Domane SL 5 is all about smooth riding, speed and versatility. The lightweight OCLV Carbon frame has both Front and Rear IsoSpeed to smooth out bumps in the road and reduce fatigue so you can stay stronger on long adventures. It has a reliable Shimano 105 drivetrain, disc brakes for all-weather stopping power and an easy-access internal storage compartment for stowing ride essentials.
It's right for you if...
You want a versatile, capable carbon bike with a super smooth ride that keeps you going strong on all-day adventures. It's a great choice if you're likely to ride in conditions where the added capability of wider tyres and disc brakes will make a big difference.
The tech you get
A 500 Series OCLV Carbon frame with road-smoothing Front and Rear IsoSpeed, powerful flat-mount disc brakes, a full 2x11 Shimano 105 group set and tubeless-ready wheels with wider 700x32 tyres. Internal storage and cable routing add to the bike's capability and sleek look.
The final word
Carbon, comfort, capability. Domane SL 5 is purpose-built for long rides with a carbon frame, stable Endurance Geometry and road-smoothing Front and Rear IsoSpeed. You also get the added advantage of a higher-end Shimano 105 drivetrain and powerful disc brakes that let you run wider tyres.
Why you'll love it
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | 500 Series OCLV Carbon, front and rear IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, DuoTrap S-compatible, mudguard mounts, flat-mount disc, 142x12 mm thru axle |
| tubeless | Bontrager TLR sealant, 180 ml/6 oz, Bontrager XXX TLR valve, 50 mm, Bontrager Aeolus XXX rim strip |
| frame fit | Endurance |
| hub front | Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle |
| skewer front | Bontrager Switch thru axle, removable lever |
| hub rear | Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle |
| skewer rear | Bontrager Switch thru-axle, removable lever |
| rim | Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve |
| tyre | Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32 c |
| max tyre size | 38c |
| shifter | Shimano 105 R7025/R7020, short-reach lever (44, 47, 50, 52), 11-speed |
| front derailleur | Shimano 105 R7000, braze-on |
| rear derailleur | Shimano 105 R7000, long cage, 34T max cog |
| crank | Shimano 105 R7000, 50/34 (compact), 165 mm length (44, 47), 170 mm length (50, 52), 172.5 mm length (54, 56), 175 mm length (58, 60) |
| bottom bracket | Praxis, T47 threaded, internal bearing |
| cassette | Shimano 105 HG700-11, 11-34, 11-speed |
| chain | Shimano 105 HG601, 11-speed |
| saddle | Bontrager P3 Verse Comp, steel rails, 145 mm width |
| seatpost | Bontrager carbon internal seat mast cap, integrated light mount, 20 mm offset |
| handlebar | Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop (44, 47, 50, 52) / 124mm drop (54, 56, 58, 60), 36 cm width (44, 47) / 38 cm width (50) / 40 cm width (52) / 42 cm width (54, 56) / 44 cm width (58, 60) |
| handlebar tape | Bontrager Supertack Perf tape |
| stem | Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree |
| brake rotor | Shimano SM-RT70, CenterLock, 160 mm |
| bag | Bontrager BITS Internal Frame Storage Bag |
| weight | 56 - 20.28 lbs / 9.2 kg |
| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Frame Material | Carbon |
| Groupset Brand | Shimano |
| Groupset Model | 105 |
| Pedals Included | No |
| Ride Style | Endurance |
| Fork Material | Carbon |
| FRAME | 500 Series OCLV Carbon, front and rear IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, DuoTrap S-compatible, mudguard mounts, flat-mount disc, 142x12 mm thru axle |
| Tubeless | Bontrager TLR sealant, 180 ml/6 oz, Bontrager XXX TLR valve, 50 mm, Bontrager Aeolus XXX rim strip |
| Frame Fit | Endurance |
| Hub Front | Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle |
| Skewer front | Bontrager Switch thru axle, removable lever |
| Hub Rear | Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle |
| Skewer rear | Bontrager Switch thru-axle, removable lever |
| Rim | Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve |
| Tyre | Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32 c |
| MAX TYRE SIZE | 38c |
| Shifter | Shimano 105 R7025/R7020, short-reach lever (44, 47, 50, 52), 11-speed |
| Front Derailleur | Shimano 105 R7000, braze-on |
| Rear Derailleur | Shimano 105 R7000, long cage, 34T max cog |
| CRANK | Shimano 105 R7000, 50/34 (compact), 165 mm length (44, 47), 170 mm length (50, 52), 172.5 mm length (54, 56), 175 mm length (58, 60) |
| Bottom Bracket | Praxis, T47 threaded, internal bearing |
| Cassette | Shimano 105 HG700-11, 11-34, 11-speed |
| Chain | Shimano 105 HG601, 11-speed |
| Saddle | Bontrager P3 Verse Comp, steel rails, 145 mm width |
| Seatpost | Bontrager carbon internal seat mast cap, integrated light mount, 20 mm offset |
| Handlebar | Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop (44, 47, 50, 52) / 124mm drop (54, 56, 58, 60), 36 cm width (44, 47) / 38 cm width (50) / 40 cm width (52) / 42 cm width (54, 56) / 44 cm width (58, 60) |
| HANDLEBAR TAPE | Bontrager Supertack Perf tape |
| Stem | Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree |
| BRAKE ROTOR | Shimano SM-RT70, CenterLock, 160 mm |
| BAG | Bontrager BITS Internal Frame Storage Bag |
| Weight | 56 - 20.28 lbs / 9.2 kg |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
