IsoSpeed allows the bike to feel smoother and comfier without sacrificing performance.
Wireless 12 speed SRAM Red AXS gives you unparalleled shifting performance with all the gears you need.
The aero handlebar and stem gives you good adjustability without sacraficing Aero performance.
Hydraulic disc brakes gives you the best braking performance to hit those descents even harder.
Madone SLR 9 Disc eTap pairs the aerodynamics and ride quality of the ultimate race bike with the smoothness of SRAM's most advanced electronic drivetrain, RED eTap AXS. It's the first-ever wireless electronic groupset with a 12-speed cassette. Saddle up for the quickest and smartest shifting of your life.
It's right for you if...
You want every advantage in speed and handling, and want a bike with the best tech available: Trek's highest-end Madone frame and a top-of-the-line 12-speed SRAM RED eTap AXS wireless electronic drivetrain that shifts with crisp precision.
The tech you get
A lightweight 700 Series OCLV Carbon frame with Kammtail Virtual Foil aerodynamic tube shaping and road-smoothing Adjustable Top Tube IsoSpeed, KVF full carbon fork, an adjustable aero bar and stem, a 2x12 SRAM RED eTap AXS wireless electronic drivetrain, Tubeless Ready Bontrager Aeolus XXX 6 wheels, a micro-adjust Madone seatmast and RED flat-mount hydraulic disc brakes.
The final word
Madone SLR 9 Disc eTap is built with the fastest road bike frame that Trek makes, but what sets this model apart is the 12-speed SRAM RED eTap AXS electronic drivetrain. It's eTap evolved to be smoother and more intuitive, and you can personalise every setting using the AXS app.
Why you'll love it
Please note: Bike accessories shown in images sold separately (e.g. Racks, Lights etc). Please refer to bike specifications for included components.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | 700 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, adjustable top tube IsoSpeed, invisible cable routing, control c |
| fork | Madone KVF full carbon, tapered carbon steerer, invisible cable routing, flat-mount disc, carbon dropouts, 12x100mm thru axle |
| wheels | Bontrager Aeolus XXX 6, OCLV Carbon, Tubeless Ready, 21mm rim width, 60mm rim depth, 12mm thru-axle |
| tyres | Bontrager R4 320 Handmade Clincher, Hard-Case Lite, 320 tpi, 700x25c |
| shifters | SRAM RED eTap AXS, 12-speed |
| front derailleur | SRAM RED eTap AXS, braze-on |
| rear derailleur | SRAM RED eTap AXS, Orbit chain management, 33T max cog |
| crank | SRAM RED D1, 48/35, 24mm spindle |
| bottom bracket | Trek BB90 |
| cassette | SRAM RED XG-1290, 10-28, 12-speed |
| chain | SRAM RED D1, 12-speed |
| saddle | Bontrager Montrose Pro, carbon rails, 138mm width |
| seatpost | Madone aero carbon seatmast cap, integrated light mount, 25mm offset |
| handlebar | Trek Madone adjustable aero VR-CF, OCLV Carbon, internal cable routing |
| grips | Bontrager Supertack Perf tape |
| stem | Trek Madone aero, invisible cable routing |
| brake set | SRAM Red hydraulic disc, flat mount, 160mm rotors |
| weight | 56 - 7.98kg / 17.6lbs |
| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125kg (275lb) |
| head set | Madone integrated, stainless cartridge bearings, sealed, 1-3/8? top, 1.5" bottom |
| Fork Material | Carbon |
| Frame Material | Carbon |
| Groupset Brand | Sram |
| Groupset Model | Red |
| Pedals Included | No |
| FRAME | 700 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, adjustable top tube IsoSpeed, invisible cable routing, control c |
| Fork | Madone KVF full carbon, tapered carbon steerer, invisible cable routing, flat-mount disc, carbon dropouts, 12x100mm thru axle |
| Wheels | Bontrager Aeolus XXX 6, OCLV Carbon, Tubeless Ready, 21mm rim width, 60mm rim depth, 12mm thru-axle |
| TYRES | Bontrager R4 320 Handmade Clincher, Hard-Case Lite, 320 tpi, 700x25c |
| Shifters | SRAM RED eTap AXS, 12-speed |
| Front Derailleur | SRAM RED eTap AXS, braze-on |
| Rear Derailleur | SRAM RED eTap AXS, Orbit chain management, 33T max cog |
| CRANK | SRAM RED D1, 48/35, 24mm spindle |
| Bottom Bracket | Trek BB90 |
| Cassette | SRAM RED XG-1290, 10-28, 12-speed |
| Chain | SRAM RED D1, 12-speed |
| Saddle | Bontrager Montrose Pro, carbon rails, 138mm width |
| Seatpost | Madone aero carbon seatmast cap, integrated light mount, 25mm offset |
| Handlebar | Trek Madone adjustable aero VR-CF, OCLV Carbon, internal cable routing |
| GRIPS | Bontrager Supertack Perf tape |
| Stem | Trek Madone aero, invisible cable routing |
| BRAKE SET | SRAM Red hydraulic disc, flat mount, 160mm rotors |
| Weight | 56 - 7.98kg / 17.6lbs |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125kg (275lb) |
| Head Set | Madone integrated, stainless cartridge bearings, sealed, 1-3/8? top, 1.5" bottom |
| Ride Style | Aero Race |
| IsoSpeed Front and Rear | IsoSpeed allows the bike to feel smoother and comfier without sacrificing performance. |
| Electronic Groupset | Wireless 12 speed SRAM Red AXS gives you unparalleled shifting performance with all the gears you need. |
| Aero Handlebar and Stem | The aero handlebar and stem gives you good adjustability without sacraficing Aero performance. |
| Hydraulic Disc Brakes | Hydraulic disc brakes gives you the best braking performance to hit those descents even harder. |
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
