Experience balanced trail brutality at its finest.
The Slayer is now available in a mixed-wheel setup, is longer and slacker than ever and features a handy PenaltyBox, storage compartment. Nothing can stop you now. Expect villainous levels of confidence when taking on trails or devouring the park.
frame | SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing and Storage Compartment | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 2 Position Axle | 180mm Travel. SMOOTHWALL™ Carbon Rear Triangle |
fork | Fox 38 Float EVOL GRIP2 Performance Elite Series | 180mm | 44mm Offset |
front travel | 180 |
shock | Fox DHX2 Performance Elite | Steel Spring | Sealed Bearing Eyelet | 25x8mm F Hardware | All Sizes = 230 x 65mm | Coil Spring SM - MD - LG - XL = 400 - 450 - 500 - 550 |
rear travel | 180 |
headset | FSA Orbit NO.57E ZS44|56 | Durable Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
stem | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm |
handlebar | Race Face Turbine | 780mm Width | 35mm Rise | 8° Backsweep | 5° Upsweep | 40mm Clamp |
grips | ODI Elite Pro Lock On |
brakes | Shimano XT Trail 4 Piston | Metal Pads |
shifters | Shimano XT |
rear derailleur | SHIMANO XT |
cranks & chainring | Race Face Aeffect R Cinch | 32T | 24mm Spindle | SM = 165mm | MD - XL = 170mm |
bottom bracket | Shimano SM-BBMT500 |
cassette | Shimano XT 10-51T |
chain | Shimano M8100 |
front hub | Rocky Mountain SL Sealed Boost 15mm |
rear hub | DT Swiss 370 Boost 148mm | 18T Star-Ratchet |
spokes | DT Swiss Champion 2.0 |
rims | Race Face ARC HD 30 | 32H / Tubeless Ready - Tape / Valves Incl |
tires | F - Maxxis Assegai 2.5 WT 3C MaxxGrip DD Tubeless Ready // R - Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready // Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection |
seatpost | Race Face Turbine R (by Fox) Dropper 30.9mm | SM = 150mm | MD = 175mm | LG - XL = 200mm |
saddle | WTB Volt Race 142 |
weight | 35.486|16.13 KGS |
FRAME | SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing and Storage Compartment | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 2 Position Axle | 180mm Travel. SMOOTHWALL™ Carbon Rear Triangle |
Fork | Fox 38 Float EVOL GRIP2 Performance Elite Series | 180mm | 44mm Offset |
FRONT TRAVEL | 180 |
Shock | Fox DHX2 Performance Elite | Steel Spring | Sealed Bearing Eyelet | 25x8mm F Hardware | All Sizes = 230 x 65mm | Coil Spring SM - MD - LG - XL = 400 - 450 - 500 - 550 |
REAR TRAVEL | 180 |
Headset | FSA Orbit NO.57E ZS44|56 | Durable Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
Stem | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm |
Handlebar | Race Face Turbine | 780mm Width | 35mm Rise | 8° Backsweep | 5° Upsweep | 40mm Clamp |
GRIPS | ODI Elite Pro Lock On |
BRAKES | Shimano XT Trail 4 Piston | Metal Pads |
Shifters | Shimano XT |
Rear Derailleur | SHIMANO XT |
Cranks & Chainring | Race Face Aeffect R Cinch | 32T | 24mm Spindle | SM = 165mm | MD - XL = 170mm |
Bottom Bracket | Shimano SM-BBMT500 |
Cassette | Shimano XT 10-51T |
Chain | Shimano M8100 |
FRONT HUB | Rocky Mountain SL Sealed Boost 15mm |
REAR HUB | DT Swiss 370 Boost 148mm | 18T Star-Ratchet |
SPOKES | DT Swiss Champion 2.0 |
RIMS | Race Face ARC HD 30 | 32H / Tubeless Ready - Tape / Valves Incl |
Tires | F - Maxxis Assegai 2.5 WT 3C MaxxGrip DD Tubeless Ready // R - Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready // Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection |
Seatpost | Race Face Turbine R (by Fox) Dropper 30.9mm | SM = 150mm | MD = 175mm | LG - XL = 200mm |
Saddle | WTB Volt Race 142 |
Weight | 35.486|16.13 KGS |
Frame Material | Carbon |
Brake Type | Hydraulic Disc Brake |
Groupset Brand | Shimano |
Groupset Model | XT |
Fork Brand | Fox |
Fork Travel | 171 - 220mm |
Shock Travel | 171 - 220mm |
Shifting Type | Mechanical |
Pedals Included | No |
Ride Style | Enduro |
