If you’re looking for one bike that does it all, look no further than the Instinct.
We’ve designed a bike that’s capable of tackling technical trail riding but still allows you to push the pedals hard on the climbs. We’ve updated the geometry, frame features, and suspension kinematics to make sure you feel confident on the up’s, down’s, and everything in between. Trust your Instinct.
frame | SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. SMOOTHWALL™ Carbon Rear Triangle |
fork | Fox 36 Float EVOL GRIP Performance Series 150mm | 27.5 = 37mm Offset | 29 = 44mm Offset |
front travel | 150 |
shock | Fox Float DPS Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ |
rear travel | 140 |
headset | FSA Orbit NO.57E | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
stem | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m |
handlebar | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp |
grips | ODI Elite Pro Lock On |
shifters | Shimano XT |
rear derailleur | SHIMANO XT |
bottom bracket | Shimano SM-BBMT500 |
cassette | Shimano SLX 10-51T |
chain | Shimano M6100 |
front hub | ROCKY MOUNTAIN SEALED BOOST 15MM |
rear hub | DT Swiss 370 Boost 148mm | 18T Star-Ratchet |
spokes | DT Swiss Champion 2.0 |
rims | WTB ST Light i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl |
seatpost | Rocky Mountain Toonie Drop Alloy 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm |
saddle | WTB Volt Race 142 |
weight | 31.24|14.2 KGS |
cranks & chainring | Race Face Aeffect Cinch | 32T Steel | 24mm Spindle | Crankarm Length XS = 165mm Crankarm | SM - XL = 170mm |
tires | F- Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready // R- Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready |
Frame Material | Carbon |
Brake Type | Hydraulic Disc Brake |
Groupset Brand | Shimano |
Groupset Model | XT |
Fork Brand | Fox |
Fork Travel | 141 - 170mm |
Shock Travel | 121 - 140mm |
Shifting Type | Mechanical |
Pedals Included | No |
Ride Style | Trail |
FRAME | SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. SMOOTHWALL™ Carbon Rear Triangle |
Fork | Fox 36 Float EVOL GRIP Performance Series 150mm | 27.5 = 37mm Offset | 29 = 44mm Offset |
FRONT TRAVEL | 150 |
Shock | Fox Float DPS Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ |
REAR TRAVEL | 140 |
Headset | FSA Orbit NO.57E | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
Stem | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m |
Handlebar | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp |
GRIPS | ODI Elite Pro Lock On |
Shifters | Shimano XT |
Rear Derailleur | SHIMANO XT |
Bottom Bracket | Shimano SM-BBMT500 |
Cassette | Shimano SLX 10-51T |
Chain | Shimano M6100 |
FRONT HUB | ROCKY MOUNTAIN SEALED BOOST 15MM |
REAR HUB | DT Swiss 370 Boost 148mm | 18T Star-Ratchet |
SPOKES | DT Swiss Champion 2.0 |
RIMS | WTB ST Light i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl |
Seatpost | Rocky Mountain Toonie Drop Alloy 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm |
Saddle | WTB Volt Race 142 |
Weight | 31.24|14.2 KGS |
Cranks & Chainring | Race Face Aeffect Cinch | 32T Steel | 24mm Spindle | Crankarm Length XS = 165mm Crankarm | SM - XL = 170mm |
Tires | F- Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready // R- Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready |
