lock On Light |
BRAKES | Shimano MT4100 2 Piston | Resin Pads |
Shifters | Shimano Deore 12spd |
Rear Derailleur | Shimano SLX |
Bottom Bracket | Shimano SM-BBMT500 |
Cassette | Shimano Deore 10-51T 12spd |
Chain | Shimano M6100 |
FRONT HUB | Shimano MT410 | 15mm Boost |
REAR HUB | Shimano MT410 Boost 148mm |
SPOKES | 2.0 Stainless |
RIMS | WTB ST i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl |
Seatpost | X Fusion Manic Composire 30.9mm | XS = 100mm | SM = 100mm | MD = 125mm | LG - XL = 150mm |
Saddle | WTB Volt 142 |
DRIVE SYSTEM | Dyname 4.0 Mountain Bike Drive | 700W Max Power | 250W Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada |
REMOTE | Rocky Mountain Micro Remote |
Display | Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration |
Charger | Rocky Mountain Powerplay FAST Charger V1 | 4A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4) |
Weight | 48.906|22.23 KGS |
Motor Brand | Dyname |
Max Assisted Speed | 32km/h |
Motor Type | Mid-Drive Motor |
Cranks & Chainring | Race Face Ride Cinch 34T | 24mm Spindle | Crank Length SM - MD = 165mm | LG - XL = 170mm |
Battery | Sizes S-XL 720 Wh | Size XS 480 Wh | Removable Integrated Li-Ion |
Tires | F- Maxxis Rekon 2.4 WT EXO Tubeless Ready // R- Maxxis Rekon 2.4 WT EXO Tubeless Ready // |
Ordering a bike from Evo? If you choose the option Evo Home Delivery at the checkout your order will be personally delivered to you, by an Evo Crew Member, who will also be able to answer any questions you have about your new bike. If you choose Evo Delivery your bike will be delivered completely built, tuned and ready to ride! We are also able to offer Evo Home Delivery on previously restricted brands such as Giant & Trek!
Our home delivery charge is only $30 for 15km and $1 per km after that.
Free for all orders over $99. Orders under $99 a $6.99 flat shipping & handling fee applies. Order and pay online and collect everything from one of our showrooms. Just select which store you would like to collect from at checkout. Find out more about Click & Collect here.
LEARN MORE
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
